Part Number

Search

GS832218E-225M

Description
Cache SRAM, 2MX18, 7ns, CMOS, PBGA165, 17 X 15 MM, 1 MM PITCH, FPBGA-165
Categorystorage    storage
File Size679KB,39 Pages
ManufacturerGSI Technology
Websitehttp://www.gsitechnology.com/
Download Datasheet Parametric Compare View All

GS832218E-225M Overview

Cache SRAM, 2MX18, 7ns, CMOS, PBGA165, 17 X 15 MM, 1 MM PITCH, FPBGA-165

GS832218E-225M Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerGSI Technology
Parts packaging codeBGA
package instructionLBGA, BGA165,11X15,40
Contacts165
Reach Compliance Codeunknown
ECCN code3A991.B.2.B
Maximum access time7 ns
Other featuresFLOW-THROUGH OR PIPELINED ARCHITECTURE, IT ALSO OPERATES AT AS 3.3V SUPPLY
Maximum clock frequency (fCLK)225 MHz
I/O typeCOMMON
JESD-30 codeR-PBGA-B165
length17 mm
memory density37748736 bit
Memory IC TypeCACHE SRAM
memory width18
Number of functions1
Number of terminals165
word count2097152 words
character code2000000
Operating modeSYNCHRONOUS
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
organize2MX18
Output characteristics3-STATE
Package body materialPLASTIC/EPOXY
encapsulated codeLBGA
Encapsulate equivalent codeBGA165,11X15,40
Package shapeRECTANGULAR
Package formGRID ARRAY, LOW PROFILE
Parallel/SerialPARALLEL
power supply2.5/3.3 V
Certification statusNot Qualified
Maximum seat height1.5 mm
Maximum standby current0.2 A
Minimum standby current2.3 V
Maximum slew rate0.28 mA
Maximum supply voltage (Vsup)2.7 V
Minimum supply voltage (Vsup)2.3 V
Nominal supply voltage (Vsup)2.5 V
surface mountYES
technologyCMOS
Temperature levelMILITARY
Terminal formBALL
Terminal pitch1 mm
Terminal locationBOTTOM
width15 mm
GS832218/36(B/E)-225M
GS832272C-225M
119-, 165-, & 209-Pin BGA
Military Temp
Features
• Military Temperature Range
• FT pin for user-configurable flow through or pipeline operation
• Single/Dual Cycle Deselect selectable
• IEEE 1149.1 JTAG-compatible Boundary Scan
• ZQ mode pin for user-selectable high/low output drive
• 2.5 V +10%/–10% core power supply
• 3.3 V +10%/–10% core power supply
• 2.5 V or 3.3 V I/O supply
• LBO pin for Linear or Interleaved Burst mode
• Internal input resistors on mode pins allow floating mode pins
• Default to SCD x18/x36 Interleaved Pipeline mode
• Byte Write (BW) and/or Global Write (GW) operation
• Internal self-timed write cycle
• Automatic power-down for portable applications
• JEDEC-standard 119-, 165-, and 209-bump BGA package
• RoHS-compliant packages available
2M x 18, 1M x 36, 512K x 72
36Mb S/DCD Sync Burst SRAMs
225 MHz
2.5 V or 3.3 V V
DD
2.5 V or 3.3 V I/O
either linear or interleave order with the Linear Burst Order (LBO)
input. The Burst function need not be used. New addresses can be
loaded on every cycle with no degradation of chip performance.
Flow Through/Pipeline Reads
The function of the Data Output register can be controlled by the
user via the FT mode . Holding the FT mode pin low places the
RAM in Flow Through mode, causing output data to bypass the
Data Output Register. Holding FT high places the RAM in
Pipeline mode, activating the rising-edge-triggered Data Output
Register.
SCD and DCD Pipelined Reads
The GS832218/36/72-225M is a SCD (Single Cycle Deselect) and
DCD (Dual Cycle Deselect) pipelined synchronous SRAM. DCD
SRAMs pipeline disable commands to the same degree as read
commands. SCD SRAMs pipeline deselect commands one stage
less than read commands. SCD RAMs begin turning off their
outputs immediately after the deselect command has been
captured in the input registers. DCD RAMs hold the deselect
command for one full cycle and then begin turning off their
outputs just after the second rising edge of clock. The user may
configure this SRAM for either mode of operation using the SCD
mode input.
Byte Write and Global Write
Byte write operation is performed by using Byte Write enable
(BW) input combined with one or more individual byte write
signals (Bx). In addition, Global Write (GW) is available for
writing all bytes at one time, regardless of the Byte Write control
inputs.
FLXDrive™
The ZQ pin allows selection between high drive strength (ZQ low)
for multi-drop bus applications and normal drive strength (ZQ
floating or high) point-to-point applications. See the Output Driver
Characteristics chart for details.
Functional Description
Applications
The GS832218/36/72-225M is a
37,748,736
-bit high
performance synchronous SRAM with a 2-bit burst address
counter. Although of a type originally developed for Level 2
Cache applications supporting high performance CPUs, the device
now finds application in synchronous SRAM applications, ranging
from DSP main store to networking chip set support.
Controls
Addresses, data I/Os, chip enable (E1), address burst control
inputs (ADSP, ADSC, ADV), and write control inputs (Bx, BW,
GW) are synchronous and are controlled by a positive-edge-
triggered clock input (CK). Output enable (G) and power down
control (ZZ) are asynchronous inputs. Burst cycles can be initiated
with either ADSP or ADSC inputs. In Burst mode, subsequent
burst addresses are generated internally and are controlled by
ADV. The burst address counter may be configured to count in
Parameter Synopsis
-225M
t
KQ
(x18/x36)
t
KQ
(x72)
tCycle
Curr (x18)
Curr (x36)
Curr (x72)
t
KQ
tCycle
Curr (x18)
Curr (x36)
Curr (x72)
2.7
3.0
4.4
315
415
460
7.0
7.0
230
325
360
Unit
ns
ns
ns
mA
mA
mA
ns
ns
mA
mA
mA
Pipeline
3-1-1-1
Flow Through
2-1-1-1
Rev: 1.00 1/2011
1/39
© 2011, GSI Technology
Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.

GS832218E-225M Related Products

GS832218E-225M GS832272C-225MT GS832272C-225M GS832236E-225M GS832236E-225MT GS832236B-225M GS832236B-225MT GS832218E-225MT GS832218B-225MT GS832218B-225M
Description Cache SRAM, 2MX18, 7ns, CMOS, PBGA165, 17 X 15 MM, 1 MM PITCH, FPBGA-165 Cache SRAM, 512KX72, 7ns, CMOS, PBGA209, 14 X 22 MM, 1 MM PITCH, BGA-209 Cache SRAM, 512KX72, 7ns, CMOS, PBGA209, 14 X 22 MM, 1 MM PITCH, BGA-209 Cache SRAM, 1MX36, 7ns, CMOS, PBGA165, 17 X 15 MM, 1 MM PITCH, FPBGA-165 Cache SRAM, 1MX36, 7ns, CMOS, PBGA165, 17 X 15 MM, 1 MM PITCH, FPBGA-165 Cache SRAM, 1MX36, 7ns, CMOS, PBGA119, 22 X 14 MM, 1.27 MM PITCH, FPBGA-119 Cache SRAM, 1MX36, 7ns, CMOS, PBGA119, 22 X 14 MM, 1.27 MM PITCH, FPBGA-119 Cache SRAM, 2MX18, 7ns, CMOS, PBGA165, 17 X 15 MM, 1 MM PITCH, FPBGA-165 Cache SRAM, 2MX18, 7ns, CMOS, PBGA119, 22 X 14 MM, 1.27 MM PITCH, FPBGA-119 Cache SRAM, 2MX18, 7ns, CMOS, PBGA119, 22 X 14 MM, 1.27 MM PITCH, FPBGA-119
Is it Rohs certified? incompatible incompatible incompatible incompatible incompatible incompatible incompatible incompatible incompatible incompatible
Parts packaging code BGA BGA BGA BGA BGA BGA BGA BGA BGA BGA
package instruction LBGA, BGA165,11X15,40 LBGA, BGA209,11X19,40 LBGA, BGA209,11X19,40 LBGA, BGA165,11X15,40 LBGA, BGA165,11X15,40 BGA, BGA119,7X17,50 BGA, BGA119,7X17,50 LBGA, BGA165,11X15,40 BGA, BGA119,7X17,50 BGA, BGA119,7X17,50
Contacts 165 209 209 165 165 119 119 165 119 119
Reach Compliance Code unknown compliant compliant unknown unknown unknown unknown unknown unknown unknown
ECCN code 3A991.B.2.B 3A991.B.2.B 3A991.B.2.B 3A991.B.2.B 3A991.B.2.B 3A991.B.2.B 3A991.B.2.B 3A991.B.2.B 3A991.B.2.B 3A991.B.2.B
Maximum access time 7 ns 7 ns 7 ns 7 ns 7 ns 7 ns 7 ns 7 ns 7 ns 7 ns
Other features FLOW-THROUGH OR PIPELINED ARCHITECTURE, IT ALSO OPERATES AT AS 3.3V SUPPLY FLOW-THROUGH OR PIPELINED ARCHITECTURE, IT ALSO OPERATES AT AS 3.3V SUPPLY FLOW-THROUGH OR PIPELINED ARCHITECTURE, IT ALSO OPERATES AT AS 3.3V SUPPLY FLOW-THROUGH OR PIPELINED ARCHITECTURE, IT ALSO OPERATES AT AS 3.3V SUPPLY FLOW-THROUGH OR PIPELINED ARCHITECTURE, IT ALSO OPERATES AT AS 3.3V SUPPLY FLOW-THROUGH OR PIPELINED ARCHITECTURE, IT ALSO OPERATES AT AS 3.3V SUPPLY FLOW-THROUGH OR PIPELINED ARCHITECTURE, IT ALSO OPERATES AT AS 3.3V SUPPLY FLOW-THROUGH OR PIPELINED ARCHITECTURE, IT ALSO OPERATES AT AS 3.3V SUPPLY FLOW-THROUGH OR PIPELINED ARCHITECTURE, IT ALSO OPERATES AT AS 3.3V SUPPLY FLOW-THROUGH OR PIPELINED ARCHITECTURE, IT ALSO OPERATES AT AS 3.3V SUPPLY
Maximum clock frequency (fCLK) 225 MHz 225 MHz 225 MHz 225 MHz 225 MHz 225 MHz 225 MHz 225 MHz 225 MHz 225 MHz
I/O type COMMON COMMON COMMON COMMON COMMON COMMON COMMON COMMON COMMON COMMON
JESD-30 code R-PBGA-B165 R-PBGA-B209 R-PBGA-B209 R-PBGA-B165 R-PBGA-B165 R-PBGA-B119 R-PBGA-B119 R-PBGA-B165 R-PBGA-B119 R-PBGA-B119
length 17 mm 22 mm 22 mm 17 mm 17 mm 22 mm 22 mm 17 mm 22 mm 22 mm
memory density 37748736 bit 37748736 bit 37748736 bit 37748736 bit 37748736 bit 37748736 bit 37748736 bit 37748736 bit 37748736 bit 37748736 bit
Memory IC Type CACHE SRAM CACHE SRAM CACHE SRAM CACHE SRAM CACHE SRAM CACHE SRAM CACHE SRAM CACHE SRAM CACHE SRAM CACHE SRAM
memory width 18 72 72 36 36 36 36 18 18 18
Number of functions 1 1 1 1 1 1 1 1 1 1
Number of terminals 165 209 209 165 165 119 119 165 119 119
word count 2097152 words 524288 words 524288 words 1048576 words 1048576 words 1048576 words 1048576 words 2097152 words 2097152 words 2097152 words
character code 2000000 512000 512000 1000000 1000000 1000000 1000000 2000000 2000000 2000000
Operating mode SYNCHRONOUS SYNCHRONOUS SYNCHRONOUS SYNCHRONOUS SYNCHRONOUS SYNCHRONOUS SYNCHRONOUS SYNCHRONOUS SYNCHRONOUS SYNCHRONOUS
Maximum operating temperature 125 °C 125 °C 125 °C 125 °C 125 °C 125 °C 125 °C 125 °C 125 °C 125 °C
Minimum operating temperature -55 °C -55 °C -55 °C -55 °C -55 °C -55 °C -55 °C -55 °C -55 °C -55 °C
organize 2MX18 512KX72 512KX72 1MX36 1MX36 1MX36 1MX36 2MX18 2MX18 2MX18
Output characteristics 3-STATE 3-STATE 3-STATE 3-STATE 3-STATE 3-STATE 3-STATE 3-STATE 3-STATE 3-STATE
Package body material PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY
encapsulated code LBGA LBGA LBGA LBGA LBGA BGA BGA LBGA BGA BGA
Encapsulate equivalent code BGA165,11X15,40 BGA209,11X19,40 BGA209,11X19,40 BGA165,11X15,40 BGA165,11X15,40 BGA119,7X17,50 BGA119,7X17,50 BGA165,11X15,40 BGA119,7X17,50 BGA119,7X17,50
Package shape RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR
Package form GRID ARRAY, LOW PROFILE GRID ARRAY, LOW PROFILE GRID ARRAY, LOW PROFILE GRID ARRAY, LOW PROFILE GRID ARRAY, LOW PROFILE GRID ARRAY GRID ARRAY GRID ARRAY, LOW PROFILE GRID ARRAY GRID ARRAY
Parallel/Serial PARALLEL PARALLEL PARALLEL PARALLEL PARALLEL PARALLEL PARALLEL PARALLEL PARALLEL PARALLEL
power supply 2.5/3.3 V 2.5/3.3 V 2.5/3.3 V 2.5/3.3 V 2.5/3.3 V 2.5/3.3 V 2.5/3.3 V 2.5/3.3 V 2.5/3.3 V 2.5/3.3 V
Certification status Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified
Maximum seat height 1.5 mm 1.7 mm 1.7 mm 1.5 mm 1.5 mm 1.99 mm 1.99 mm 1.5 mm 1.99 mm 1.99 mm
Maximum standby current 0.2 A 0.2 A 0.2 A 0.2 A 0.2 A 0.2 A 0.2 A 0.2 A 0.2 A 0.2 A
Minimum standby current 2.3 V 2.3 V 2.3 V 2.3 V 2.3 V 2.3 V 2.3 V 2.3 V 2.3 V 2.3 V
Maximum slew rate 0.28 mA 0.39 mA 0.39 mA 0.36 mA 0.36 mA 0.36 mA 0.36 mA 0.28 mA 0.28 mA 0.28 mA
Maximum supply voltage (Vsup) 2.7 V 2.7 V 2.7 V 2.7 V 2.7 V 2.7 V 2.7 V 2.7 V 2.7 V 2.7 V
Minimum supply voltage (Vsup) 2.3 V 2.3 V 2.3 V 2.3 V 2.3 V 2.3 V 2.3 V 2.3 V 2.3 V 2.3 V
Nominal supply voltage (Vsup) 2.5 V 2.5 V 2.5 V 2.5 V 2.5 V 2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
surface mount YES YES YES YES YES YES YES YES YES YES
technology CMOS CMOS CMOS CMOS CMOS CMOS CMOS CMOS CMOS CMOS
Temperature level MILITARY MILITARY MILITARY MILITARY MILITARY MILITARY MILITARY MILITARY MILITARY MILITARY
Terminal form BALL BALL BALL BALL BALL BALL BALL BALL BALL BALL
Terminal pitch 1 mm 1 mm 1 mm 1 mm 1 mm 1.27 mm 1.27 mm 1 mm 1.27 mm 1.27 mm
Terminal location BOTTOM BOTTOM BOTTOM BOTTOM BOTTOM BOTTOM BOTTOM BOTTOM BOTTOM BOTTOM
width 15 mm 14 mm 14 mm 15 mm 15 mm 14 mm 14 mm 15 mm 14 mm 14 mm
Maker GSI Technology GSI Technology GSI Technology GSI Technology GSI Technology - - GSI Technology GSI Technology GSI Technology
Base Number Matches - 1 1 1 1 1 1 - - -
