REVISION CA
C
L
CLH-1XX-XX-X-XX-X-XX
No OF POSITIONS
-02 THRU -51
PLATING SPEC
-L: 10µ" LIGHT SELECTIVE GOLD ON
CONTACT AREA, MATTE TIN ON TAIL
-F: 3µ" FLASH SELECTIVE GOLD IN CONTACT
AREA MATTE TIN ON TAIL
-H: 30µ" HEAVY GOLD IN CONTACT AREA
3µ" GOLD ON TAIL
(ONLY OFFERED ON DV, PE & BE)
-G: 10µ" GOLD IN CONTACT AREA
3µ" GOLD ON TAIL
(NOT AVAILABLE WITH -PE & -TE)
-LM: 10µ" LIGHT SELECTIVE GOLD IN CONTACT AREA
MATTE TIN ON TAIL
-FM: 3µ" FLASH SELECTIVE GOLD
MATTE TIN ON TAIL
OPTION
-TR: TAPE & REEL (29 POSITION MAX)
OPTION
-P: PICK & PLACE PAD (SEE FIGURE 5)
AVAILABLE ON POSITIONS 03 THRU 50 ONLY
-A: ALIGNMENT PIN (N/A ON -PE & -TE, SEE FIG 6 & 7 SHT 2) (-4 POS MIN)
-LC: LOCKING CLIP (N/A ON -TE, SEE FIG 6 & 7 SHT 2)
-K: POLYIMIDE FILM PAD (AVAILABLE ON POS 03 THRU 50 ONLY)
(SEE FIG 8, SHT 2) (USE K-DOT-.256-.375-.005)
(AVAILABLE FOR ENTRY STYLE-DV AND -BE ONLY )
ENTRY STYLE
-DV: SURFACE MOUNT (SEE TABLE 1 & FIG 1)
* -TE: TOP ENTRY (SEE TABLE 1 & FIG 2)
-PE: PASS-THROUGH ENTRY (SEE TABLE 1 & FIG 3)
-BE: BOTTOM MOUNT ENTRY (SEE TABLE 1 & FIG 4)
-BE TOP VIEW
C
DO NOT
SCALE FROM
THIS PRINT
(No OF POS x .100[2.54]) +.008[.20]/-.005[.13]
(SEE NOTE 7 & 8)
(No OF POS x .100 [2.54]) - .100 [2.54]
C
L
02
BODY SPECIFICATION
-D: DOUBLE ROW
(SEE TABLE 1)
(* = AVAILABLE TO EXISTING CUSTOMERS ONLY)
.200 5.08 REF
.100 2.54 REF
.020 0.51
REF
C
L
03
2 MAX SWAY
(EITHER DIRECTION)
01
C
L
.144±.005 3.66±0.127
C
(SEE NOTE 10)
C
L
SEE TABLE 1
+4°
C
SEE TABLE 1
C
L
.140 3.56 REF
SEE NOTE 5
+3
.28 7.1
-3
C
90°
- 2°
.120 3.05
.2750 6.985
REF
+.015
+0.381
FIG 1
(-DV: SURFACE MOUNT)
C
L
SEE TABLE 1
C
.004 0.10 REF
C
FIG 2
(-TE: TOP ENTRY)
FIGURE 5
(-P: PICK & PLACE PAD)
.280 7.11
SEE NOTE 5
C
.100
- .005
2.54
- 0.127
IN PROCESS
C
L
"Q" = (# OF POS x .100) .005
"P" = ("Q" - .225/2) .020
"P"
"Q"
.225 5.71
C
L
.144±.005 3.66±0.127
(SEE NOTE 10)
MUST USE
C
L
CLH-XX-DBE
SEE TABLE 1
+3
.28 7.1
-3
C
+5°
90°
- 3°
+.015
.300
- .010
C
.090 2.3
.1950 4.953
REF
C
+0.38
7.6
- 0.25
IN PROCESS
.152 3.86
C
FIG 3
(-PE: PASS-THROUGH ENTRY)
AVAILABLE ON POSITIONS 03 THRU 50 ONLY
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
LMP-02
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
FIG 4
(-BE: BOTTOM MOUNT ENTRY)
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. PUSHOUT FORCE TO BE: 1 lb. MIN.
3. [ ] DIMENSIONS ARE IN MILLIMETERS.
4. PARTS TO BE SYMMETRICAL ABOUT C .
L
5. FOR POSITIONS -02 THRU -40, COPLANARITY TO BE .004; FOR
POSITIONS -41 THRU -51, COPLANARITY TO BE .006.
6. TUBE POSITIONS 03 THRU 51; LAYER PACKAGE POSITION 02. (-PE CAN BE TUBED 02 THRU 51)
7. WILL LOSE A POSITION FOR EVERY CUT MADE ON A SOCKET STRIP;
CUT FLASH TO BE .010 [0.25] MAX WITH NO FLASH ALLOWED IN HOLES OR EXTENDING BELOW LEADS.
8. ENDWALL AFTER CUTTING: .0255 .003
9. MAX BURR: .003
10. DIMENSION TO BE MEASURED FROM BEND RADIUS.
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
BODY: PTFELCP, UL 94 VO, COLOR: BLACK
CONTACT: 521 PHOSPHOR BRONZE FULL HARD
F:\DWG\MISC\MKTG\CLH-1XX-XX-X-XX-X-XX-MKT.SLDDRW
SMA RIGHT ANGLE, JACK, 50 OHM
CLH-1XX-XX-X-XX-X-XX
9/10/2010
SHEET
1
OF
2
BY:
ALVIN W
REVISION CA
.140 3.56
REF
PT-1-24-03-16
PACKAGE AS SHOWN
(SEE NOTE 6)
PT-1-24-01-55
PT-1-24-03-38
C
L
SEE TABLE 1
(SHEET 1)
C
L
C
L
PT-1-24-11-09
C
.050 1.27
.0620 1.575 REF
SM-A10H
(2 REQ'D)
.055±.005 1.40±0.13
LC-08-TM-01
C
PT-1-24-11-63
PT-1-24-10-63
-A OPTION
4 POS MIN
-LC OPTION
2 POS MIN
PT-1-24-01-29
STYLE
TABLE 2
PKG TUBE
PT-1-24-10-63
PT-1-24-03-16
PT-1-24-10-63
PT-1-24-01-55
PT-1-24-03-38
PT-1-24-11-09
PT-1-24-01-29
PT-1-24-11-63
PLUG
TP-24
TP-24
TP-24
TP-24
TP-03
TP-09
TP-03
TP-09
No OF POS x .1000[2.540]-.2000[5.080]
FIG 6
(-DV-A & -LC: SURFACE MOUNT WITH ALIGNMENT PIN OR LOCKING CLIP OPTION)
[DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1]
C
L
.140 3.56
REF
SEE TABLE 1
C
-DV -A, -BE -A, -DV -LC, -BE -LC
-DV, -BE
-BE-P
-PE
-PE-P
-TE
-TE-P
-DV-P, -DV-P-A, -BE-P-A,
-DV-P-LC, -BE-P-LC, -DV-K, -DV-K-LC,
-BE-K, DV-A-K, BE-K-LC, -BE-A-K
C
"R"
(SEE NOTE)
C
L
NOTE: "R" = USE MEASURED DIMENSION (REF)
"S" = {("R" - .2559 [6.500])/2} .020 [.51]
.028±.010 0.71±0.25
"S"
(SEE NOTE)
2 MAX SWAY
(ANY DIRECTION)
C
L
LC-08-TM-01
C
.055±.005 1.40±0.13
-LC OPTION
2 POS MIN
C
.2559±.0050 6.500±0.127
.149 3.78
FIG 8
-K: POLYIMIDE FILM PAD
AVAILABLE ON POS 03 THRU 50 ONLY.
PROPRIETARY NOTE
C
No OF POS x .1000[2.540]-.2000[5.080]
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
FIG 7
(-PE -LC: DUAL ENTRY WITH LOCKING CLIP OPTION)
[DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 3]
F:\DWG\MISC\MKTG\CLH-1XX-XX-X-XX-X-XX-MKT.SLDDRW
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
SMA RIGHT ANGLE, JACK, 50 OHM
CLH-1XX-XX-X-XX-X-XX
9/10/2010
SHEET
2
OF
2
BY:
ALVIN W
