LS5301, PF5301
VERY HIGH INPUT IMPEDANCE
N-CHANNEL JFET AMPLIFIER
FEATURES
REPLACEMENT FOR LF5301, PF5301
HIGH INPUT INPEDANCE
HIGH GAIN
ABSOLUTE MAXIMUM
RATINGS
1
@ 25 °C (unless otherwise stated), TA=25°C
Maximum Temperatures
Storage Temperature (TO-72)
Storage Temperature (TO-92)
Maximum Power
Dissipation
2
300mW
50mA
-30V
-30V
Continuous Power Dissipation, TA=25°C
Maximum Currents
Gate Current
Maximum Voltages
Gate to Drain
Gate to Source
-55 to 150°C
-55 to 150°C
G
3
S
2
D
1
I
G
= 0.100 pA
g
fs
= 70 µS
LS5301
TO-72
TOP VIEW
PF5301
TO-92
TOP VIEW
COMMON ELECTRICAL CHARACTERISTICS @ 25 °C (unless otherwise stated)
SYMBOL
BV
GSS
V
GS(off)
I
GSS
I
G
I
DSS
g
fs
C
iss
C
rss
e
n
CHARACTERISTIC
Gate to Source Breakdown Voltage
Gate to Source Cutoff Voltage
Gate Leakage Current
Gate Operating Current
Drain to Source Saturation Current
Forward Transconductance
Input Capacitance
Reverse Transfer Capacitance
Equivalent Noise Voltage
45
30
70
LS5301
PF5301
-0.04
500
500
3
1.5
150
µA
µS
pF
nV/√Hz
MIN
-30
-0.6
-3.0
-1
-5
pA
TYP
MAX
UNIT
V
CONDITIONS
V
DS
= 0V, I
D
= -1µA
V
DS
= 10V, I
D
= 1nA
V
DS
= 0V, V
GS
= -15V
V
DG
= 6V, I
D
= 5µA
V
DS
= 10V, V
GS
= 0V
V
DS
= 10V, V
GS
= 0V,
f
= 1kHz
V
DS
= 10V, V
GS
= 0V,
f
= 1MHz
V
DG
= 10V, I
D
= 50µA,
f
= 100Hz
NOTES
1.
2.
3.
Absolute maximum ratings are limiting values above which serviceability may be impaired.
Derate PF series 2.8mW/° C when TA>25° C. Derate LS series 2.0mW°C when TA>25° C
All MIN/TYP/MAX limits are absolute numbers. Negative signs indicated electrical polarity only.
Information furnished by Linear Integrated Systems is believed to be accurate and reliable. However, no responsibility is assumed for its use;
nor for any infringement of patents or other rights of third parties which may result from its use. No license is granted by implication or
otherwise under any patent or patent rights of Linear Integrated Systems.
