PART NUMBER
FTH-24-01
FTH-24-1-01
Diameter A
Ø0.21(Ø5.3) FOR #10 SCREW
Ø0.25(Ø6.4 )
FOR M6 AND 1/4" SCREW
1.09
27.7
0.48
12.2
0.74 ±0.018
18.7 ±0.5
A
0.18
4.6
0.20 TYP
5.1
0.200 ±0.016 TYP
5.1 ±0.4
+0.031
4.582 - 0.015
+0.8
116.4 - 0.4
0.15 TYP
3.8
3
2 16 "
55.6
0.73
18.5
11
1 32 "
34.1
5
32 "
4.0
63
64 "
25.0
NOTE:
1.Material:NYLON 6/6 (RMS-01);
2.COLOR:NATURAL;
3.ALL MOUNTING SLOTS ACCOMMODATES WIT-18
THRU WIT-60, AND QTE-18 THRU QTE-50 TIES.
H
G
---
R
E
SEE CO 220014
FOR CHANGES
SEE CO 220002
FOR CHANGES
M.C
14/11/08
M.C
28/05/08
---
ENGR.
DATE
SEE ENGINEEERING
FOR REV A-F
TITLE:
TOLERANCES
UNLESS NOTED
.XX=±.010
.XXX=±.005
FRAC.=±1/64
ANG.=±1°
FLAT TIE HOLDER
FILE #: FTH-24
MAT'L: SEE NOTES
RE:
DWN: P.B
DT: 05-25-95
APP:
CHKD: W.H
V.
DESCRIPTION
DWG IN
IN [MM]
FINAL
PART #
RICHCO
RICHCO, XIAMEN
RICHCO_XIAMEN@RICHCO.CN
SEE TABLE
(+86) 0592-4884500
CA
PRINT
TYPE
