2SA1083
Elektronische Bauelemente
RoHS Compliant Product
A suffix of “-C” specifies halogen & lead-free
-0.1 A, -60 V
PNP Plastic Encapsulated Transistor
FEATURES
TO-92
Low Frequency Amplifier
G
H
CLASSIFICATION OF h
FE
Product-Rank
Range
2SA1083-D
250-500
2SA1083-E
400-800
K
J
A
B
D
Emitter
Collector
Base
REF.
A
B
C
D
E
F
G
H
J
K
E
C
F
Millimeter
Min.
Max.
4.40
4.70
4.30
4.70
12.70
-
3.30
3.81
0.36
0.56
0.36
0.51
1.27 TYP.
1.10
-
2.42
2.66
0.36
0.76
Collector
Base
Emitter
ABSOLUTE MAXIMUM RATINGS
(T
A
= 25°C unless otherwise specified)
Parameter
Collector to Base Voltage
Collector to Emitter Voltage
Emitter to Base Voltage
Collector Current - Continuous
Collector Power Dissipation
Thermal Resistance From Junction to Ambient
Junction, Storage Temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
C
R
θJA
T
J
, T
STG
Rating
-60
-60
-5
-0.1
400
312
150, -55~150
Unit
V
V
V
A
mW
°C / W
°C
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise specified)
Parameter
Collector to Base Breakdown Voltage
Collector to Emitter Breakdown Voltage
Emitter to Base Breakdown Voltage
Collector Cut-Off Current
Emitter Cut-Off Current
DC Current Gain
Collector to Emitter Saturation Voltage
Base to Emitter Voltage
Transition Frequency
Collector Output Capacitance
Symbol
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
I
CBO
I
EBO
h
FE
V
CE(sat)
V
BE
f
T
C
ob
Min
-60
-60
-5
-
-
250
-
-
-
-
Typ
-
-
-
-
-
-
-
-0.6
90
3.5
Max
-
-
-
-0.1
-0.1
800
-0.2
-
-
-
Unit
V
V
V
μA
μA
V
V
MHz
pF
Test condition
I
C
= -0.01mA, I
E
=0
I
C
= -1mA, I
B
=0
I
E
= -0.01mA, I
C
=0
V
CB
= -50 V, I
E
=0
V
EB
= -2V, I
C
=0
V
CE
= -12V, I
C
= -2mA
I
C
= -10mA, I
B
= -1mA
V
CE
= -12V, I
C
= -2mA
V
CE
= -12V, I
C
= -2mA
V
CB
= -10V, I
E
=0, f=1MHz
http://www.SeCoSGmbH.com/
Any changes of specification will not be informed individually.
13-Jan-2011 Rev. A
Page 1 of 1
