T-1 3/4 (5mm) BI-COLOR RIGHT ANGLE
LED INDICATORS
L-59CB/1 SERIES
Features
PRE-TRIMMED LEADS FOR PC BOARD MOUNTING.
3 LEADS WITH COMMON CATHODE LEAD.
THIRD COLOR (MIXED COLOR) AVAILABLE.
I.C. COMPATIBLE.
BLACK CASE ENHANCES CONTRAST RATIO.
WIDE VIEWING ANGLE.
HIGH RELIABILITY - LIFE MEASURED IN YEARS.
UL RATING : 94V-0.
HOUSING MATERIAL: TYPE 66 NYLON.
Description
The High Efficiency Red source color devices are made
with Gallium Arsenide Phosphide on Gallium Phosphide
Orange Light Emitting Diode.
The Green source color devices are made with Gallium
Phosphide Green Light Emitting Diode.
The Yellow source color devices are made with Gallium
Arsenide Phosphide on Gallium Phosphide Yellow Light
Emitting Diode.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: KDA0370
APPROVED: J.LU
REV NO: V.1
CHECKED:
DATE: SEP/23/2001
DRAWN: Z.W.XIE
PAGE: 1 OF 4
Selection Guide
Par t No .
Dic e
L en s Ty p e
Iv (m c d )
@ 20 m A
Min .
L-59CB/1EGW
HIGH EFFICIENCY RED (GaAsP/GaP)
GREEN (GaP)
HIGH EFFICIENCY RED (GaAsP/GaP)
YELLOW (GaAsP/GaP)
GREEN (GaP)
YELLOW (GaAsP/GaP)
WHITE DIFFUSED
20
20
20
20
20
20
Ty p .
60
50
60
40
50
40
V i ew i n g
An g l e
2θ1/2
60°
L-59CB/1EYW
WHITE DIFFUSED
60°
L-59CB/1GYW
WHITE DIFFUSED
60°
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Electrical / Optical Characteristics at T
)
=25°C
°
Sy m b o l
λ
peak
Par am et er
Peak Wavelength
D ev i c e
High Efficiency Red
Green
Yellow
High Efficiency Red
Green
Yellow
Ty p .
627
565
590
625
568
588
45
30
35
15
15
20
2.0
2.2
2.1
2.5
2.5
2.5
10
Max .
Un it s
nm
Tes t Co n d it io n s
IF=20mA
λ
D
Dominate Wavelength
nm
IF=20mA
∆λ
1/2
High Efficiency Red
Spectral Line Halfwidth Green
Yellow
Capacitance
High Efficiency Red
Green
Yellow
High Efficiency Red
Green
Yellow
All
nm
IF=20mA
C
pF
VF=0V;f=1MHz
V
F
I
R
Forward Voltage
Reverse Current
V
uA
IF=20mA
V R = 5V
Absolute Maximum Ratings at T
)
=25°C
°
Par am et er
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
H i g h E f f i c i e n c y R ed
105
30
160
5
Gr een
105
25
140
5
-40
°
C To +85
°C
260
°
C For 5 Seconds
Yello w
105
30
14 0
5
Un it s
mW
mA
mA
V
SPEC NO: KDA0370
APPROVED: J.LU
REV NO: V.1
CHECKED:
DATE: SEP/23/2001
DRAWN: Z.W.XIE
PAGE: 2 OF 4
