Aluminium Electrolytic Capacitors/GYU
Screw Terminal Type
Series:
GYU
n
Features
Endurance : +85°C 2000 h
n
Recommended Applications
n
Specifications
Category temp. range
Rated W.V. Range
Nominal Cap. Range
Capacitance Tolerance
DC Leakage Current
Dissipation Factor
Discontinued
Japan
U.S.A.
-40 to + 85°C
10 to 100 V .DC
5600 to 1000000 µ F
-25 to + 85°C
160 to 250 V .DC
1200 to 27000 µ F
Suitable for the circuits of switching power supply,computer,inverter
-10 to +30% (120Hz/+20°C)
3ﾖCV (µA) max. after 5 minutes application of rated working voltage +20°C
C:Capacitance(µF) V: W.V. (V.DC)
Please see the attached standard products list
After 2000 hours application of DC voltage with specified ripple current (< rated DC working
voltage) at +85°C, the capacitor shall meet the following limits.
Capacitance change ±20 % of initial measured value
D.F.
<150
% of initial specified value
DC leakage current
<
initial specified value
After storage for 1000hours at +85±2
°C
with no voltage applied and then being stabilized
at +20
°C,
capacitors shall meet the limits specified in ìEnduranceî.(With voltage treatment)
Endurance
Shelf Life
n
Frequency Correction Factor for Ripple Current
W.V.(V)
φD(mm)
Freq.(Hz)
10 to 50
63, 80
100
160, 200
250
36
51, 64
77, 90
36
51, 64
77, 90
36
51, 64
77, 90
36
51, 64
77, 90
36
51, 64
77, 90
50
0.95
0.97
0.98
0.92
0.94
0.96
0.90
0.93
0.95
0.80
0.86
0.90
0.71
0.83
0.85
60
0.96
0.98
0.99
0.95
0.96
0.97
0.94
0.97
0.98
0.86
0.91
0.95
0.79
0.88
0.90
120
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
300
1.02
1.01
1.01
1.06
1.05
1.03
1.06
1.04
1.02
1.07
1.05
1.05
1.09
1.07
1.05
360
1.03
1.02
1.02
1.08
1.07
1.05
1.09
1.06
1.03
1.08
1.06
1.06
1.10
1.08
1.06
1k
1.04
1.03
1.03
1.11
1.10
1.08
1.13
1.10
1.07
1.12
1.08
1.08
1.15
1.13
1.11
10k to
1.04
1.03
1.03
1.12
1.11
1.09
1.15
1.13
1.08
1.17
1.10
1.10
1.21
1.20
1.20
n
Dimensions in mm (not to scale)
P
.V.C. sleeve
M5x12
Hexagonal-bolt
Vent
L+4 max
9 max
φD
36
51
64
77
90
F
13.0
22.0
28.6
31.8
31.8
n
Mounting clamp
Type 1;
φ36
59 max
48±1
φD±1
F±1.0
Type 2
H
14
8.4
16
C
E
Type 3
120°
35
°
6
2-3.5×7
44±1
2
φ
D
10
B
A
26
m
ax
(mm)
φD
51
64
77
A
B
C
68.0 57.5
80.0
93.0 81.0 70.0
104.5 93.5 90.0
E H
max
4.4 13
5.0 13
5.0 13
φD
51
64
77
90
45
°
W
1
W
2
12
0
°
5
1
φ
D
(mm)
W1
9.0
8.0
8.0
8.0
W2
14.0
13.0
14.0
14.0
Design, Specifications are subject to change without notice. Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consulation without fail.
30
°
φD1 φD2
65.0 74.0
76.0 86.0
89.0 100.0
101.6 113.0
–
