Power Entry Modules with Line Filter
https://www.schurter.com /PG06
FGS
IEC Appliance Inlet C14 with Filter, Front or Rear side Mounting
Snap-In Version with quick connect terminals
6.3 x 0.8 mm
Screw-On Version with
quick connect terminals 6.3 x 0.8 mm
C14
70° C
Description
- Panel Mount :
Snap-in or screw-on mounting from front or rear-side
- 2 Functions :
Appliance Inlet , Line-filter in standard version
- Quick connect terminals or wires
Newly available variants corresponding to V-Lock mating cordset. The connector is equipped with a notch intended for use with the latching cordset.
The cord latching system prevents against accidental removal of the cordset.
Technical Data
Ratings IEC
Ratings UL/CSA
Dielectric Strength
SE
1 - 10 A @ Ta 40 °C / 250 VAC; 50 Hz
1 - 10 A @ Ta 40 °C / 125 VAC; 60 Hz
> 1.7 kVDC between L-N
> 2.7 kVDC between L/N-PE
Test voltage (2 sec)
> 2.5 kV between L-N
> 5 kV between L/N-PE
-25 °C to 85 °C
Line Filter
MTBF
25/085/21 acc. to IEC 60068-1
from front side IP 40 acc. to IEC 60529
Suitable for appliances with protection
class I acc. to IEC 61140
Quick connect terminals or wires Quick
connect terminals 6.3 x 0.8 mm straight
Screw max 8 mm
Mounting screw torque max 0.5 Nm
Snap-in 1 mm to 3 mm
Aluminium 1.5-3 mm, steel 1-3 mm, not
suitable for plastic material
Thermoplastic, black, UL 94V-0
Impulse Withstand Voltage
Allowable Operation Tempe-
rature
Climatic Category
IP-Protection
Protection Class
Terminal
PH
A
Panel Thickness S
Material: Housing
Approvals and Compliances
Detailed information on product approvals, code requirements, usage instructions and detailed test conditions can be looked up in
Details about
Approvals
-O
UT
Screw-On Version with flexible wires
Approvals and Compliances
Characteristics
-
-
-
-
Compact design with optimal shielding
All single elements are already wired
For standard applications
Suitable for use in equipment according to IEC/UL 60950
References
Weblinks
We recommend for new applications the type
5120
Last order date: 31.12.2014
pdf datasheet, html-datasheet, General Product Information, Distributor-
Stock-Check, Accessories, Detailed request for product, Microsite
appliance inlet/-outlet
C14 acc. to IEC 60320-1,
UL 498, CSA C22.2 no. 42 (for cold
conditions) pin-temperature 70 °C, 10 A,
Protection Class I
Standard Version, IEC 60939, UL 1283,
CSA C22.2 no. 8
Technical Details
> 3'100'000 h acc. to MIL-HB-217 F
EMC Products
1
FGS
Approvals
Power Entry Modules with Line Filter
https://www.schurter.com /PG06
The approval mark is used by the testing authorities to certify compliance with the safety requirements placed on electronic products.
Approval Reference Type: FGS
Approval Logo
Certificates
VDE Approvals
UL Approvals
Certification Body
VDE
UL
Description
Certificate Number: 40004665
Product standards
Product standards that are referenced
Organization
Design
Designed according to
Designed according to
Designed according to
Designed according to
Designed according to
Designed according to
Designed according to
Standard
IEC 60320-1
IEC 60939
IEC 61058-1
UL 498
UL 1283
CSA C22.2 no. 42
CSA C22.2 no. 8
Application standards
Application standards where the product can be used
Organization
Design
Designed for applications acc.
Standard
Compliances
Identification
Details
The product complies with following Guide Lines
CE declaration of conformity
RoHS
China RoHS
REACH
PH
A
MicrositeV-Lock
2
SE
Initiator
SCHURTER AG
SCHURTER AG
SCHURTER AG
SCHURTER AG
SCHURTER AG
IEC/UL 60950
EMC Products
-O
UT
UL File Number: E72928
Description
Appliance couplers for household and similar general purposes
Passive filters for suppressing electromagnetic interference
Switches for appliances. Part 1. General requirements
Standard for Attachment Plugs and Receptacles
Electromagnetic interference filters
General Use Receptacles, Attachment Plugs, and Similar Wiring Devices
Electromagnetic interference (EMI) filters
Description
IEC 60950-1 includes the basic requirements for the safety of information
technologyequipment.
Description
The CE marking declares that the product complies with the applicable
requirements laid down in the harmonisation of Community legislation on
its affixing in accordance with EU Regulation 765/2008.
EU Directive RoHS 2011/65/EU
The law SJ / T 11363-2006 (China RoHS) has been in force since 1 March
2007. It is similar to the EU directive RoHS.
On 1 June 2007, Regulation (EC) No 1907/2006 on the Registration,
Evaluation, Authorization and Restriction of Chemicals 1 (abbreviated as
"REACH") entered into force.
V-Lock system are based on a matching plug-dose combination. The
connector is equipped with a notch intended for use with the latching
cordset. The cord latching system prevents against accidental removal of
the cordset.
Power Entry Modules with Line Filter
https://www.schurter.com /PG06
FGS
Dimension [mm]
Snap-in, front side, quick connect terminals
max. 26
6.3x0.8
max. 44
0.8...3 mm
Screw-on, rear side, quick connect terminal
(23)
(R4.8)
max.52
SE
(22.2)
(5)
(5)
(57)
150
±10
max.50
(R4.8)
30.4
(21.1)
22
-0
Screw-on, rear side, flexible wires
(23)
3.2
PH
A
max.52
(30.3)
(40)
(22.2)
40
±0.15
(30.3)
(28.1)
brown
+0.5
-0
yellow green
+0.5
(4)
30.4
blue
(21.1)
22
-0
(10)
EMC Products
3
40
±0.15
(28.1)
-O
UT
(5.8)
(21.1)
22.3
+0.1
-0
(57)
max. 29.5
(R 4.8)
max. 34
(28.1)
28.4
-0
+0.1
R3
X
X
max.50
3.2
(R4.5)
R < 4.3
=
(40)
+0.5
-0
+0.5
(R4.5)
R < 4.3
=
FGS
Technical Data of Filter-Components
Rated Current
[A]
1
2
4
6
10
Filter-Type
Standard
Standard
Standard
Standard
Standard
Inductances
L [mH]
2 x 10
2x4
2 x 1.5
2 x 0.8
2 x 0.3
Capacitance
CX [nF]
47
47
Power Entry Modules with Line Filter
https://www.schurter.com /PG06
47
47
Diagrams
Standard version
L
L1
L’
R
L2
Cy
Cy
1)
PE
Cx
PE’
2)
N’
N
1) Line
2) Load
Attenuation Loss
Standard version
1A
2A
10 A
PH
A
All Variants
Rated Current
[A]
Mounting
Panel mounting
1
Snap-in
Mounting from front side
2
Snap-in
Mounting from front side
4
Snap-in
Mounting from front side
6
Snap-in
Mounting from front side
10
1
2
Snap-in
Mounting from front side
Screw
Screw-on from rear side
Screw
Screw-on from rear side
4
Screw
Screw-on from rear side
6
Screw
Screw-on from rear side
10
Screw
Screw-on from rear side
SE
Terminal
Order Number
Quick connect terminals 6.3 x 0.8 mm
Quick connect terminals 6.3 x 0.8 mm
Quick connect terminals 6.3 x 0.8 mm
Quick connect terminals 6.3 x 0.8 mm
Quick connect terminals 6.3 x 0.8 mm
Quick connect terminals 6.3 x 0.8 mm
Quick connect terminals 6.3 x 0.8 mm
Quick connect terminals 6.3 x 0.8 mm
Quick connect terminals 6.3 x 0.8 mm
Quick connect terminals 6.3 x 0.8 mm
4300.5011
4300.5012
4300.5013
4300.5014
4300.5015
4300.5091
4300.5092
4300.5093
4300.5094
4300.5095
4
EMC Products
-O
UT
- - - - 50Ω differential mode _____ 50Ω common mode
47
4A
6A
Power Entry Modules with Line Filter
https://www.schurter.com /PG06
FGS
Terminal
Flexible wire AWG18
Flexible wire AWG18
Flexible wire AWG18
Flexible wire AWG18
Flexible wire AWG18
Order Number
4300.5071
4300.5072
4300.5073
4300.5074
4300.5075
Rated Current
[A]
1
2
4
6
10
Mounting
Screw
Screw
Screw
Screw
Screw
Panel mounting
Screw-on from rear side
Screw-on from rear side
Screw-on from rear side
Screw-on from rear side
Screw-on from rear side
Availability for all products can be searched real-time:https://www.schurter.com/en/Stock-Check/Stock-Check-SCHURTER
Packaging unit
Accessories
10 Pcs
Description
Assorted Covers
Rear Cover
Mating Outlets/Connectors
Category / Description
SE
Appliance Outlet Overview complete
IEC Appliance Outlet F, Screw-on Mounting, Front Side, Solder Terminal
Appliance Outlet further types to FGS
Connector Overview complete
Connector further types to FGS
IEC Appliance Outlet F, Snap-in Mounting, Front Side, Solder or Quick-connect Terminal
IEC Appliance Outlet F or H, Screw-on Mounting, Front Side, Solder, PCB or Quick-connect Terminal
PH
A
Mating Outlets/Connectors shuttered
Power Cord Overview complete
Power Cord further types to FGS
4782 Mounting: Power Cord, 3 x 1 mm² / 3 x 18 AWG, Cable, Connector: IEC C13
4022 Mounting: Power Supply Cord, 3 x 1.5 mm², Screw clamps, Connector: IEC C13
4785 Mounting: Power Cord, 3 x 1 mm² / 3 x 18 AWG, Cable, Connector: IEC C13
4300-06 Mounting: Power Cord, 3 x 1 mm² / 3 x 18 AWG, Cable, Connector: IEC C13
4012 Mounting: Power Supply Cord, 3 x 1.5 mm², Screw clamps, Connector: IEC C13
VAC13KS, Overview, diverse Connector IEC C13, cord end:
-O
UT
0859.0048
4787
4788
5091
4782
4022
4785
4300-06
4012
...
VAC13KS
The specifications, descriptions and illustrations indicated in this document are based on current
information. All content is subject to modifications and amendments. Information furnished is believed
to be accurate and reliable. However, users should independently evaluate the suitability and test each
product selected for their own applications.
EMC Products
5
02.12.2017
