Phycomp
Product specification
Surface-mount ceramic
EMI filter
Table of Contents
1. Introduction, Benefits, Applications
2. Available Capacitances & Voltage Ranges
3. Mechanical Data
4. NP0:
X2Y
Ç
Series
5. X7R:
Selection Chart
Electrical Characteristics
Thickness Qualification and Packing quantities
6. Y5V:
Selection Chart
Electrical Characteristics
Thickness Qualification and Packing quantities
Selection Chart
Electrical Characteristics
Thickness Qualification and Packing quantities
7. Ordering information
8. Recommended Solder lands
9. Insertion loss characteristics and measurement setup
10. Tests & Requirements
11. Revision history.
2002 Jul 10 Rev.6
2
www.yageo.com
Phycomp
Product specification
Surface-mount ceramic
EMI filter
X2Y EMI FILTERS
X2Y
Ç
Series
Phycomp’s X2Y®-series is a breakthrough in the design of ceramic multilayer products for decoupling and
filtering in an IPD (integrated passive device).
X2Y® products are comprised of two identical Y-capacitors and one X-capacitor, integrated into a 4-terminal
device, which is available in standard MLCC sizes. Thanks to the unique multilayer construction the device
provides noise cancellation within the device, reducing ESL from nanohenry to picohenry levels.
Using the unique balance between the Y-capacitors and the shielded multilayer structure the X2Y® products
offer superior decoupling and filtering.
The X2Y ® device performs as a broadband filter enabling better EMC compliance for electrical equipment in
a wide range of applications.
BENEFITS
Broadband Filter and Decoupler:
X2Y is effective up to 10 GHz and frequencies beyond.
By-pass:
Unlike feedthrough capacitors, X2Y devices are in by-pass and only handle the noise current.
Superior Balance:
2 closely matched Y-caps provide stable balance over time and temperature.
Ultra-low Inductance:
typical equivalent series inductance (ESL) to less than 50 picohenries.
Ultra-low ESR:
typical values of a few milli-ohms.
Lower Component and Placement Costs:
X2Y can eliminate inductors, ferrites, standard capacitors,
resistors and surge devices normally combined to form filter networks in the past.
Board Space Reduced:
Whether on the PCB board or IC Package, X2Y components allow for design
simplification resulting in a substantial reduction of board space needed.
APPLICATIONS
EMI filtering on DC motors
Filtered connectors (airbag connectors, RJ-45 connectors)
High speed data-line filtering
Decoupling of supply-lines in high speed digital circuits
Broadband filtering
7\SLFDO $SSOLFDWLRQ
(TXLYDOHQW &LUFXLW
&RQILJXUDWLRQ
/LQH
&\
*URXQG
&[
&\
/LQH
)LJ ;< 0XOWLOD\HUI LOWHU FDSDFLWRU
2002 Jul 10 Rev.6
3
www.yageo.com
Phycomp
Product specification
Surface-mount ceramic
EMI filter
QUICK REFERENCE DATA
DESCRIPTION
Materials
Rated Voltage
Capacitance range (Y-capacitor)
0603 series
0805 series
1206 series
1210 series
1812 series
Tolerance on capacitance:
Test Voltage (DC) for 1 minute:
Sectional specifications
Detailed specification
Climatic category (IEC 60 068)
VALUE
NP0, X7R, (Y5V, development)
10 V, 16 V, 25 V, 50 V, 100 V (IEC)
X2Y
Ç
Series
10 pF to 100 nF
10 pF to 470 nF
47 nF to 2200 nF
100 nF to 4700 nF
100 nF to 1000 nF
10%,
20%, - 20% / + 80%
2.5 x U-rated
IEC 60384-10, second edition 1989-04
Based on IEC – 60384-10-1
NP0 and X7R: 55/125/56, Y5V: 25/085/21
Available Capacitances & Voltage Ranges
C (pF)
NP0
10
22
47
100
220
330
1000
2200
4700
5600
10,000
15,000
18,000
22,000
39,000
47,000
56,000
100,000
180,000
220,000
270,000
330,000
390,000
470,000
560,000
820,000
1,000,000
2,200,000
4,700,000
0603
X7R
Y5V
NP0
0805
X7R
Y5V
1206
X7R
Y5V
1210
X7R
Y5V
1812
X7R
100V
100V
100V
100V
63V
25V
63V
25V
16V
16V
10V
16V
10V
16V
25V
16V
25V
10V
16V
16V
16V
25V
63V
63V
100V
63V
100V
100V
2002 Jul 10 Rev.6
4
www.yageo.com
