HIGH-PERFORMANCE COMMUNICATION IF AMPLIFIER
HIA SERIES
MODEL
NUMBER *
HIA-2-50-15-I/O
HIA-2-50-20-I/O
HIA-2-50-30-I/O
HIA-50-90-10-I/O
HIA-50-90-20-I/O
HIA-50-90-30-I/O
HIA-100-180-10-I/O
HIA-100-180-20-I/O
HIA-100-180-30-I/O
HIA-2-200-30-I/O
HIA-2-200-38-I/O
HIA-10-400-30-I/O
HIA-10-400-38-I/O
HIA-20-1000-32-I/O
HIA-20-1000-40-I/O
HIA-50-1500-32-I/O
HIA-50-1500-40-I/O
HIA-100-2000-32-I/O
HIA-100-2000-40-I/O
FREQUENCY
(MHz)
2 – 50
2 – 50
2 – 50
50 – 90
50 – 90
50 – 90
100 – 180
100 – 180
100 – 180
2 – 200
2 – 200
10 – 400
10 – 400
20 – 1000
20 – 1000
50 – 1500
50 – 1500
100 – 2000
100 – 2000
GAIN
(±0.5)
(dB, Min.)
15
20
30
10
20
30
10
20
30
30
38
30
38
32
40
32
40
32
40
GAIN
VARIATION
(±dB, P-P)
0.1
0.1
0.15
0.05
0.1
0.15
0.2
0.2
0.25
0.25
0.25
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
GROUP DELAY
VARIATION
(ns, Max.)
1
1
1
0.25
0.5
0.5
1
1
1
**
**
**
**
1
1
1
1
1
1
VSWR
(Max.)
1.2:1
1.2:1
1.2:1
1.25:1
1.25:1
1.25:1
1.3:1
1.3:1
1.3:1
1.8:1
1.8:1
1.8:1
1.8:1
2:1
2:1
2:1
2:1
2:1
2:1
NOISE
FIGURE
(dB, Max.)
-
-
-
-
-
-
-
-
2
2
2.2
2.2
2.4
2.4
2.6
2.6
3.2
3.2
1 dB
COMP.
(dB, Min.)
12
12
15
12
12
15
12
12
15
10
16
10
16
10
16
10
16
10
16
DC POWER
SUPPLY
(volts/mA)
15 / 40
15 / 60
15 / 85
15 / 45
15 / 60
15 / 90
15 / 50
15 / 70
15 / 95
12 / 45
12 / 115
12 / 45
12 / 115
12 / 95
12 / 95
12 / 95
12 / 95
12 / 95
12 / 95
* I = Input impedance; O = Output impedance.
For impedance of 75 ohms, I or O = 7; for impedance of 50 ohms, I or O = 5.
** 2 to 20 MHz > 2 ns.
MECHANICAL SPECIFICATIONS
PHYSICAL
Dimensions .......................................................... 1.3” x 7” x 1.5”
CONNECTORS
Input/output.......................................................... SMA or BNC female available, models up to 200 MHz,
SMA above 200 MHz.
DC power............................................................. Feedthru terminal
Housing ground ................................................... 2-56 terminal
OPTIONS
HIA-1
Slope adjustment of ±0.2 dB minimum, if required, for compensating intra-system modules or system
interconnections (models up to 180 MHz).
