G8XB05 THRU G8XB100
SINGLE PHASE GLASS
PASSIVATED BRIDGE RECTIFIER
Voltage: 50
to 1000V
Current: 8.0A
Features
Glass passivated chip junction
Ideal for printed circuit board
High surge current capability
High case dielectric strength
GSIB-3S
Mechanical Data
Terminal: Plated leads solderable per MIL-STD 202E,
Method 208C
Case: UL-94 Class V-0 recognized Flame Retardant Epoxy
Polarity: Polarity symbol marked on body
Mounting position: any
Dimensions in millimeters
MAXIMUM
RATINGS AND ELECTRICAL
CHARACTERISTICS
(single-phase, half -wave, 60HZ, resistive or inductive load rating at 25°C, unless otherwise stated)
G8XB
05
50
35
50
G8XB
10
100
70
100
G8XB
20
200
140
200
G8XB
40
400
280
400
8.0
150
1.0
120
10.0
200
22.0
4.2
-55 to +150
G8XB
60
600
420
600
G8XB
80
800
560
800
G8XB
100
1000
700
1000
Symbol
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward Rectified output current
at Tc = 100℃(Note 1)
Peak forward surge current single sine-wave
superimposed on rated load (JEDEC Method)
Maximum instantaneous forward voltage drop per
leg at 4.0A
Rating for fusing (t < 8.3ms)
Maximum DC reverse current at
rated DC blocking voltage per leg
Maximum thermal resistance per leg
Ta = 25°
C
Ta = 125°
C
(Note2)
(Note1)
Vrrm
Vrms
Vdc
If(av)
Ifsm
Vf
I
2
t
Ir
Rth(ja)
Rth(jc)
Tj, Tstg
units
V
V
V
A
A
V
A
2
Sec
µA
℃/W
℃
Operating junction and storage temperature range
Note:
1. Unit case mounted onAl plate heatsink
2. Unit case mounted on P.C.B. with 0.5 x 0.5” (12 x 12mm) copper peads and 0.375”(9.5mm) lead length
3. Recommended mounting position is to bolt down on heatsink with silicone thermal compound for maximum heat transfer with #6 screw
