SAW Components
SAW IF filter
WCDMA
Series/type:
Ordering code:
Date:
Version:
B5070
B39171-B5070-H810
Sep 24, 2007
2.0
©
EPCOS AG 2007. Reproduction, publication and dissemination of this data sheet, enclosures
hereto and the information contained therein without EPCOS’ prior express consent is prohibited.
SAW Components
SAW IF filter
Data sheet
Application
s
Low-loss IF filter for WCDMA base station
s
Usable passband 15 MHz
s
Balanced or unbalanced operation possible
B5070
167.0 MHz
Features
Package size 7.0 x 5.0 x 1.33 mm
3
Package code QCC12E
RoHS compatible
Approx. weight 0.25 g
Ceramic package for
Surface Mount Technology
(SMT)
s
Ni, gold-plated terminals
s
Electrostatic Sensitive Device
(ESD)
s
Filter surface passivated
s
s
s
s
s
Pin configuration
s
s
s
s
s
s
10
12
4
6
2, 3, 8, 9
1, 5, 7, 11
Input
Input ground or input balance
Output
Output ground or output balance
To be grounded
Case ground
10
4
12
6
1,5,7,11
Please read
cautions and warnings and
important notes
at the end of this document.
2
Sep 24, 2007
SAW Components
SAW IF filter
Data sheet
Characteristics
Operating temperature range:
Terminating source impedance:
Terminating load impedance:
T =
Z
S
=
Z
L
=
–10 to 85 ˚C
50
Ω
and matching network
50
Ω
and matching network
min.
Nominal frequency
Minimum insertion attenuation
(including matching network)
f
N
α
min
—
—
typ.
@ 25 ˚C
167.0
7.3
max.
—
8.5
MHz
dB
B5070
167.0 MHz
Maximum insertion attenuation
α
max
(including matching network) f
N
±
7.5 MHz
Passband width
α
rel
≤
1.0 dB
Amplitude ripple
(p-p)
f
N
±
7.5 MHz
B
1dB
∆α
—
7.7
9.5
dB
15.0
18.1
—
MHz
—
0.4
1.0
dB
Average Error Vector Magnitude
EVM
f
N
±
1.92 MHz
f
N
– 5 MHz
±
1.92 MHz
f
N
+
5 MHz
±
1.92 MHz
f
N,CDMA
(k)
1)
±
0.6144 MHz
Return Loss
Input
Output
Input IP3
f
N
±
7.5 MHz
f
N
±
7.5 MHz
—
—
—
—
0.7
0.9
0.9
0.7
3.0
4.0
4.0
4.0
%
%
%
%
10.0
10.0
15.0
19.0
—
—
dB
dB
40
Relative attenuation (relative to
α
min
)
α
rel
f
N
– 10.0 MHz ... f
N
– 15.0 MHz
f
N
+
10.0 MHz ... f
N
+
15.0 MHz
f
N
±
15.0 MHz ... f
N
±
20.0 MHz
f
N
±
20.0 MHz ... f
N
±
57.0 MHz
Temperature coefficient of frequency
1)
—
—
dBm
0.5
1.5
25
40
—
4.0
5.7
46
50
–87
—
—
—
—
—
dB
dB
dB
dB
ppm/K
TC
f
f
N,CDMA
(k) = 160.125MHz + k*1.25MHz;
k = (0,1,... ,11)
Please read
cautions and warnings and
important notes
at the end of this document.
3
Sep 24, 2007
SAW Components
SAW IF filter
Data sheet
Characteristics
Operating temperature range:
Terminating source impedance:
Terminating load impedance:
T =
Z
S
=
Z
L
=
–40 to 85 ˚C
50
Ω
and matching network
50
Ω
and matching network
min.
Nominal frequency
Minimum insertion attenuation
(including matching network)
f
N
α
min
—
—
typ.
@ 25 ˚C
167.0
7.3
max.
—
8.5
MHz
dB
B5070
167.0 MHz
Maximum insertion attenuation
α
max
(including matching network) f
N
±
7.5 MHz
Passband width
α
rel
≤
1.0 dB
Amplitude ripple
(p-p)
f
N
±
7.5 MHz
B
1dB
∆α
—
7.7
9.5
dB
15.0
18.1
—
MHz
—
0.4
1.0
dB
Average Error Vector Magnitude
EVM
f
N
±
1.92 MHz
f
N
– 5 MHz
±
1.92 MHz
f
N
+
5 MHz
±
1.92 MHz
f
N,CDMA
(k)
1)
±
0.6144 MHz
Return Loss
Input
Output
Input IP3
f
N
±
7.5 MHz
f
N
±
7.5 MHz
—
—
—
—
0.7
0.9
0.9
0.7
3.0
4.0
4.0
4.0
%
%
%
%
10.0
10.0
15.0
19.0
—
—
dB
dB
40
Relative attenuation (relative to
α
min
)
α
rel
f
N
– 10.0 MHz ... f
N
– 15.0 MHz
f
N
+
10.0 MHz ... f
N
+
15.0 MHz
f
N
±
15.0 MHz ... f
N
±
20.0 MHz
f
N
±
20.0 MHz ... f
N
±
57.0 MHz
Temperature coefficient of frequency
1)
—
—
dBm
0.5
0.5
25
40
—
4.0
5.7
46
50
–87
—
—
—
—
—
dB
dB
dB
dB
ppm/K
TC
f
f
N,CDMA
(k) = 160.125MHz + k*1.25MHz;
k = (0,1,... ,11)
Please read
cautions and warnings and
important notes
at the end of this document.
4
Sep 24, 2007
SAW Components
SAW IF filter
Data sheet
Matching network to 50
Ω
unbalanced
B5070
167.0 MHz
L
s1
= 68 nH
L
p2
= 68 nH
L
p3
= 120 nH
L
s4
= 100 nH
Maximum ratings
Operable temperature range
Storage temperature range
DC voltage
ESD voltage
Input power
Input peak power
1)
T
T
stg
V
DC
V
ESD
P
IN
P
IN,peak
–40/+85
–40/+85
0
200
1)
10
23
˚C
˚C
V
V
dBm
dBm
machine model, 1 pulse
for max. 100 hours
acc. to J-STD22A-0115A (machine model, 1 pulse +/-).
Please read
cautions and warnings and
important notes
at the end of this document.
5
Sep 24, 2007
