Sub-Miniature Precision
5.0x3.2mm
Clipped Sinewave TCXO
In Stock at Digi-Key
Description
2111 Comprehensive Drive
Aurora, Illinois 60505
Phone: 630-851-4722
Fax: 630-851-5040
www.conwin.com
US Headquarters
630-851-4722:
European Headquarters:
+353-61-472221
The Connor
-
Winfield
’s D53G
series are 5.0x3.2
mm
Surface Mount
T
emperature
Compensated Crystal
Oscillator (TCXO).
Through the use of
Analog Temperature Compensation,
t
he D53G
series are capable of
holding sub 1-ppm stabilities
over the
-30 to 85
°C
temperature range.
D53
G
20. 0 8 4 7
0M
Hz
Features
Model D53G
TCXO
3.3Vdc Operation
Clipped Sinewave Output Logic
Frequency Stability: ±0.50ppm
Temperature Range: -30 to 85°C
Low Jitter <1pS RMS
5.0x3.2mm Surface Mount Package
Tape and Reel Packaging
RoHS Compliant / Lead Free
Specification
Absolute Maximum Ratings
Parameter
Storage Temperature
Supply Voltage
Input Voltage
Operating Specifications
Parameter
Frequencies Available
Frequency Calibration @ 25 C
Frequency Stability [±(Fmax – Fmin)/2.Fo]
Supply Voltage Variation (Vcc ±5%)
Load Coefficient (±5%)
Static Temperature Hysteresis
Frequency shift after reflow soldering
Aging
Temperature Range
Supply Voltage
Supply Current
Period Jitter
Phase Jitter (BW=12kHz to 20MHz)
SSB Phase Noise at 10Hz offset
SSB Phase Noise at 100Hz offset
SSB Phase Noise at 1KHz offset
SSB Phase Noise at 10KHz offset
Clipped Sinewave Output Characteristics
Parameter
Output Voltage
Output Load Resistance
Output Load Capacitance
Minimum
1.00
-
-
Nominal
-
10K
10
Maximum
-
-
-
Units
V pk-pk
Ohms
pF
6
Note
5
(Vcc)
(Icc)
(Fo)
-1.00
-0.50
-0.025
-0.025
-
-1.00
-1.00
-30
3.135
-
-
-
-
-
-
-
Minimum
Nominal
20.0, 26.0
-
-
-
-
-
-
-
-
3.3
-
3
0.5
-80
-110
-130
-145
1.00
0.50
0.025
0.025
0.4
1.00
1.00
85
3.465
2
5
1
Maximum
Units
MHz
ppm
ppm
ppm
ppm
ppm
ppm
ppm/year
C
Vdc
mA
ps rms
ps rms
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
3
4
1
2
Note
(Vcc)
Minimum
-55
-0.5
-0.5
Nominal
-
-
-
Maximum
85
6.0
Vcc+0.5
Units
°C
Vdc
Vdc
Note
Note:
1) Initial calibration @ 25 C. Specifications at time of shipment after 48 hours of operation
2) Frequency stability vs. change in temperature.
3) Frequency change after reciprocal temperature ramped over the operating range.
Frequency measured before and after at 25°C.
4) Within two hours after reflow.
5) Output is DC coupled.
6) For best performance it is recommended that the circuit connected to this output should
have an equivalent input capacitance of 10pF.
Bulletin
Page
Revision
Date
Tx239
1 of 2
01
14 Nov 2008
Specifications subject to change without notice. All dimensions in inches. © Copyright 2008 The Connor-Winfield Corporation
2111 Comprehensive Drive
Aurora, Illinois 60505
Phone: 630-851-4722
Fax: 630-851-5040
www.conwin.com
Package Characteristics
Package
Ceramic Surface Mount Package.
Ordering Information
D53G - 020.0MHZ *
D53G - 026.0MHZ *
TCXO
SERIES
CENTER
FREQUENCY
Environmental Characteristics
Vibration:
Shock:
Soldering:
Solderability
Vibration per Mil Std 883E Method 2007.3 Test Condition A
Mechanical Shock per Mil Std 883E Method 2002.4 Test Condition B.
SMD product suitable for Convection Reflow soldering. Peak temperature
260 C. Maximum time above 220 C, 60 seconds.
Solderability per Mil Std 883E Method 2003
Package Layout
0.126
(3.2mm)
0.083 Max.
(2.1mm)
0.065
(1.65mm)
0.006 Typ.
(0.15mm)
0.016
(0.41mm)
0.050
(1.27mm)
0.028
(0.71mm)
Pad 1
Dimensional Tolerance:
+/-0.005 (+/-0.127mm)
0.008 Typ.
(0.20mm)
Pad 8
0.042
(1.07mm)
0.028
(0.71mm)
0.042
(1.07mm)
Suggested Pad Layout
To
Output
External AC
Coupling Capacitor
Used For Clipped
Sinwave Output
Keep Out
Area*
0.028
(0.71mm)
5
4
0.053
(1.35mm)
0.098
(2.49mm)
* For the tape and reel option,
add -T to the end of the part number.
Example: D53G-020.0 MHZ -T
Pin Connections
Pad
1
2
3
4
5
6
7
8
Connection
N/C
Do not connect
Do not connect
Ground
Output
Do not connect
Do not connect
Supply, Vcc
D53G 0847
20.0MHZ
0.197
(5.0mm)
Top
View
8
1
Top
View
Bottom
View
External
Bypass
Capacitor
0.01 uF
To
Ground
0.050
(1.27mm)
0.050
(1.27mm)
Dimensional Tolerance:
+/-0.005 (+/-0.127mm)
Typical Phase Noise
Model D53G-020.0MHZ
* Do not route any traces in the keep out area.
It is recommended the next layer under the
keep out area is to be ground plane.
Test Circuit
DNC DNC
AC Coupling
Capacitor
8
7
6
5
10Kohm 10 pF**
.01 uF
Bypass
1
N/C
4
2
3
Vcc
Supply
Voltage
Output
DNC DNC
DNC = Do Not Connect
**NPO Grade Component
Output Waveform
10ns 200mV
Tape and Reel Information
Solder Profile
Temperature
260°C
220°C
180°C
150°C
120°C
260°C
0
120 S
Max.
Time
10 S
60 S
Max.
360 Sec. Max.
US Headquarters:
Page
630-851-4722
European Headquarters:
Revision
+353-61-472221
Specifications subject to change without notice. All dimensions in inches. © Copyright 2008 The Connor-Winfield Corporation
Bulletin
Tx239
2 of 2
01
14 Nov 2008
