5-1437471-9

Description
ON-DELAY RELAY, DPDT, MOMENTARY, 12VDC (COIL), 10A (CONTACT), 28VDC (CONTACT), 0.1-3s, SOCKET MOUNT
CategoryMechanical and electronic products    relay
File Size109KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

5-1437471-9 Overview

ON-DELAY RELAY, DPDT, MOMENTARY, 12VDC (COIL), 10A (CONTACT), 28VDC (CONTACT), 0.1-3s, SOCKET MOUNT

5-1437471-9 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerTE Connectivity
Reach Compliance Codeunknown
ECCN codeEAR99
Maximum adjustable time delay3 s
Minimum adjustable time delay0.1 s
body width50 mm
body height83 mm
Body length or diameter50 mm
Maximum coil voltage (DC)12 V
Contact (AC) maximum rated R load10A@120VAC
Maximum contact current (AC)10 A
Maximum contact current (DC)10 A
Contact (DC) maximum rated R load10A@28VDC
Maximum contact voltage (AC)120 V
Maximum contact voltage (DC)28 V
Contact/Output Power TypeAC/DC
Manufacturer's serial number1437471
Installation featuresSOCKET MOUNT
Maximum operating temperature65 °C
Minimum operating temperature-30 °C
physical size50mm x 50mm x 83mm
GuidelineCE; CSA; FM
Relay actionMOMENTARY
Relay functionDPDT
Relay typeON-DELAY RELAY
surface mountNO
Termination typeSNAP-ON
My Account
Tyco Electronics
(C hange)
Se a rch by Ke yword or Pa rt #
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Relays
>
Product Feature Selector
> Product Details
SSC12QAA Product Details
Time Delay Relays
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
SSC12QAA
(5-1437471-9)
T E I nternal N umber: 5 - 1 4 3 7 4 7 1 - 9
Product Highlights:
l
SSC Specification Grade Timing Series
l
Input Voltage = 12 VDC
l
C ontact Arrangement = 2 Form C , DPDT, 2 C /O
l
C ontact Rating = 10A Resistive @ 28 VDC /120 VAC
l
Mounting Options = Socket
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Termination Type = 8-Pin Octal Style Plug
Electrical Characteristics:
l
Input Voltage (VDC ) = 12
l
C ontact Rating = 10A Resistive @ 28 VDC /120 VAC
Body Related Features:
l
Series
= SSC Specification Grade Timing
Contact Related Features:
l
Mounting Options = Socket
l
Mode of Operation = On-Delay
l
Delay Time = 0.1 seconds to 3 seconds
l
Type of C ontrol = Knob
l
Repeatability, Max. = ±1% +4 msec
l
Approved Standards = C E Approved, C SA C ertified, FM Approved
l
Approx. Dimensions (L x W x H) (mm [in]) = 50.00 x 50.00 x 83.00
[1.970 x 1.970 x 3.270]
Configuration Related Features:
l
C ontact Arrangement
= 2 Form C , DPDT, 2 C /O
l
Multiple Timing Ranges = Without
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not suitable for lead free processing
Conditions for Usage:
l
Temperature Range (?C ) = -30 – +65
Other:
l
Brand = Agastat
