36HR14435X: DescriptionInterconnection Device, ROHS COMPLIANT; CategoryThe connector The connector; File Size104KB，1 Pages; ManufacturerSwitchcraft; Environmental Compliance

Download Datasheet Parametric Compare View All

36HR14435X Overview

Interconnection Device, ROHS COMPLIANT

36HR14435X Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Switchcraft
package instruction	ROHS COMPLIANT
Reach Compliance Code	not_compliant
Connector type	INTERCONNECTION DEVICE

Preview

Download Datasheet

View All

NOTES:

1. MATERIALS:

CABLE JACKET - PVC, BLACK

CONDUCTORS - 26 AWG, RED & WHITE W/ COPPER SPIRAL SHIELD

OVERMOLD

- PVC, BLACK

PLUG

- BRASS, NICKEL PLATED

WITH STEEL PIN, NICKEL PLATED

2. LEAD FREE SOLDER.

3. THIS PRODUCT IS RoHS COMPLIANT.

1.06

0.32

"X"

1.90

0.55

0.138 TYP

0.12

0.35

0.55

3.5MM STEREO PLUG

RIGHT ANGLE

TIP

RING

SLEEVE

WIRE CHART

WHITE

RED

SHIELD

3.5MM STEREO PLUG

CUSTOMER DRAWING

THIS DRAWING DESCRIBES A DESIGN CONSIDERED PROPRIETARY IN NATURE, DEVELOPED AND MANUFACTURED

BY SWITCHCRAFT INC. AND IS RELEASED ON A CONFIDENTIAL BASIS FOR IDENTIFICATION PURPOSES ONLY.

UNLESS OTHERWISE SPECIFIED

1. ALL DIMENSIONS IN INCHES

REV

SIZE

FINISH

WIDTH

MULT

MATERIAL

SPEC No.

SCALE

LBS/M

TEMPER

27142

26454

25790

26072

ECO NUMBER

5-7-13

09-23-09

01-07-08

7/6/06

DATE

JEB

TJK

APVD

- TWO PLACE DECIMALS

- THREE PLACE DECIMALS

0.02

0.005

SPEC No.

FIRST USED ON

DATE DRAWN

CHKD

1.25:1

7/6/06

TJK

7/6/06

PART No.

APVD

7/6/06

SHEET

REV

REVISIONS

DO NOT SCALE DRAWING

NAME

RA 3.5MM TO ST 3.5MM, RoHS

36HR___35X

SolidWorks CAD File
