EN15C7D2H-125.000M datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> EN15C7D2H-125.000M

EN15C7D2H-125.000M: DescriptionCRYSTAL OSCILLATOR, CLOCK, 125MHz, HSCL OUTPUT, ROHS COMPLIANT, CERAMIC, SMD, 6 PIN; CategoryPassive components oscillator; File Size126KB，2 Pages; ManufacturerECLIPTEK; Websitehttp://www.ecliptek.com; Environmental Compliance

Download Datasheet Parametric View All

EN15C7D2H-125.000M Overview

CRYSTAL OSCILLATOR, CLOCK, 125MHz, HSCL OUTPUT, ROHS COMPLIANT, CERAMIC, SMD, 6 PIN

EN15C7D2H-125.000M Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ECLIPTEK
Reach Compliance Code	compliant
Other features	TRI-STATE; ENABLE/DISABLE FUNCTION; COMPLEMENTARY OUTPUT; BULK
maximum descent time	0.7 ns
Frequency Adjustment - Mechanical	NO
frequency stability	50%
JESD-609 code	e4
Manufacturer's serial number	EN15C7
Installation features	SURFACE MOUNT
Nominal operating frequency	125 MHz
Maximum operating temperature	70 °C
Minimum operating temperature
Oscillator type	HCSL
Output load	50 OHM
physical size	7.0mm x 5.0mm x 2.0mm
longest rise time	0.7 ns
Maximum supply voltage	2.625 V
Minimum supply voltage	2.375 V
Nominal supply voltage	2.5 V
surface mount	YES
maximum symmetry	55/45 %
Terminal surface	Gold (Au) - with Nickel (Ni) barrier

Preview

Download Datasheet

View All

EN15C7

Series

• Crystal Clock Oscillators

• HCSL Output

• +2.5V Supply Voltage

• Complementary Output

• Tri-State Output Function

• 6 Pad Ceramic SMD Package

• Low Stand-by Current

• RoHS Compliant (Pb-Free)

ELECTRICAL SPECIFICATIONS

Nominal Frequency (MHz)

Operating Temperature Range

Storage Temperature Range

Supply Voltage (V

)

Input Current

Frequency Tolerance / Stability

EN15C7

2.0

7.0

5.0

OSCILLATOR

Without Load

Inclusive of All Conditions: Calibration Tolerance at 25°C,

Frequency Stability over the Operating Temperature Range,

Supply Voltage Change, Output Load Change, 1st Year

Aging at 25°C, Shock, and Vibration

Output Voltage Logic High (V

)

Output Voltage Logic Low (V

)

Rise Time / Fall Time

Duty Cycle

Load Drive Capability

Logic Control / Additional Output

Tri-State Input Voltage

at 0.175V

to 0.525V

of waveform

at the crossing point

Output and Complementary Output

of 70% of V

Minimum

No Connection

of 30% of V

Maximum

Without Load

at 100.000MHz (Fj = 12kHz to 20MHz)

at 125.000MHz (Fj = 12kHz to 20MHz)

Deterministic

Random

One Sigma

Cycle to Cycle

pk-pk

Fo=100.000MHz

Standby Current

Start Up Time

RMS Phase Jitter

Period Jitter

Typical Phase Noise

100.000MHz, 125.000MHz

0°C to +70°C, or -40°C to +85°C

-55°C to +125°C

2.5V

±5%

35mA Typical, 60mA Maximum

±100ppm Maximum

±50ppm Maximum

±25ppm Maximum

±20ppm Maximum

650mV

Typical, 600mV

Minimum

20mV

Typical, 50mV

Maximum

300pSec Typical, 700pSec Maximum

50 ±5(%)

50 Ohms to Ground

Tri-State and Complementary Output

Enables Output

Disables Output: High Impedance

10µA Maximum

5mSeconds Maximum

0.5pSec Typical, 0.6pSec Maximum

0.4pSec Typical, 0.5pSec Maximum

0.2pSec Typical

1.0pSec Typical

1.5pSec Typical

10pSec Typical

12pSec Typical

-78dBc/Hz at 10Hz Offset

-113dBc/Hz at 100Hz Offset

-126dBc/Hz at 1kHz Offset

-134dBc/Hz at 10kHz Offset

-140dBc/Hz at 100kHz Offset

-146dBc/Hz at 1MHz Offset

-148dBc/Hz at 10MHz Offset

-152dBc/Hz at 20MHz Offset

CLASS

REV

DATE

MANUFACTURER
