Control Relays & Timers
Timing Relays
April 2009
3-77
D80 Series — Pneumatic Timers
D80 Series — Pneumatic
Timers
Technical Data and Specifications
Table 3-121. Contact Ratings
AC Pilot Duty — Amperes A600
120V
240V
20.
10.
15.
1.5
480V
10.
6.
8.
1.
600V
8.
5.
6.
0.8
DC Pilot Duty — Amperes B600
120V
—
0.5
—
0.2
240V
—
0.2
—
0.1
600V
—
0.02
—
—
1NO-1NC
Make
Break
40.
15.
30.
3.
2NO-2NC
Make
Break
Product Selection
Catalogue Number
When Ordering Specify
■
Catalogue Number of Timer plus
Suffix Letter for solenoid volts and
hertz.
■
Catalogue Number of Enclosure (if
required).
Table 3-122. Pneumatic Timers
Timed
Contacts
Instantaneous
Contacts
ON Delay — Time Delay After OFF Delay — Time Delay
Energizing Timer Coil.
After De-energizing Timer
Convertible to OFF Delay
Coil. Convertible to ON
Delay
Catalogue
Number
1NO-1NC
Catalogue
Number
D80ND1_
D80JD10_
D80JD11_
D80JD12_
D80ND2_
D80JD20_
D80JD21_
D80JD22_
Catalogue Number
N/A
None
1NO-1NC
2NO-2NC
N/A
NONE
1NO-1NC
2NO-2NC
D80NE1_
D80JE10_
D80JE11_
D80JE12_
D80NE2_
D80JE20_
D80JE21_
D80JE22_
Product Description
Type D80 Timers are supplied only as
complete devices with Switch Block(s)
and Solenoid assembled. The Sole-
noids and Switch Blocks listed in
Tables 3-124
and
3-125
can be used for
replacement or conversion of D80
Timers.
2NO-2NC
Must be ordered with solenoid assembly. Add Suffix letter from table below.
ON or OFF Delay Timers are field convertible from ON to OFF or OFF to ON Delay by rotating the
solenoid assembly 180° — timing function is shown on mounting plate.
These timers will not accept instantaneous contacts.
Table 3-123. Solenoid Suffix Selection Table
Volts/Hertz
Suffix
R
T
A
E
Volts/Hertz
240/60 – 220/50
380/50
480/60 – 440/50
600/60 – 550/50
Suffix
B
L
C
D
12 – 50/60
24 – 50/60
120/60 – 110/50
208 – 220/60
Design Characteristics
■
Adjustable Timing Range:
0.5 to 180 seconds
■
Repeat Accuracy: +10%
■
Minimum Reset Time: 0.05 seconds
Contact Customer Support Centre at 1-800-268-3578 for availability.
3
Catalogue
Number
D80AMB
D80AML
D80AMC
D80AMD
Table 3-124. Solenoids – Can Be Used for Replacement or to Convert Above Items for Different
Volts/Hertz Applications
Volts/Hertz
12 – 50/60
24 – 50/60
120/60 – 110/50
208 – 220/60
Catalogue
Number
D80AMR
D80AMT
D80AMA
D80AME
Price
U.S. $
Volts/Hertz
240/60 – 220/50
380/50
480/60 – 440/50
600/60 – 550/50
Standards and Certifications
■
UL listed — File #E1230, Guide
#NKCR
■
CSA certified
Table 3-125. Switch Blocks – Can Be Used for Either Timed or Instantaneous Contacts
Circuit
SPDT
DPDT
Type of Contacts
1NO-1NC
2NO-2NC
Catalogue
Number
D80AS1
D80AS2
CA08102002K07A
For more information visit:
www.EatonCanada.ca
