5V CMOS Oscillator Mil Temp
MCSO1 & MCSO1H
Specifications
MCSO1: 400kHz ~ 20.0MHz
MCSO1H: 20.0 ~ 160MHz
Parameters
Frequency range:
400kHz ~ 20.0MHz
20.0 ~ 160MHz
Frequency stability*:
3.60
Product
MCSO1 MCSO1H
Option
Codes
7.86
±100ppm
±50ppm
tighter stabilities on request
T
specify
A
B
C
ACTUAL SIZE
PAD
1
2
2.00
3
4
CONNECTION
Not connected or
Enable/Disable
Operating temperature range:
0 to +70°C
-40 to +85°C
-55 to +125°C
Operable temperature range:
-55 to +125°C
Storage temperature range:
-65 to +125°C
Supply voltage (V
DD
):
+5.0V (±10%)
Supply current (max):
Driving ability:
Scale 3:1
15mA
50mA
Ground
Output
Supply
1
4
2.10
2
3
1.00
4
1
3
2
2.10
1.10
2.10
2.54
3.30
TOP VIEW
2.54
CMOS / 10 LSTTL
Features
Logic levels:
‘0' level = +0.4V max
‘1' level = 90%V
DD
min
Start up time:
5ms max
«
«
«
«
Military temperature range option
Excellent shock & vibration resistance
Enable / disable tristate option (>500kHz)
Wide frequency range available
Waveform symmetry:
40:60 max @ 50%V
DD
Rise / fall times:
7ns max
3ns max
Standard Frequencies
Frequencies in MHz
10.00000*
10.15000*
10.23000*
10.24000*
11.05920*
12.00000*
12.28800*
12.80000*
13.00000*
14.74560*
16.00000*
16.38400*
18.43200*
19.20000*
19.66080*
20.00000*
40.00000
40.60000
40.96000
44.23680
48.00000
49.15200
50.00000
50.75000
51.15000
51.20000
52.00000
55.29600
58.98240
60.00000
60.90000
61.38000
61.44000
64.00000
65.00000
65.53600
66.35520
72.00000
73.72800
76.80000
78.00000
80.00000
81.20000
81.84000
81.92000
88.47360
90.00000
96.00000
98.30400
100.00000
102.40000
104.00000
108.00000
110.59200
117.96400
120.00000
125.00000
128.00000
131.07200
132.71040
144.00000
150.00000
160.00000
Enable / disable function:
None (pad 1 NC)
Tristate* (control via pad 1)
* not available under 500kHz
Shock resistance:
5,000G, 0.3ms, ½ sine
Vibration resistance:
10G rms 10.0 ~ 2,000Hz
Soldering condition:
260°C, 10 sec max
Standard.
Optional - Please specify required code(s) when ordering
E
* Frequency stability is inclusive of calibration @ 25°C, operating temperature range, supply
voltage change, load change and ageing over 10 years.
Ordering Information
Product name + option codes (if any) + frequency
eg:
MCSO1/TBE 16.0MHz
±50ppm -40 to +85°C Enable / disable
MCSO1H/C 90.0MHz
±100ppm -55to +125°C
Option code X (eg MCSO1/X) denotes a custom specification.
* Binary divisions of the above frequencies also available.
Enable / Disable Function
Input (pad 1)
Open
‘1’ level
‘0’ level
Output (pad 3)
Enabled
Enabled
High Impedance
Packed in trays (50pcs/tray).
Tel:
+44 1460 256 100
18 Oct 2004
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
