LLNRK/LLSRK Series POWR-PRO
®
Class RK1 Fuses
250/600 VAC • Dual-Element, Time-Delay • 1/10 – 600 Amperes
Littelfuse LLNRK and LLSRK series POWR-PRO fuses provide superior
overload and short-circuit protection for service entrance, main, feeder
and general-purpose branch circuits up to 600 amperes.
LLNRK/LLSRK series fuses can be installed in existing Class H fuse
blocks to upgrade systems containing lower interrupting rating Class H
one-time or renewable fuses.
POWR-PRO
®
Fuses
Applications
All general purpose circuits
Motors
Transformers
Solenoids
Fluorescent lighting
All system components with high in-rush currents
Features/Benefits
• Extremely current-limiting — Reduces damage to circuits and
equipment under short-circuit conditions. Stops damaging short-
circuits faster than any mechanical protective device.
• 300kA Interrupting Rating — Littelfuse self-certified to 300,000
amperes as standard. Meets future trend towards higher available
short-circuit currents.
• Reduced costs — Current-limiting design often permits use of readily
available, less costly equipment. Low resistance design reduces
power consumption and utility bills.
• Excellent time-delay — True dual-element construction, with separate
non-fatiguing thermally-reversible spring-loaded thermal overload
element, withstands repeated surges within rated time delay without
opening needlessly. Eliminates needless downtime caused by power
surges or equipment demands.
Specifications
Voltage Ratings:
AC: 250 Volts (LLNRK)
600 Volts (LLSRK)
DC: 125 Volts (LLNRK)
300 Volts (LLSRK)
AC: 200,000 amperes rms symmetrical
300,000 amperes rms symmetrical
(Littelfuse self-certified)
DC: 20,000 amperes
1/10 – 600 amperes
AC: Standard 248-12, Class RK1
UL Listed (File No: E81895)
CSA Certified (File No: LR29862)
QPL: Federal Specification No. WF-1814
DC: Littelfuse self-certified
Ampere Ratings
⁄
10
1
2
8
⁄
10
6
1
⁄
4
25
80
1
⁄
100
1 ⁄
8
3
7
30
90
2
⁄
10
1
1
⁄
4
3
2
⁄
10
8
35
100
1
4
1
⁄
4
*
1 ⁄
10
3 ⁄
2
9
40
110
3
⁄
10
1
6
⁄
10
4
10
45
125
4
⁄
10
1
8
⁄
10
4
1
⁄
2
12
50
150
1
⁄
2
2
5
15
60
175
6
⁄
10
2
1
⁄
4
5
6
⁄
10
17
1
⁄
2
70
200
8
⁄
10
2
1
⁄
2
6
20
75*
225
* LLSRK Only.
Example part number (series & amperage): LLNRK 450.
For online ordering, use numbers LNRK and LSRK for LLNRK/LLSRK.
1
15
Interrupting Ratings:
250
300
350
400
450
500
600
Ampere Range:
Approvals:
Recommended Fuse Blocks
LR250 series (LLNRK Series)
LR600 series (LLSRK Series)
Refer to the Blocks & Holders section of this catalog for additional information.
