REVISION V
DO NOT
SCALE FROM
THIS PRINT
QTE-XXX-01-XXX-D-DP-EMX-XX
No OF POSITIONS
-014, -028, -042
**-056, **-070
(PER ROW)
**SEE NOTES 12 & 14
C
* = SEE NOTE 11
OPTION
-GP: GUIDE POST
(USE QTE-20-01-D-EMX-XX-GP
(SEE FIG 2, SHEET 2)
EDGE MOUNT THICKNESS
-EM2: .064[1.63] +/-.004 PCB
(USE QTE-20-01-D-EM2-XX & T-1S42-01-XXX)
*-EM3:(USE QTE-20-01-D-EM3-XX &
T-1S42-02-XXX)
(SEE NOTE 11)
* = NOT ENGINEERING
ROW SPECIFICATION
APPROVED
-D: DOUBLE (USE QTE-20-XX-D-EMX-XX)
No OF BANKS
PLATING SPECIFICATION
-F: 3µ" SELECTIVE GOLD IN CONTACT AREA, MATTE TIN
ON TAIL (T-1S42-XX-F & T-1G1-01-F SEE NOTE 6)
-L: 10µ" SELECTIVE GOLD IN CONTACT AREA, MATTE TIN
ON TAILS (USE T-1S42-XX-L & T-1G1-01-L)
-H: 30µ" GOLD IN CONTACT AREA, 3µ" GOLD ON TAIL
(USE T-1S42-XX-H & T-1G1-01-G)
-STL: 30µ" SELECTIVE GOLD IN CONTACT AREA, TIN/LEAD
(90%/10 +/-5%) TAIL (USE T-1S42-XX-STL & T-1G1-01-STL)
-FTL: 3µ" SELECTIVE GOLD IN CONTACT AREA, TIN/LEAD
(90%/10 +/-5%) TAIL (USE T-1S42-XX-FTL & T-1G1-01-FTL)
DIFFERENTIAL PAIR
LEAD STYLE
-01: .1680 [4.267]
({No OF POS / 14} x .7875 [20.003]) + .3900 [9.906] REF
(No OF POS / 14) x .7875 [20.003] REF
.7875 20.003 REF
01
.1550 3.937 REF
02
.2350 5.969
REF
.0400 1.016
.0333 0.845 REF
6 EQ SPACES
@ .0945[2.400]
.160 4.06 REF
.6440 16.358
QTE-20-01-D-EMX-XX
FIG 1
C
"A"
T-1G1-01-XXX
.155±.003 3.94±0.08
C
.1750 4.445
REF
C
.118 3.00
.1680 4.267
(SEE NOTE 7)
.2782 7.067
REF
T-1S42-XX-XXX
C
"A"
"A" REF
.0400 1.016
REF
SEE TABLE 2
.7450 18.923 REF
2 MAX SWAY
(EITHER DIRECTION)
C
C
"C" REF
.1420 3.607 REF
.1275 3.239 REF
.0080 0.203
REF
.0945 2.400 REF .0150 0.381 REF
.0315 0.800 REF
.0300 0.762 REF
"B" .0030
(INSIDE TO INSIDE OF PIN)
SECTION "A"-"A"
.1000 2.540 REF
NOTES:
.1200 3.048 REF
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MAXIMUM BURR ALLOWANCE: .0015 [0.038]
3. MINIMUM TERMINAL RETENTION: 6 OZ.
** = SEE NOTES 12 & 14
4. MINIMUM GROUND PLANE RETENTION: 1 LB.
UNLESS OTHERWISE SPECIFIED,
PROPRIETARY NOTE
5. PARTS TO BE MOLD-TO-POSITION.
DIMENSIONS ARE IN INCHES.
THIS DOCUMENT CONTAINS INFORMATION
6. -L PLATING CAN BE SUBSTITUTED FOR -F PLATING.
CONFIDENTIAL AND PROPRIETARY TO
TOLERANCES ARE:
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
7. MAXIMUM VARIANCE OF .002 [0.05]
DECIMALS
ANGLES
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
8. NOTE DELETED.
.XX: .01 [.3]
2
PURPOSE OTHER THAN THAT WHICH IT WAS
520 PARK EAST BLVD, NEW ALBANY, IN 47150
.XXX: .005 [.13]
9. BOARD THICKNESS TO BE MEASURED FROM SOLDER PAD TO SOLDER PAD.
OBTAINED WITHOUT THE EXPRESSED WRITTEN
PHONE: 812-944-6733
FAX: 812-948-5047
.XXXX: .0020 [.051]
CONSENT OF SAMTEC, INC.
10. Http://www.samtec.com/processing/edgemt_tectalk/index.htm
e-Mail info@SAMTEC.com
code 55322
FOR INFORMATION ON PROCESSING EM PARTS.
SHEET SCALE: 1.5:1
MATERIAL:
DO NOT SCALE DRAWING
DESCRIPTION:
11. -EM3 IS NOT A STANDARD OFFERING; AVAILABLE AS AN ASP ONLY. PLEASE CONTACT SAMTEC
.8mm HS EDGEMOUNT TERMINAL ASSEMBLY
INSULATOR: LCP, COLOR: BLACK
INTERCONNECT PROCESSING GROUP WITH ORDER INQUIRIES
TERMINAL & GROUND PLANE: PHOS BRONZE
12. FOR NEW APPLICATIONS REQUIRING THESE POSITIONS, PLEASE CONTACT
DWG. NO.
SAMTEC INTERCONNECT PROCESSING GROUP.
QTE-XXX-01-XXX-D-DP-EMX-XX
13. PARTS WITHOUT -TY OPTION SHALL BE PACKAGED IN TRAYS.
14. AVAILABLE FOR EXISTING CUSTOMERS ONLY.
SHEET
1
OF
2
12/12/00
BY:
KEVIN B
C:\EnterpriseVault\DWG\MISC\MKTG\QTE-XXX-01-XXX-D-DP-EMX-XX-MKT.SLDDRW
REVISION V
C
({No OF POS / 14} x .7875 [20.003])+ .7875 [20.003] REF
({No OF POS / 14} x .7875 [20.003]) + .2255 [5.728] REF
QTE-20-01-D-EMX-XX-GP
"B"
.125 3.18 REF
.300 7.62 REF
.235 5.96 REF
.040 1.02 REF
"B"
SECTION "B"-"B"
"C"
"C"
FIG 2
-GP OPTION SHOWN
( SAME AS FIG 1, UNLESS OTHERWISE STATED )
.0700 1.778 REF
.2887 7.332 REF
SECTION "C"-"C"
C:\EnterpriseVault\DWG\MISC\MKTG\QTE-XXX-01-XXX-D-DP-EMX-XX-MKT.SLDDRW
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
.8mm HS EDGEMOUNT TERMINAL ASSEMBLY
QTE-XXX-01-XXX-D-DP-EMX-XX
12/12/00
SHEET
2
OF
2
BY:
KEVIN B
