Resettable Fuses
https://www.schurter.com /PG01_1
PFRA
Radial Leaded Fuse, PTC, 60 VDC
16.0 - 60.0 VDC · 0.1 - 11 A
Description
Approvals and Compliances
- THT standard industry type
- Directly solderable on printed circuit boards
Applications
- Computer & Peripherals
- General electronics
- Automotive applications
References
Weblinks
Packaging Details
pdf datasheet, html-datasheet, General Product Information, Packaging
details, Distributor-Stock-Check, Detailed request for product
Technical Data
V max
Imax
I hold
Attachment
Allowable Operation Tempe-
rature
Material: Terminals
Weight
Storage Conditions
Product Marking
16.0 - 60.0 VDC
40 - 100 A
0.1 - 11 A
PCB,THT
-40 °C to 85 °C
see variants
0.35 g
0 °C to 40 °C, max. 70% r.h.
, Type, I hold
Soldering Methods
Solderability
Resistance to Soldering Heat
Passing Aging
Humidity Aging
Thermal Shock
Wave
Soldering Profile
235 °C / 2 sec
260 °C / 10 sec
+85 °C, 1000 Hours -> +/- 5% Typical
Resistance Change
+85 °C, 85% r.h., 1000 Hours -> +/-
5% Typical Resistance Change
MIL-STD-202, Method 107 (+125 °C to
-55 °C, 10 Cycles) -> +/- 15% Typical
Resistance Change
MIL-STD-883C, Method 2007.1, Test
Condition A
MIL-STD-202, Methode 215
UL 94V-0
Vibration
Resistance to Solvents
Flammability
Approvals and Compliances
Detailed information on product approvals, code requirements, usage instructions and detailed test conditions can be looked up in
Details about
Approvals
Approvals
The approval mark is used by the testing authorities to certify compliance with the safety requirements placed on electronic products.
Approval Reference Type: PFRA
Approval Logo
Certificates
TUEV Approvals
UL Approvals
Certification Body
TUEV
UL
Description
Technischer Überwachungsverein
UL File Number: E172175
Product standards
Product standards that are referenced
Organization
Design
Designed according to
Designed according to
Standard
UL 1434
CSA 22.2 No. 0 TIL No. CA-3A
Description
Thermistor-type devices
General requirements - Canadian electrical code, part II
Fuses
1
PFRA
Application standards
Application standards where the product can be used
Organization
Design
Designed for applications acc.
Standard
IEC/UL 60950
Description
https://www.schurter.com /PG01_1
Resettable Fuses
IEC 60950-1 includes the basic requirements for the safety of information
technologyequipment.
Compliances
The product complies with following Guide Lines
Identification
Details
CE declaration of conformity
Initiator
SCHURTER AG
Description
The CE marking declares that the product complies with the applicable
requirements laid down in the harmonisation of Community legislation on
its affixing in accordance with EU Regulation 765/2008.
EU Directive RoHS 2011/65/EU
The law SJ / T 11363-2006 (China RoHS) has been in force since 1 March
2007. It is similar to the EU directive RoHS.
On 1 June 2007, Regulation (EC) No 1907/2006 on the Registration,
Evaluation, Authorization and Restriction of Chemicals 1 (abbreviated as
"REACH") entered into force.
RoHS
China RoHS
REACH
SCHURTER AG
SCHURTER AG
SCHURTER AG
Dimension [mm]
A
E
A
E
B
D
C
C
PFRA.010 - PFRA.185
PFRA.250 - PFRA.1100
Time-Current-Curves
1000
100
10
1
0.1
0.01
0.001
PFRA.1100
PFRA.900
PFRA.800
PFRA.700
PFRA.600
PFRA.500
PFRA.400
PFRA.300
PFRA.250
PFRA.185
PFRA.160
PFRA.135
PFRA.110
PFRA.090
PFRA.075
PFRA.065
PFRA.050
PFRA.040
PFRA.030
PFRA.025
PFRA.020
PFRA.017
PFRA.010
Time to Trip in Seconds
0.1
1
10
100
Fault Current in Amperes
2
Fuses
D
B
Resettable Fuses
https://www.schurter.com /PG01_1
PFRA
I trip [A]
R initial min
[Ω]
0.27
0.18
0.18
0.14
0.14
0.1
0.1
0.065
0.065
0.055
0.055
0.04
0.04
0.025
0.025
0.02
0.02
0.01
0.01
0.01
0.005
0.005
0.005
0.005
0.003
R initial max
[Ω]
0.48
0.4
0.4
0.31
0.31
0.18
0.18
0.115
0.115
0.105
0.105
0.07
0.07
0.048
0.048
0.05
0.05
0.03
0.03
0.03
0.02
0.02
0.02
0.01
0.01
R 1hour max
[Ω]
0.72
0.6
0.6
0.47
0.47
0.27
0.27
0.17
0.17
0.15
0.15
0.11
0.11
0.07
0.07
0.08
0.08
0.05
0.05
0.05
0.04
0.03
0.03
0.02
0.01
Max Time to
trip [A]
3.25
3.75
3.75
4.5
4.5
5.5
5.5
6.75
6.75
8
8
9.25
9.25
12.5
12.5
15
15
20
20
25
30
35
40
45
40
Max Time to
Trip [s]
5.3
6.3
6.3
7.2
7.2
6.6
6.6
7.3
7.3
8
8
8.7
8.7
10.3
10.3
10.8
10.8
12.7
12.7
14.5
16
17.5
18.8
20
20
Tripped Power
Dissipation [W]
0.90
0.90
0.90
1.00
1.00
0.70
0.70
0.80
0.80
0.90
0.90
1.00
1.00
1.20
1.20
2.00
2.00
2.50
2.50
3.00
3.50
3.80
4.00
4.20
4.50
Order Number
V max [VDC]
I max [A]
I hold [A]
60.0
60.0
60.0
60.0
60.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
16.0
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
100
0.65
0.75
0.75
0.9
0.9
1.1
-
1.35
1.35
1.6
1.6
1.85
1.85
2.5
2.5
3
3
4
4
5
6
7
8
9
11
1.3
1.5
1.5
1.8
1.8
2.2
2.2
2.7
2.7
3.2
3.2
3.7
3.7
5
5
6
6
8
8
10
12
14
16
18
22
PFRA.065.2
PFRA.075
PFRA.075.2
PFRA.090
PFRA.090.2
PFRA.110
PFRA.110.2
PFRA.135
PFRA.135.2
PFRA.160
PFRA.160.2
PFRA.185
PFRA.185.2
PFRA.250
PFRA.250.2
PFRA.300
PFRA.300.2
PFRA.400
PFRA.400.2
PFRA.500
PFRA.600
PFRA.700
PFRA.800
PFRA.900
PFRA.1100
█
█
█
█
█
█
█
█
█
█
█
Most Popular.
Availability for all products can be searched real-time:https://www.schurter.com/en/Stock-Check/Stock-Check-SCHURTER
Packaging Unit
PFRA.xxxx
Bulk (500 pcs.)
PFRA.010.2 - PFRA.160.2
Taped 34 cm Reel (3000 pcs.)
PFRA.185.2 - PFRA.400.2
Taped 34 cm Reel (1500 pcs.)
The specifications, descriptions and illustrations indicated in this document are based on current
information. All content is subject to modifications and amendments. Information furnished is believed
to be accurate and reliable. However, users should independently evaluate the suitability and test each
product selected for their own applications.
Fuses
5
02.12.2017
