OCTAVE AND MULTI-OCTAVE
DETECTORS, VIDEO
0.2-18 GHz
GENERAL INFORMATION
Series PB and PT miniature Detectors achieve the input impedance
match without the use of resistive elements, which assures excellent sen-
sitivity. This unique design also results in low VSWR and low video ripple.
The units are supplied with either Schottky diodes (PT Series) or back
diodes (PB Series).
SERIES PB, PT
GENERAL SPECIFICATIONS
Frequency Range:
RF Impedance:
Burnout Power:
Temperature Information:
Connectors:
0.20 to 18.0 GHz
50 OHMS.
Series PT; 50 mW CW, 5 W Peak
Series PB; 10 mW CW, 1.0 W Peak
Operating temperature from –55°C to
+85C
SMA standard
SMA
MALE
SMA
FEMALE
0.50
[12,7]
SMA
MALE
SMA
FEMALE
0.50
[12,7]
2.38
[60,45]
0.75
[19,1]
1.38
[35,02]
2.25
[57,15]
OUTLINE 1
0.50
[12,7]
3.25
[82,55]
OUTLINE 2
Notes:
1. Models with prefix PB use either zero bias, Schottky (back) diodes and
require no bias. Models with prefix PT use Schottky diodes and require 20
to 60 microamps bias.
2. Diodes are replaceable.
3. All units have DC returns.
4. Output voltages are negative.
5. Fig. 1 shows the relationship of tangential sensitivity versus video band-
width.
6. Fig. 2 illustrates the output voltage versus input power.
ELECTRICAL SPECIFICATIONS
Tangential
Output
Sensitivity
Voltage
Frequency @2 Mhz Video
Flatness vs.
Range
Bandwidth Maximum Frequency Sensitivity
GHz
–dBm
VSWR
dB
mV/mW Outline
0.2–0.4
0.5–1.0
1.0–2.0
1.0–2.0
1.0–2.0
1.5–3.0
2.0–4.0
2.6–5.2
4.0–8.0
4.0–8.0
7.0–12.4
7.0–12.4
8.0–16.0
52
53
52
53
56
52
50
50
50
54
50
54
48
53
48
46
1.75
1.40
1.80
1.50
2.20
1.80
1.80
2.00
2.00
2.50
2.00
2.50
2.50
3.00
2.20
1.60
±0.60
±0.50
±0.60
±0.50
±0.60
±0.60
±0.60
±0.70
±0.80
±0.80
±1.00
±1.00
±1.25
±1.25
±1.25
±2.00
1000
800
800
800
2000
600
600
600
600
1800
400
1700
300
1500
300
300
1
2
1
2
1
1
1
1
1
1
1
1
1
1
1
1
Model
No.
PB-3N
PB-7Q
PB-8N
PB-8Q
PT-22A
PB-27N
PB-34N
PB-45N
PB-48N
PT-49A
PB-54N
PT-56A
PB-58N
OCTAVE MODELS
FIG. 1
1000
FIG. 2
100
50
MODEL PT
OUTPUT VOLTAGE (mV)
TSS (dBm)
10
MODEL PB
1
58
.1
PT-59A 8.0–16.0
PB-62N 12.0–18.0
PB-518
0.5–18.0
.01
2
MULTI-OCTAVE MODEL
4
6
8
VIDEO BW (MHZ)
10
-60
-40
INPUT POWER (dBm)
-20
0
TANGENTIAL SENSITIVITY (TSS)
vs
VIDEO BANDWIDTH
OPEN CIRCUIT OUTPUT VOLTAGE
vs
INPUT POWER
KEY:
Inches[Millimeters] .XX ±.03 .XXX ±.010 [.X ±0.8 .XX ±0.25]
