DTC114TUA
Features
•
Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
and MSL Rating 1
Built-in bias resistors enable the configuration of an inverter circuit
without connecting external input resistors (see equivalent circuit)
The bias resistors consist of thin-film resistors with complete
isolation to allow negative biasing of the input. They also have the
advantage of almost completely eliminating parasitic effects
Only the on/off conditions need to be set for operation, making
device design easy
NPN Digital Transistor
SOT-323
A
D
3
Absolute Maximum Ratings
Parameter
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base voltage
Collector Current-Continuous
Collector Dissipation
Junction Temperature
Storage Temperature Range
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
C
T
J
T
STG
Value
50
50
5
100
200
150
-55~150
Unit
V
V
V
mA
mW
G
1
F
E
2
B
C
1: Base
2: Emitter
3: Collector
H
J
K
DIMENSIONS
Electrical Characteristics
Sym
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
I
CBO
I
EBO
h
FE
V
CE(sat)
R
1
f
T
Parameter
Collector-Base Breakdown Voltage
(I
C
=50uA, I
E
=0)
Collector-Emitter Breakdown Voltage
(I
C
=1mA, I
B
=0)
Emitter-Base Breakdown Voltage
(I
E
=50uA, I
C
=0)
Collector Cut-off Current
(V
CB
=50V, I
E
=0)
Emitter Cut-off Current
(V
EB
=4V, I
C
=0)
DC Current Gain
(V
CE
=5V, I
C
=1mA)
Collector-Emitter Saturation Voltage
(I
C
=10mA, I
B
=1mA)
Input Resistor
Transition Frequency
(V
CE
=10V, I
C
=-5mA, f=100MHz)
Min
50
50
5
---
---
100
---
7
---
Typ
---
---
---
---
---
300
---
10
250
Max
---
---
---
0.5
0.5
600
0.3
13
---
Unit
V
V
V
uA
uA
---
V
K
MHz
DIM
A
B
C
D
E
F
G
H
J
K
INCHES
MIN
MAX
.071
.087
.045
.053
.079
.087
.026 Nominal
.047
.055
.012
.016
.000
.004
.035
.039
.004
.010
.012
.016
MM
MIN
MAX
1.80
2.20
1.15
1.35
2.00
2.20
0.65Nominal
1.20
1.40
.30
.40
.000
.100
.90
1.00
.100
.250
.30
.40
NOTE
Suggested Solder
Pad Layout
0.70
0.90
1.90
*Marking: 04
0.65
0.65
www.mccsemi.com
Revision: 3
1 of
3
