LPS6225-472MQB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> LPS6225-472MQB

LPS6225-472MQB: DescriptionGeneral Purpose Inductor, 4.7uH, 20%, 1 Element, Ferrite-Core, SMD, 2424, CHIP, 2424, HALOGEN FREE AND ROHS COMPLIANT; CategoryPassive components inductor; File Size169KB，2 Pages; ManufacturerCOILCRAFT; Websitehttp://www.coilcraft.com/; Environmental Compliance

Download Datasheet Parametric View All

LPS6225-472MQB Overview

General Purpose Inductor, 4.7uH, 20%, 1 Element, Ferrite-Core, SMD, 2424, CHIP, 2424, HALOGEN FREE AND ROHS COMPLIANT

LPS6225-472MQB Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	2424
Reach Compliance Code	compli
ECCN code	EAR99
uppercase and lowercase codes	2424
structure	Shielded
core material	FERRITE
DC Resistance	0.065 Ω
Nominal inductance(L)	4.7 µH
Inductor Applications	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e1
Number of functions	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package height	2.53 mm
Package length	6.13 mm
Package form	SMT
Package width	6.13 mm
method of packing	TR
Maximum rated current	1.3 A
self resonant frequency	53 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	YES
surface mount	YES
Terminal surface	Tin/Silver/Copper (Sn95.5Ag4.0Cu0.5)
Terminal location	DUAL ENDED
Terminal shape	ONE SURFACE
Test frequency	0.1 MHz
Tolerance	20%
Base Number Matches	1

Preview

Download Datasheet

View All

Document 554-1

Shielded Power Inductors – LPS6225

• Low DCR; high current; shielded construction

• Perfect for backlight applications

Designer’s Kit C349

contains 3 each of all values

Core material

Ferrite

Core and winding loss

See www.coilcraft.com/coreloss

Environmental

RoHS compliant, halogen free

Terminations

RoHS compliant matte tin over nickel over silver.

Other terminations available at additional cost.

Weight

309 – 331 mg

Ambient temperature

–40°C to +85°C with

Irms

current, +85°C to

+125°C with derated current

Storage temperature

Component: –40°C to +125°C.

Tape and reel packaging: –40°C to +80°C

Resistance to soldering heat

Max three 40 second reflows at

+260°C, parts cooled to room temperature between cycles

Moisture Sensitivity Level (MSL)

1 (unlimited floor life at <30°C /

85% relative humidity)

Failures in Time (FIT) / Mean Time Between Failures (MTBF)

38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332

Packaging

750/7″ reel; 2500/13″ reel Plastic tape: 12 mm wide,

0.3 mm thick, 8 mm pocket spacing, 2.57 mm pocket depth

Recommended pick and place nozzle

OD: 6.2 mm; ID:

≤

3.1 mm

PCB washing

Tested with pure water or alcohol only. For other solvents,

see

Doc787_PCB_Washing.pdf.

Part number

Isat

(A)

DCR

SRF

Inductance

max

typ

10% 20% 30%

± 20% (µH) (Ohms) (MHz) drop drop drop

1.2

2.2

3.3

4.7

6.8

100

120

150

220

330

470

680

1000

1500

1800

2200

3300

4700

5600

0.040 178

0.045 100

0.055 68

0.065 53

0.095 40

0.105

0.135

0.175

0.260

0.360

0.420

0.610

0.750

0.920

1.30

2.00

2.60

4.00

6.00

9.00

11.7

13.5

21.0

30.0

36.0

43.0

54.0

70.0

9.6

7.7

7.4

6.4

5.0

3.8

3.2

2.8

2.3

1.8

1.7

1.3

1.1

0.90

0.72

5.3

3.9

3.5

3.0

2.6

2.1

1.4

1.1

0.98

0.58

0.48

0.42

0.39

0.32

0.26

0.22

0.18

0.15

0.12

0.11

0.10

0.099

0.086

0.083

5.4

4.0

3.5

3.1

2.7

2.1

2.2

1.5

1.2

1.0

0.61

0.51

0.45

0.41

0.34

0.27

0.23

0.19

0.16

0.13

0.12

0.10

0.096

0.090

5.4

4.1

3.6

3.2

2.8

2.2

1.6

1.2

1.0

0.62

0.52

0.46

0.42

0.35

0.28

0.24

0.20

0.17

0.13

0.12

0.11

0.10

0.096

Irms

(A)

20°C 40°C

rise rise

1.1

1.0

0.90

0.85

0.80

0.65

0.60

0.57

0.47

0.43

0.40

0.37

0.28

0.24

0.18

0.15

0.13

0.11

0.080

0.075

0.070

1.65

1.40

1.35

1.30

1.20

1.10

0.90

0.80

0.74

0.64

0.58

0.54

0.50

0.39

0.37

0.26

0.24

0.20

0.14

0.13

0.11

0.090

1. Please specify

termination

and

packaging

codes:

LPS6225-106MRC

Termination: R

= RoHS compliant matte tin over

nickel over silver.

Special order, added cost:

= RoHS tin-silver-copper (95.5/4/0.5)

= non-RoHS tin-lead (63/37).

Packaging: C

= 7″ machine-ready reel. EIA-481

embossed plastic tape (750 parts

per full reel).

= Less than full reel. In tape, but not

machine ready. To have a leader and

trailer added ($25 charge), use code

letter C instead.

= 13″ machine-ready reel. EIA-481

embossed plastic tape. Factory

order only, not stocked (2500 parts

per full reel).

2. Inductance tested at 100 kHz, 0.1 Vrms, 0 Adc.

3. DCR measured on a micro-ohmmeter.

4. SRF measured using Agilent/HP 8753ES or equivalent.

5. DC current that causes the specified inductance drop

from its value without current.

6. Current that causes the specified temperature rise from

25°C ambient.

7. Electrical specifications at 25°C.

Refer to Doc 362 “Soldering Surface Mount Components”

before soldering.

LPS6225-122MR_

LPS6225-222MR_

LPS6225-332MR_

LPS6225-472MR_

LPS6225-682MR_

LPS6225-103MR_

LPS6225-153MR_

LPS6225-223MR_

LPS6225-333MR_

LPS6225-473MR_

LPS6225-683MR_

LPS6225-104MR_

LPS6225-124MR_

LPS6225-154MR_

LPS6225-224MR_

LPS6225-334MR_

LPS6225-474MR_

LPS6225-684MR_

LPS6225-105MR_

LPS6225-155MR_

LPS6225-185MR_

LPS6225-225MR_

LPS6225-335MR_

LPS6225-475MR_

LPS6225-565MR_

LPS6225-685MR_ 6800

LPS6225-825MR_ 8200

LPS6225-106MR_ 10000

0.70 0.080 0.086 0.089 0.065 0.080

0.69 0.079 0.086 0.088 0.060 0.075

0.68 0.075 0.084 0.087 0.060 0.065

+1-847-639-6400 sales@coilcraft.com

+44-1236-730595 sales@coilcraft-europe.com

Taiwan

+886-2-2264 3646 sales@coilcraft.com.tw

China

+86-21-6218 8074 sales@coilcraft.com.cn

Singapore

+ 65-6484 8412 sales@coilcraft.com.sg

Document 554-1

Revised 08/01/13

This product may not be used in medical or high

risk applications without prior Coilcraft approval.

Specification subject to change without notice.

Please check web site for latest information.
