10-55-10 Hz, 2.5 mm single amplitude (5 mm double amplitude) and 55 to 500 Hz, 300 m/s
2
10-55-10 Hz, 1.65 mm single amplitude (3.3 mm double amplitude) and 55 to 500 Hz, 200 m/s
2
1,000 m/s
2
750 m/s
2
50,000,000 operations min. (at 36,000 operations/hour)
100,000 operations min. (with a rated load at 1,800 operations/hour)
10
μA
at 10 mVDC
-40 to 70°C (with no icing or condensation)
5% to 85%
Approx. 0.7 g
*3.
This value was measured at a switching frequency of 120
operations/min and the criterion of contact resistance is
50
Ω.
This value may vary depending on the switching
frequency
and
operating
environment.
Always
double-check relay suitability under actual operating
conditions.
Failure rate (P level) *3
Ambient operating temperature
Ambient operating humidity
Weight
Note: The above values are initial values.
*1. The contact resistance was measured with 10 mA at 1
VDC with a voltage-drop method.
*2. The insulation resistance was measured with a 500 VDC
megohmmeter applied to the same parts as those used for
checking the dielectric strength.
2
G6K
■Engineering
Data
●Maximum
Switching Capacity
Switching
current (A)
10
7
5
3
Surface Mounting Relay
●Durability
Durability (x10
4
operations)
1,000
500
300
●Ambient
Temperature vs.
Maximum Coil Voltage
Maximum coil voltage (%)
250
200
100
50
30
1
0.7
0.5
DC resistive load
0.3
AC resistive load
30 VDC resistive load
Ambient temperature: 23°C
Switching frequency:
1,800 operations/hour
150
100
10
5
3
125 VAC resistive load
Ambient temperature: 23°C
Switching frequency:
1,800 operations/hour
50
0.1
10
30
50 70 100
300
500 700 1,000
Switching
voltage (V)
1
0
0.2
0.4
0.6
0.8
1
1.2
Switching current (A)
0
−40
−20
0
20
40
60
80
100
Ambient temperature (°C)
Note: The maximum coil voltage refers to the maximum
value in a varying range of operating power
voltage, not a continuous voltage.
●Ambient
Temperature vs.
Switching Current
Switching
current (A)
1.2
●Ambient
Temperature vs. Must
Operate or Must Release Voltage
G6K-2G (F/P), G6K-2G (F/P)-Y
On the
basis
of rated voltage (%)
100
90
80
70
60
50
40
30
max.
−
X
min.
Must operate voltage
Must release voltage
−40
−20
0
20
40
60
80
100
max.
−
X
min.
●Ambient
Temperature vs. Must
Set or Must Reset Voltage
G6KU-2G (F/P)-Y
On the basis of rated voltage (%)
100
90
80
70
60
50
40
1
Max. estimated value
0.8
0.6
max.
−
X
min.
G
6
K
0.4
0.2
20
10
0
−40
−20
0
20
40
60
80
100
0
−60
30
−60
−40
−20
0
20
40
60
80 100
Ambient temperature (°C)
Ambient temperature (°C)
Ambient temperature (°C)
●Shock
Malfunction
Y
1,000
800
X
1,000
600 De-
energized
400
200
Z
1,000
Energized
●Electrical
Durability (with Must Operate
●Electrical
Durability
and Must Release Voltage)
*1
(Contact Resistance)
*1
G6K-2G (F/P), G6K-2G (F/P)-Y
G6K-2G (F/P), G6K-2G (F/P)-Y
On the basis of rated voltage (%)
Sample: G6K-2G
Number of Relays: 10 pcs
Test conditions: 1 A resistive load at 30 VDC
with an operation rate of 50%
80
Switching frequency: 1,800 operations/h
max.
60
min.
Must operate voltage
Contact resistance (m
Ω
)
100
1,000
Sample: G6K-2G
Number of Relays: 10 pcs
Test conditions: 1 A resistive load
500
at 30 VDC with an operation rate
of 50%
300
Switching frequency: 1,800
operations/h
NO contact
NC contact
100
40
200
1,000
Z'
Shock directions
X
X'
Y
Z
Z'
Y'
400
600
800
1,000
Unit: m/s
2
Sample: G6K-2G
Number of Relays: 10 pcs
1,000
X'
Contact resistance
50
max.
min.
max.
max.
min.
min.
20
Y'
30
Must release voltage
0
0.001
0.01
Conditions: Shock is applied in ±X, ±Y, and ±Z
directions three times each with and
without energizing the Relays to check
the number of contact malfunctions.
●Contact
Reliability Test
*1, *2
0.1
1
10
100
Operating frequency (x10
3
operations)
10
0.001
0.01
0.1
1
10
100
Operating frequency (x10
3
operations)
G6K-2G (F/P), G6K-2G (F/P)-Y
1,000
Sample: G6K-2G
Number of Relays: 10 pcs
500 Test conditions: 10
μA
resistive
load at 10 m VDC with an
operation rate of 50%
300 Switching frequency: 7,200
operations/h
●Mutual
Magnetic Interference
G6K-2G (F/P), G6K-2G (F/P)-Y
+30
+20
+10
0
−10
−20
−30
+30
+20
+10
0
−10
−20
−30
Change rate on the
basis of initial value (%)
●Mutual
Magnetic Interference
G6K-2G (F/P), G6K-2G (F/P)-Y
Change rate on the
basis of initial value (%)
Contact resistance (m
Ω
)
Initial stage
Test
NO contact
max.
NC contact
min.
Sample
De-energized
Sample
Average value
De-energized
+30
+20
+10
0
−10
−20
−30
+30
+20
+10
0
−10
−20
−30
Initial stage
Test
Average value
100
max.
max.
min.
min.
Change rate on the
basis of initial value (%)
50
30
Sample
Energized
Sample
Average value
Must operate voltage
Must release voltage
Energized
Change rate on the
basis of initial value (%)
Initial stage
Test
Initial stage
Test
10
0.001 0.01
Average value
Must operate voltage
Must release voltage
0.1
1
10
100 1,000 10,000 100,000
Operating frequency (x10
3
operations)
*1.
*2.
The test was conducted at an ambient temperature of 23°C.
The contact resistance data are periodically measured reference values and are not values from each monitoring operation. Contact resistance values will vary
according to the switching frequency and operating environment, so be sure to check operation under the actual operating conditions before use.
3
G6K
●External
Magnetic Interference
G6K-2G (F/P), G6K-2G (F/P)-Y
(Average value)
Change rate on the basis of initial value (%)
Surface Mounting Relay
(Average value)
Change rate on the basis of initial value (%)
S
+20
N
S
N
(Average value)
Change rate on the basis of initial value (%)
+30
S
+20
N
S
N
+30
S
+20
N
S
N
+30
+10
+10
+10
0
0
0
−10
−10
−10
−20
−30
−1,200
Sample: G6K-2G
Number of Relays: 10 pcs
−800
−400
Must operate voltage
Must release voltage
0
400
800 1,200
External magnetic field (A/m)
−20
−30
−1,200
Sample: G6K-2G
Number of Relays: 10 pcs
−800
−400
Must operate voltage
Must release voltage
0
400
800 1,200
External magnetic field (A/m)
−20
−30
−1,200
Sample: G6K-2G
Number of Relays: 10 pcs
−800
−400
Must operate voltage
Must release voltage
0
400
800 1,200
External magnetic field (A/m)
●High-frequency
Characteristics
(Isolation) *1, *2
G6K-2G (F/P), G6K-2G (F/P)-Y
(Average value (initial))
Isolation (dB)
●High-frequency
Characteristics
(Insertion Loss) ) *1, *2
G6K-2G (F/P), G6K-2G (F/P)-Y
(Average value (initial))
Insertion loss (dB)
0
●High-frequency
Characteristics
(Return Loss) *1, *2
G6K-2G (F/P),G6K-2G (F/P)-Y
(Average value (initial))
Return loss (dB)
0
10
20
30
Return loss
40
1.2
1.15
1.1
1.05
1
100
Frequency (MHz)
Sample: G6K-2F-Y
Number of Relays: 5 pcs
1.4
1.35
1.3
1.25
V.SWR
G
6
K
Sample: G6K-2G
10 Number of Relays: 10 pcs
20
30
40
50
60
70
0
0.1
0.2
0.3
50
60
80
90
100
1
10
100
Frequency (MHz)
0.4
Sample: G6K-2G
Number of Relays: 10 pcs
10
100
Frequency (MHz)
70
80
1
V.SWR
10
0.5
1
●Must
Operate and Must Release
Time Distribution *1
G6K-2G (F/P), G6K-2G (F/P)-Y
Number of contacts
60
Sample: G6K-2G
Number of Relays:
50 pcs
Must operate
voltage
Must release
voltage
●Must
Operate and Must Release
Bounce Time Distribution *1
G6K-2G (F/P) , G6K-2G (F/P)-Y
Number of contacts
60
Must operate bounce time
Must release bounce time
●Vibration
Resistance
G6K-2G (F/P), G6K-2G (F/P)-Y
Change rate on the
basis
of rated value (%)
10.0
5.0
40
40
Must operate voltage
0.0
Must release voltage
20
20
−5.0
0
0.5
1
1.5
2
2.5
3
0
0.5
1
Sample: G6K-2G
Number of Relays: 50 pcs
1.5
2
2.5
3
Time (ms)
−10.0
Initial
After test
Time (ms)
*1.
*2.
The tests were conducted at an ambient temperature of 23°C.
High-frequency characteristics depend on the PCB to which the Relay is mounted. Always check these characteristics including endurance in the actual machine
before use.
4
G6K
■Dimensions
(Unit: mm)
●Single-side
Stable
G6K-2F
5.2
±0.2
1.6
0.5
±0.1
1.19
2.54
7.8
(2.54) (2.54)
5.08
7.62
0.8
(1.19)
1.8
Surface Mounting Relay
Mounting Dimensions
(TOP VIEW)
Tolerance: ±0.1 mm
10
±0.2
6.5
±0.2
2.54
7.62
5.08
Terminal Arrangement/
Internal Connections
(TOP VIEW)
8
7
6
5
0.3
7
1
2
3
4
Note 1. Each value has a tolerance of ±0.3 mm.
Note 2. The coplanarity of the terminals is 0.1 mm max.
Orientation mark
G6K-2G
10
±0.2
6.5
±0.2
Mounting Dimensions
(TOP VIEW)
Tolerance: ±0.1 mm
2.54
5.4
±0.2
1.8
0.5
±0.1
1.19
2.54
4.9
(2.54) (2.54)
5.08
7.62
0.5
0.8
(1.19)
1.8
5.7
7.62
5.08
Terminal Arrangement/
Internal Connections
(TOP VIEW)
8
7
6
5
1
2
3
4
Note 1. Each value has a tolerance of ±0.3 mm.
Note 2. The coplanarity of the terminals is 0.1 mm max.
Orientation mark
G6K-2P
10
±0.2
6.5
±0.2
2.54
PCB Mounting Holes
(Bottom VIEW)
Tolerance: ±0.1 mm
2.54
Eight, 0.85-dia. holes
Terminal Arrangement/
Internal Connections
(Bottom VIEW)
Orientation mark
G
6
K
5
3.5
0.5
1
2
3
4
0.4
±0.1
1.19
2.54
5.08
(2.54) (2.54)
5.08
7.62
R0.2
5.08
(0.71)
(1.19)
7.62
0.15
8
7
6
5
Note: Each value has a tolerance of ±0.3 mm.
G6K-2F-Y
10
±0.2
6.5
±0.2
Mounting Dimensions
(TOP VIEW)
Tolerance: ±0.1 mm
3.2
7.6
5.4
Terminal Arrangement/
Internal Connections
(TOP VIEW)
8
7
6
5
5.2
±0.2
1.6
0.5
±0.1
1.2
3.2
7.8
(2.2) (2.2)
5.4
7.6
0.8
(1.2)
1.8
0.3
7
1
2
3
4
Orientation mark
Note 1. Each value has a tolerance of ±0.3 mm.
Note 2. The coplanarity of the terminals is 0.1 mm max.
G6K-2G-Y
10
±0.2
6.5
±0.2
Mounting Dimensions
(TOP VIEW)
Tolerance: ±0.1 mm
3.2
5.4
±0.2
1.8
0.5
±0.1
1.2
3.2
4.9
(2.2) (2.2)
5.4
7.6
0.5
0.8
(1.2)
1.8
5.7
7.6
5.4
Terminal Arrangement/
Internal Connections
(TOP VIEW)
8
7
6
5
1
2
3
4
Orientation mark
Note 1. Each value has a tolerance of ±0.3 mm.
Note 2. The coplanarity of the terminals is 0.1 mm max.
京公网安备 11010802033920号
EEWORLD
