Tops 1 Power LED
OSXXXAT1C1S
■
Features
●
●
●
■
Outline
Dimension
Highest Luminous Flux
Super Energy Efficiency
Long Lifetime Operation
Superior ESD protection
Superior UV Resistance
Electronic Signs And Signals
Small Area Illuminations
Back Lighting
Other Lighting
Bollards / Security / Garden
Traffic signaling / Beacons
-
+
●
●
■
Applications
●
●
●
●
●
●
Unit:mm
Tolerance:±0.30mm
-
+
■
Absolute
Maximum Rating
Symbo
l
I
F
I
FP
V
R
P
D
Topr
Tstg
Tsol
Item
DC Forward Current
Pulse Forward Current*
Reverse Voltage
Power Dissipation
Operating Temperature
Storage Temperature
Lead Soldering Temperature
(Ta=25℃)
Value
W/M/B/G
400
500
5
1600
-40 ~ +85
-40~ +85
260
℃
/5sec
R
400
500
5
1200
■
Directivity
Unit
mA
mA
V
mW
0
0
℃
℃
-
*Pulse width Max 0.1ms, Duty ratio max 1/10
■
Electrical
-Optical Characteristics
V
F
(V)
(Ta=25℃)
I
R
(µA)
Max.
Max.
V
R
=5V
4.0
4.0
4.0
4.0
Φv(lm)*
Min.
90
80
λD(nm)*
Max.
-
-
-
-
Min.
Typ.
Max.
I
F
=350mA
2θ1/2(deg)
Part Number
OSW4XAT1C1S
OSB5XAT1C1S
OSG5XAT1C1S
OSR5XAT1C1S
Color
White
Blue
Pure Green
Red
W
■
B
■
G
■
R
■
Min.
Typ.
I
F
=350mA
Typ.
100
90
Typ.
120
120
120
120
120
3.0
3.0
3.0
3.0
3.3
3.3
3.3
3.3
10
10
10
10
10
X=0.31, Y=0.33
X=0.45, Y=0.41
465
520
620
470
525
625
475
530
630
OSM5XAT1C1S
Warm White
M
■
10
65
40
15
75
50
2.0
2.5
3.0
Note: *1. Tolerance of chromaticity coordinates is
±10%
*2. Dominant wavelength tolerance: ±1nm
*3. Tolerance of luminous Flux is
±15%
