Molded Wirewound Inductors
(NL Series)
Features:
•
•
•
•
•
•
•
•
RoHS Compliant and Halogen Free
Molded, heat resistant, resin package
Unified automatic chip mounting shape with no directionality
Excellent solderability for flow or reflow soldering
Resistant to mechanical shocks and pressure
Super Q characteristics
Inductance Range: 0.1uH to 1000uH
Ferrite core
Part Number Structure
NL
Series
252018 - 1R0
Size
252018
322522
453232
Inductance
Value
J
Tolerance
T
Packaging
T = Tape & Reel
J = ±5%
R12 = 0.12μH K = ±10%
1R0 = 1μH
M = ±20%
820 = 82μH
Example P/N:
NL252018-1R0JT
NOTE:
Topside marking available for 3225-22 and 4532-32 sizes only.
Standard temination finish is 100% matte Tin (Sn) over Nickel.
Dimensions
SIZE
470J
252018
(1008)
W
322522
(1210)
0.5
T
453232
(1812)
4.5 ± 0.3
3.2 ± 0.2
3.2 ± 0.2
1.2
3.2 ± 0.4
2.5 ± 0.2
2.2 ± 0.2
1.0 ± 0.2
Unit: mm (inches)
L
2.5 ± 0.2
W
2.0 ± 0.2
T
1.8 ± 0.1
a
1.4 ± 0.1
C
0.4
L
0.6 + 0.3, -0
Terminal
electrode
a
C
1
Operating / Storage Temperature Range
Storage Temperature Range
Operating Temperature Range*
(including Self-Temperature Rise)
Temperature Rise
(against Ambient Temperature)
Ambient Temperature
Terminal Tensile Strength
Current Rating
Resistance to Soldering Heat
Resistance to Solvent
-40 to 100° C
-20 to 100° C
20° C max.
80° C max.
0.5kg min.
Value obtained when current flows and the temperature has risen to 20° C
or when DC current flows and the initial value of inductance has fallen by 10%,
whichever is smaller.
260° C, 10 seconds
Conforms to MIL-STD-202E
* Should be used at a stabilized operating temperature.
118
Email:
sales@venkel.com
|
Phone:
512.794.0081
|
Toll Free:
800.950.8365
|
Web:
www.venkel.com
Rev. 04/2014-C
