The REM6 series of medical grade regulated DC/DC converters feature reinforced 5kVAC/1 minute
isolation with low 2µA leakage and are 60601-1 3rd Ed. certified for 250VAC continuous working. The
compact DIP24 package offers tightly regulated single and dual outputs, even under no-load conditions.
The outputs are short circuit and overload protected. The converters are available in two different pin-
ning options and optionally with an external control pin for standby consumption as low as 12.5mW. The
converters are fully certified to CB, IEC/EN and ANSI/AAMI standards and carry the CE and UL marks.
wa
rranty
Selection Guide
Part
Number
REM6-xx3.3S/*
REM6-xx05S/*
REM6-xx12S/*
REM6-xx15S/*
REM6-xx24S/*
REM6-xxx05D/*
REM6-xx12D/*
REM6-xx15D/*
REM6-xx3.3SW/*
REM6-xx05SW/*
REM6-xx12SW/*
REM6-xx15SW/*
REM6-xx24SW/*
REM6-xx05DW/*
REM6-xx12DW/*
REM6-xx15DW/*
Input
Voltage Range
(VDC)
4.5-9 / 9-18 / 18-36 / 36-75
4.5-9 / 9-18 / 18-36 / 36-75
4.5-9 / 9-18 / 18-36 / 36-75
4.5-9 / 9-18 / 18-36 / 36-75
4.5-9 / 9-18 / 18-36 / 36-75
4.5-9 / 9-18 / 18-36 / 36-75
4.5-9 / 9-18 / 18-36 / 36-75
4.5-9 / 9-18 / 18-36 / 36-75
9-36 / 18-75
9-36 / 18-75
9-36 / 18-75
9-36 / 18-75
9-36 / 18-75
9-36 / 18-75
9-36 / 18-75
9-36 / 18-75
Output
Voltage
(VDC)
3.3
5
12
15
24
±5
±12
±15
3.3
5
12
15
24
±5
±12
±15
Output
Current
(mA)
1800
1200
500
400
250
±600
±250
±200
1800
1200
500
400
250
±600
±250
±200
Efficiency
typ.
(%)
86 / 86 / 86 / 86.5
86 / 89 / 89 / 88
87.5 / 88.5 / 88.5 / 88.5
87 / 88.5 / 88.5 / 88
84 / 85 / 85 / 85
86.5 / 89 / 88.5 / 88
87.5 / 88 / 88.5 / 87
83 / 82.5
86 / 86.5
89 / 88
89 / 88.5
88.5 / 88
85 / 85
88.5 / 88
88.5 / 87
Max. Capacitive
Load
(µF)
2100
1500
260
210
75
±860
±150
±110
2100
1500
260
210
75
±860
±150
±110
81.5 / 83.5 / 83 / 82.5
E224736
2MOPP
250VAC
Model Numbering
REM 6- __ __ __ __ / __ __
Output Power
Input Voltage
(1)
Output Voltage
Single
or
Dual
Notes:
Note1: for 4:1 Input Voltage Type add “W”, see Note 2.
2:1
4:1 “W”
xx= 4.5-9 Vin = “05”
xx= 9-36Vin =
xx= 9-18Vin
= “12”
xx= 18-75Vin =
xx= 18-36Vin = “24”
xx= 36-75Vin = “48”
CTRL Option
(4)
Pinning
(3)
Input Type
(2)
UL-60950-1 (Pending)
EN-55011 (Pending)
EN-55022 (Pending)
EN-60601-1 Certified
IEC-60950-1 (Pending)
IEC-60601-1 Certified
ES-60601-1 Certifed
“24”
“48”
Note2: Blank for Standard 2:1 Input Voltage Range; „W“ suffix for 4:1 Input Voltage Range
Note3: „A“ suffix for A pinning; „C“ suffix for C pinning, for more details refer to Package Style and Pinning
Note4: „CTRL“ suffix for control pin option, for A pinning only, for C pinning not aviable
Examples:
REM6-0512D/A
REM6-1215S/C
REM6-4815SW/A/CTRL
REM6 -243.3SW/C
=
=
=
=
2:1 Input,
2:1 Input,
4:1 Input,
4:1 Input,
4.5-9Vin,
9-18Vin,
36-75Vin,
9-36Vin,
±12Vout,
15Vout,
15Vout,
3.3Vout,
pinout „A“,
pinout „C“,
pinout „A“
pinout „C“,
without control pin
without control pin
with control pin
without control pin
Refer to Applications Notes
MED-1
www.recom-international.com
REV.: 0/2015
REM6
DC/DC Converter
Specifications
(measured at TA= 25°C, nominal input voltage, full load and after warm-up)
BASIC CHARACTERISTICS
Parameter
2:1
Absolute Maximum Input Voltage
( 3sec max.)
4:1
2:1
Under Voltage Lockout
4:1
Start-up Time
Remote ON/OFF
(referenced to -Vin Pin)
Current of CTRL Pin
Remote OFF Input Current
Operating Frequency
Output Ripple and Noise
(20MHz BW limited)
10µF/25V 7XR MLCC for 3.3, 5Vout
12, 15Vout
4.7µF/50V X7R MLCC for 24Vout
225kHz
Series
Condition
5Vin nom.
12Vin nom.
24Vin nom.
48Vin nom.
24Vin nom.
48Vin nom
5Vin nom.
12Vin nom.
24Vin nom.
48Vin nom.
24Vin nom.
48Vin nom
DC-DC ON
DC-DC OFF
-0.5mA
2.5mA
250kHz
30mVp-p
40mVp-p
50mVp-p
275kHz
4VDC
8VDC
16VDC
33VDC
8VDC
16VDC
30ms
Open or 0-1.2VDC
2.2-12VDC
1mA
Min.
Typ.
Max.
16VDC
25VDC
50VDC
100VDC
50VDC
100VDC
4.5VDC
9VDC
18VDC
36VDC
9VDC
18VDC
constant resistive load, Power up or Remote ON/OFF
Efficiency
Table1: Efficiency Crosstable
Graph1: Efficiency Factor vs. Load
Efficiency Crosstable (%) @ full load
Input Voltage
1.2
1.0
Efficiency Factor
5
3.3S
05S
Output Voltage
12S
15S
24S
05D
12D
15D
81.5
86
86
87.5
87
84
86.5
87.5
12
83.5
86
89
88.5
88.5
85
89
88
24
83
86
89
89
88.5
85
88.5
88.5
48
82.5
86.5
88
88.5
88
85
88
87
24W
83
86
89
89
88.5
85
88.5
88.5
48W
82.5
86.5
88
88.5
88
85
88
87
0.8
0.6
0.4
0.2
0.0
0
10
20
30
40
50
60
70
80
90 100
Load (%)
continued on next page
MED-2
REV.: 0/2015
www.recom-international.com
REM6
DC/DC Converter
Specifications
(measured at TA= 25°C, nominal input voltage, full load and after warm-up)
Calculation Example:
Efficiency (%)
100
90
Series
choose your model:
80
REM6-1212D
70
• Efficiency from Table1 (= 89% @ max Load / nom Vin)
60
50
• Loading conditions in application (e.g. 50%)
10 20 30 40 50 60 70 80
• use Eff factor from Graph1 (= 0.96 @50%)
Load (%)
Calculation:
Eff
50%
= Eff
100%
* Eff
factor50%
= 89 * 0.960 = 85.44%
Vin = 12V
P
out100%
* 0.5
Iout = 50%
P
DIS50%
= P
in50%
- P
out50%
=
- (P
out100%
* 0.5) = 3.51 - 3
= 0.51W
Eff
50%
Eff
100%
= 89%
Eff
factor50%
= 0.96
T
OVER
=
R
th
* P
DIS50%
= 18 * 0.51 =
9.2°C
R
th
= 18°C/W
T
CASEmax
= 105°C
T
=
T
- T = 105 - 9.2 =
95.8°C
AMBmax
CASEmax
OVER
90 100
REGULATIONS
Parameter
Output Voltage Accuracy
Single
Voltage Adjustability
Dual
Line Voltage Regulation
LL to HL
LL to HL
no load to full load
no load to full load
Single
Dual
Single
Dual
3.3, 5, 12Vout
15, 24Vout
Condition
Type
Value
±1%
±10%
±10% min. / ±20% max.
±10%
±0.2%
±0.5%
±0.2%
±1%
±5%
250µs
Load Voltage Regulation
Cross Regulation
Transient Response
asymmetrical load 25% / Full Load only Dual Output
25% load step change
PROTECTIONS
Parameter
Short Circuit Protection (SCP)
Over Load Protection (OLP)
% of Iout rated
Single
3.3Vout
5Vout
12Vout
15Vout
24Vout
5Vout
12Vout
15Vout
Condition
Type
Value
continuous, auto-recovery
Hiccup mode, 150% typ.
3.7VDC min. / 5VDC max.
5.6VDC / 7VDC max.
13.5VDC min. / 16VDC max.
18.3VDC min. / 22VDC max.
29.1VDC min. / 34.5VDC max.
5.6VDC min. / 7VDC max.
13.5VDC min. / 18.2VDC max.
17VDC min. / 22VDC max.
5kVAC / 1 minute
250VAC / continuous
2µA
8mm
8mm
12pF typ. / 17pF max.
Output Over Voltage Protection (OVP)
Dual
Isolation Voltage
(2MOPP insulation)
Leakage Current
Clearance
Creepage
Isolation Capacitance
www.recom-international.com
I/P to O/P
working voltage
240VAC, 60Hz
I/P to O/P
I/P to O/P
REV.: 0/2015
MED-3
REM6
DC/DC Converter
Specifications
(measured at TA= 25°C, nominal input voltage, full load and after warm-up)
ENVIRONMENTAL
Parameter
Relative Humidity
Temperature Coefficient
Thermal Impedance
max. Case Temperature Range
max. Ambient Temperature Range
Storage Temperature Range
MTBF (+25°C)
according to MIL-HDBK-217F, full load
natural convection (20LFM)
Series
Condition
Value
5% to 95% RH
±0.02% / °C
18°C / W
-40°C to +105°C
see calculation example
-55°C to +125°C
4718 x 10
3
hours
SAFETY AND CERTIFICATIONS
Agency
CB
CB Medical
UL General Safety
ANSI/AAMI
EN General Safety
EN Medical Safety
1409015
E314885-A6
E314885-A6
Report / File Number
Standard
IEC-60950-1
IEC-60601-1
UL-60950-1
ES60601-1
EN-60950-1
EN-60601-1
Certificate Type
ESD
Radiated Immunity
Fast Transient
(1)
Surge
(1)
Conducted Immunity
EMI Standard
(2)
Condition
Air ±8kV; Contact ±6kV
10V/m
±2kV
±2kV
10Vr.m.s
Standard / Criterion
EN61000-4-2, Criteria A
EN61000-4-3, Criteria A
EN61000-4-4, Criteria A
EN61000-4-5, Criteria A
EN61000-4-6, Criteria A
EN55011, Class A, B
EN55022, Class A, B
FCC Part 18
MIL-STD-810F
MIL-STD-810F
Thermal Shock
Vibration
Notes:
Note1:
Note2:
Note3:
An external input filter capacitor is required if the model has to meet EN61000-4-4 or/and EN61000-4-5.
Recommended components:
5Vin
aluminium capacitor (Nippon Chemi-con KY series, 1000µF/25V) and a
reverse diode (Vishay V10P45) to connect in parallel
12Vin, 24Vin
aluminium capacitor (Nippon Chemi-con KY series, 470µF/50V)
48Vin
aluminium capacitor (Nippon Chemi-con KY series, 330µF/100V)
The REM3 (W) with 4:1 input voltage can meet EMI Class A with no external filter. And Class B only with external components.
This Power module is not internally fused. A input line fuse must be always used.
MED-4
REV.: 0/2015
www.recom-international.com
REM6
DC/DC Converter
Specifications
(measured at TA= 25°C, nominal input voltage, full load and after warm-up)
DIMENSIONS and PHYSICAL CHARACTERISTICS
Parameter
Material
Package Dimensions (LxWxH)
Package Weight
Packaging Dimensions (LxWxH)
Packaging Quantity
Tube
Series
Type
Case
Potting
Value
non-conductive black plastic
Silicone (UL94-V0)
31.80 x 20.30 x 10.20mm
14g
225 x 21.80 x 16.50mm
7pcs
Mechanical Dimensions
“C” Pinning
“A” Pinning
(Standard)
MEDICAL GRADE DC/DC CONVERTER
REM6-Series
20.3
MEDICAL GRADE DC/DC CONVERTER
REM6-Series
20.3
31.8
31.8
10.2
3.8
2.54
15.24
2.0
2.54
20.32
2.54
3.8
2.0
15.24
10.2
0.6 dia.
5.08
20.32
0.6 dia.
1
11 12
1 2
11
Bottom View
24 23
15
13
Bottom View
23 22
16 14
Pin Connections
Pin # Single
Dual
1
+Vin
+Vin
11
No Pin
Com
12
-Vout
No Pin
13
+Vout
-Vout
15
No Pin
+Vout
23
-Vin
-Vin
24
-Vin
-Vin
Tolerance: xx.x= ±0.5mm
xx.xx= ± 0.25mm
Pin Connections
Pin # Single
Dual
1
CTRL*
CTRL*
2
-Vin
-Vin
11
No Pin
-Vout
14
+Vout
+Vout
16
-Vout
Com
22
+Vin
+Vin
23
+Vin
+Vin
* If don´t choose CTRL option, there is
no pin on the corresponding pin number
Tolerance: xx.x= ±0.5mm
xx.xx= ± 0.25mm
The product information and specifications are subject to change without prior notice. All products are designed for non-safety critical commercial and industrial applications.
The buyer agrees to implement safeguards that anticipate the consequences of any failures that might cause harm, loss of life and/or property damage.
