SAW Components
SAW GPS Filter
Series/type:
Ordering code:
Date:
Version:
B9080
B39162B9080L310
May 12, 2009
2.5
©
EPCOS AG 2009. Reproduction, publication and dissemination of this data sheet, enclosures
hereto and the information contained therein without EPCOS’ prior express consent is prohibited.
SAW Components
SAW GPS Filter
Data Sheet
Application
s
s
s
s
s
s
s
B9080
1575.42 MHz
ESD robust low-loss RF GPS filter
High ESD protection at the filter input
Usable passband: 4 MHz
Very low insertion attenuation
Very high out of band selectivity
Unbalanced to unbalanced operation
No matching network required for operation at 50
Ω
Features
Package size 2.0 x 1.6 x 0.86. mm
3
Package code DCS4M
RoHS compatible
Approximate weight 0.007 g
Package for
Surface Mount Technology
(SMT)
s
Ni, gold-plated terminals
s
Electrostatic Sensitive Device
(ESD)
s
s
s
s
s
0.86
Pin configuration
s
1
s
3
s
2,4
Input
Output
Case ground
1
3
4
2
Please read
cautions and warnings and
important notes
at the end of this document.
2
May 12, 2009
SAW Components
SAW GPS Filter
Data Sheet
Characteristics of Filter
Temperature range for specification:
Terminating source impedance:
Terminating load impedance:
T = –30 ˚C to +85˚C
Z
S
=
50
Ω
Z
L
=
50
Ω
B9080
typ.
@ 25 ˚C
1575.42
B9080
1575.42 MHz
min.
Center frequency
f
C
—
max.
—
MHz
Maximum insertion attenuation
α
max
1573.42 ... 1577.42 MHz
Amplitude ripple
(p-p)
∆α
1573.42 ... 1577.42 MHz
VSWR (Input and Output)
1573.42 ... 1577.42 MHz
IIP2 (2
nd
order Input Intercept Point)
2 tone (cw) method:
P1@+22.5dBm @F1=824MHz..915MHz
P2 @-0.5dBm @F2=F1+1575.42MHz
P1@+21dBm @F1=824MHz..915MHz
P2 @+14dBm @F2=F1+1575.42MHz
P1@+20dBm @F1=1710MHz..1785MHz
P2 @-13.3dBm @F2=F1+1575.42MHz
P1@+20dBm @F1=1850MHz..1910MHz
P2 @-13.3dBm @F2=F1+1575.42MHz
IIP3 (3
rd
order Input Intercept Point)
2 tone (cw) method:
P1@+20dBm @F1=1710MHz..1785MHz
P2 @+11dBm @F2=2*F1+1575.42MHz
P1@+21dBm @F1=824MHz..915MHz
P2@-13.3dBm @F2=2*F1+1575.42MHz
P1@+20dBm @F1=2500MHz..2570MHz
P2@-13.3dBm @F2=2*F1-1575.42MHz
Group delay ripple
(p-p)
∆τ
1573.42 ... 1577.42 MHz
—
1.2
1.5
dB
—
0.1
0.4
dB
—
1.35
1.8
110.5
98.0
95
95
117.8
115
111
110
—
—
—
—
dBm
dBm
dBm
dBm
95
90
85
110
105
100
—
—
—
dBm
dBm
dBm
—
8
20
ns
Please read
cautions and warnings and
important notes
at the end of this document.
3
May 12, 2009
SAW Components
SAW GPS Filter
Data Sheet
min.
Attenuation
0.1 ... 824.0
824.0 ... 849.0
849.0 ... 915.0
915.0 ... 1400.0
1611.0 ... 1648.0
1648.0 ... 1710.0
1710.0 ... 1785.0
1785.0 ... 1850.0
1850.0 ... 1910.0
1910.0 ... 1980.0
1980.0 ... 2400.0
2400.0 ... 2484.0
2484.0 ... 2570.0
2570.0 ... 3900.0
3900.0 ... 4400.0
4400.0 ... 5150.0
5150.0 ... 5400.0
5400.0 ... 6000.0
((824 - 849) + (2400 - 2484))/2
((849 - 915) + (2400 - 2484))/2
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
α
48
50
50
48
6
45
53
46
46
46
43
43
42
33
30
15
14
10
45
45
57
57
56
55
13
61
61
61
62
61
51
50
48
41
41
27
20
15
53.5
53
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
B9080
typ.
@ 25 ˚C
max.
B9080
1575.42 MHz
Please read
cautions and warnings and
important notes
at the end of this document.
4
May 12, 2009
SAW Components
SAW GPS Filter
Data Sheet
Maximum ratings of Filter
Operable temperature range
Storage temperature range
DC voltage
ESD voltage @ Input
Contact Discharge
Air Discharge
Machine Model
Machine Model
Charge Device Model
Human Body Model
Input power
WCDMA systems
TDMA systems
1)
2)
3)
4)
5)
B9080
1575.42 MHz
T
T
stg
V
DC
V
ESD
V
ESD
V
ESD
V
ESD
V
ESD
V
ESD
P
IN
P
IN
–30/+85
–40/+85
5
± 8
1)
± 15
2)
± 1000
3)
± 100
2)
± 500
4)
± 200
5)
30
36
˚C
˚C
V
kV
kV
V
V
V
V
dBm
dBm
at input pin 1
at input pin 1
at input pin 1
at output pin 3
at input and output (pin 1 and 3)
at input and output (pin 1 and 3)
Average, cw
Peak, max. duty cycle 1:2
acc. to IEC61000-4-2 (Contact discharge, Rs = 330 R, Cs = 150 pF), 10 negative & 10 positive pulses.
acc. to IEC61000-4-2 (Air discharge, Rs = 330 R, Cs = 150 pF), 10 negative & 10 positive pulses.
acc. to JESD22-A115A (Machine model, Rs = 0 R, Cs = 200 pF), 10 negative & 10 positive pulses.
acc. to JESD22-C101 (Charge device model)
acc. to JESD22-A114 (Human body model, Rs = 1500 R, Cs = 100 pF), 1 negative & 1 positive pulse.
Please read
cautions and warnings and
important notes
at the end of this document.
5
May 12, 2009
