BD6216FP-E2

Description
Brush DC Motor Controller, 1A, PDSO25, ROHS COMPLIANT, HSOP-25
CategoryOther integrated circuit (IC)    The signal circuit
File Size383KB,17 Pages
ManufacturerROHM Semiconductor
Websitehttps://www.rohm.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

BD6216FP-E2 Overview

Brush DC Motor Controller, 1A, PDSO25, ROHS COMPLIANT, HSOP-25

BD6216FP-E2 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerROHM Semiconductor
Parts packaging codeSOIC
package instructionHSSOP, SOP32,.3,32
Contacts25
Reach Compliance Codecompliant
ECCN codeEAR99
Analog Integrated Circuits - Other TypesBRUSH DC MOTOR CONTROLLER
JESD-30 codeR-PDSO-G25
length13.6 mm
Number of functions1
Number of terminals25
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Maximum output current1 A
Package body materialPLASTIC/EPOXY
encapsulated codeHSSOP
Encapsulate equivalent codeSOP32,.3,32
Package shapeRECTANGULAR
Package formSMALL OUTLINE, HEAT SINK/SLUG, SHRINK PITCH
Peak Reflow Temperature (Celsius)NOT SPECIFIED
power supply5 V
Certification statusNot Qualified
Maximum supply current (Isup)1.7 mA
Maximum supply voltage (Vsup)5.5 V
Minimum supply voltage (Vsup)3 V
Nominal supply voltage (Vsup)5 V
surface mountYES
Temperature levelINDUSTRIAL
Terminal formGULL WING
Terminal pitch0.8 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
width5.4 mm
For brush motors
H-bridge drivers
(7V max.)
BD6210, BD6211, BD6212, BD6215, BD6216, BD6217
Overview
These H-bridge drivers are full bridge drivers for brush motor applications. Each IC can operate at a wide range of power
supply voltages (from 3V to 36V), supporting output currents of up to 2A. MOS transistors in the output stage allow for
PWM signal control, while the integrated VREF voltage control function of previous models offers direct replacement of
deprecated motor driver ICs. These highly efficient H-bridge driver ICs facilitate low-power consumption design.
No.09007ECT01
Features
1) Built-in, selectable one channel or two channels configuration
2) Low standby current
3) Supports PWM control signal input (20kHz to 100kHz)
4) VREF voltage setting pin enables PWM duty control
5) Cross-conduction prevention circuit
6) Four protection circuits provided: OCP, OVP, TSD and UVLO
Applications
VCR; CD/DVD players; audio-visual equipment; optical disc drives; PC peripherals;
car audios; car navigation systems; OA equipments
Line up matrix
Rating voltage
Channels
Maximum output current
0.5A
BD6210
HFP / F
BD6215
FP
BD6220
HFP / F
BD6225
FP
BD6230
HFP / F
BD6235
FP
1.0A
BD6211
HFP / F
BD6216
FP / FM
BD6221
HFP / F
BD6226
FP / FM
BD6231
HFP / F
BD6236
FP / FM
2.0A
BD6212
HFP / FP
BD6217
FM
BD6222
HFP / FP
BD6227
FM
BD6232
HFP / FP
BD6237
FM
1ch
7V
2ch
1ch
18V
2ch
1ch
36V
2ch
*Packages; F:SOP8, HFP:HRP7, FP:HSOP25, FM:HSOP-M28
www.rohm.com
c
2009 ROHM Co., Ltd. All rights reserved.
1/16
2009.08 - Rev.C

BD6216FP-E2 Related Products

BD6216FP-E2 BD6216FM-E2 BD6217FM-E2 BD6215FP-E2
Description Brush DC Motor Controller, 1A, PDSO25, ROHS COMPLIANT, HSOP-25 Brush DC Motor Controller, 1A, PDSO28, ROHS COMPLIANT, HSOP-28 Brush DC Motor Controller, 2A, PDSO28, ROHS COMPLIANT, HSOP-28 Brush DC Motor Controller, 0.5A, PDSO25, ROHS COMPLIANT, HSOP-25
Is it Rohs certified? conform to conform to conform to conform to
Parts packaging code SOIC SOIC SOIC SOIC
package instruction HSSOP, SOP32,.3,32 HSSOP, SOP28/42,.4,32 HSSOP, SOP28/42,.4,32 HSSOP, SOP32,.3,32
Contacts 25 28 28 25
Reach Compliance Code compliant compliant compliant compliant
ECCN code EAR99 EAR99 EAR99 EAR99
Analog Integrated Circuits - Other Types BRUSH DC MOTOR CONTROLLER BRUSH DC MOTOR CONTROLLER BRUSH DC MOTOR CONTROLLER BRUSH DC MOTOR CONTROLLER
JESD-30 code R-PDSO-G25 R-PDSO-G28 R-PDSO-G28 R-PDSO-G25
length 13.6 mm 18.5 mm 18.5 mm 13.6 mm
Number of functions 1 1 1 1
Number of terminals 25 28 28 25
Maximum operating temperature 85 °C 85 °C 85 °C 85 °C
Minimum operating temperature -40 °C -40 °C -40 °C -40 °C
Maximum output current 1 A 1 A 2 A 0.5 A
Package body material PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY
encapsulated code HSSOP HSSOP HSSOP HSSOP
Encapsulate equivalent code SOP32,.3,32 SOP28/42,.4,32 SOP28/42,.4,32 SOP32,.3,32
Package shape RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR
Package form SMALL OUTLINE, HEAT SINK/SLUG, SHRINK PITCH SMALL OUTLINE, HEAT SINK/SLUG, SHRINK PITCH SMALL OUTLINE, HEAT SINK/SLUG, SHRINK PITCH SMALL OUTLINE, HEAT SINK/SLUG, SHRINK PITCH
Peak Reflow Temperature (Celsius) NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
power supply 5 V 5 V 5 V 5 V
Certification status Not Qualified Not Qualified Not Qualified Not Qualified
Maximum supply current (Isup) 1.7 mA 1.7 mA 1.7 mA 1.7 mA
Maximum supply voltage (Vsup) 5.5 V 5.5 V 5.5 V 5.5 V
Minimum supply voltage (Vsup) 3 V 3 V 3 V 3 V
Nominal supply voltage (Vsup) 5 V 5 V 5 V 5 V
surface mount YES YES YES YES
Temperature level INDUSTRIAL INDUSTRIAL INDUSTRIAL INDUSTRIAL
Terminal form GULL WING GULL WING GULL WING GULL WING
Terminal pitch 0.8 mm 0.8 mm 0.8 mm 0.8 mm
Terminal location DUAL DUAL DUAL DUAL
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
width 5.4 mm 7.5 mm 7.5 mm 5.4 mm
