Aluminum Electrolytic Capacitors/ MC
Snap-in Type
Series:
MC
Type :
TS
Country of Origin
Japan
U.S.A
Malaysia
n
Features
Endurance: 105°C 2000 h
n
Recommended Applications
n
Specifications
Category temp. range
Rated W.V. Range
Nominal Cap. Range
Capacitance Tolerance
DC Leakage Current
tan
δ
Frequency Correction
Factor for Ripple Current
-40 to + 105°C
200 to 250 V .DC
120 to 1500 µ F
Smoothing circuits, AC adaptor
-25 to + 105°C
400 to 450 V .DC
39 to 390 µ F
±20 % (120Hz/+20°C)
0.03 CV (µA) or 3 mA, whichever is smaller, after 5 minutes application of rated working
voltage at +20°C.
C:Capacitance(µF) V: W.V. (V.DC)
Please see the attached standard products list.
Frequency (Hz)
50
60
100
120
500
1k
10k to
0.75
0.80
0.95
1.00
1.20
1.25
1.40
Correction Factor
After 2000 hours application of DC voltage with specified ripple current (< rated DC working
voltage) at +105°C, the capacitor shall meet the following limits.
Capacitance change ±20 % of initial measured value
<
200 % of initial specified value
tan
δ
DC leakage current
<
initial specified value
After storage for 1000 hours at +105±2
°C
with no voltage applied and then being stabilized
at +20
°C,
capacitors shall meet the limits specified in Endurance.(With voltage treatment)
Please contact the factory for detailed information on test methods and standards
relating overvoltage characteristics.
Endurance
Shelf Life
Overvoltage
n
Dimensions in mm (not to scale)
(10.0) 2-φ2.0±0.1
10.0±0.1
Polarity bar
φD+1.0
max
P
.V.C. sleeve
Vent
L+2.0 max
Recommended PWB piercing plan
i
(Standard terminal type)
0.8
-
0.1
+0.2
Terminal
0.8
-
0.1
+0.2
i
4.0±0.5
2.0 max
2.0 max
(t= 0.8)
i
6.3±1.0
(3.5)
Bottom of can
(4.0)
Bottom of can
1.5 ± 0.2
1.5±0.2
Standard terminal type does not require
terminal trimming process.
Design, and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase
and / or use. Should a safety concern arise regarding this product,please be sure to contact us immediately.
—
EE166
—
Aluminum Electrolytic Capacitors/MC
n
Standard Products
W.V.
(V)
Cap.
(±20%)
Case size
Specification
Part No.
Min.
PackagingQ'ty
(µF)
180
220
270
(Standard Terminals)
Dia. Length Ripple
tan
δ
current
Terminal Length
Terminal Length
(120Hz) (120Hz)
6.3mm
4.0mm
(+105°C) (+20°C)
(Without P.V.C.plate) (Without P.V.C.plate)
(mm) (mm)
(A)
(pcs)
200
200
200
200
200
100
200
200
100
200
200
100
200
200
100
200
100
100
200
100
100
100
100
100
100
100
100
200
200
200
200
200
200
200
100
200
200
100
200
200
100
200
22
22
25
22
25
30
25
30
25
35
30
25
40
30
25
45
35
30
50
40
30
45
35
30
50
40
30
45
35
50
40
45
50
25
30
25
35
30
40
30
25
45
35
30
50
40
30
45
0.90
1.00
1.00
1.10
1.10
1.10
1.20
1.20
1.20
1.30
1.30
1.30
1.40
1.40
1.40
1.50
1.50
1.50
1.70
1.70
1.70
2.00
2.00
2.20
2.20
2.30
2.50
0.70
0.80
0.80
0.90
0.90
1.00
1.00
1.00
1.10
1.10
1.10
1.20
1.20
1.20
1.30
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
ECES2DC181BB ECEC2DC181BB
ECES2DC221BB ECEC2DC221BB
ECES2DC221CB ECEC2DC221CB
ECES2DC271BB ECEC2DC271BB
ECES2DC271CB ECEC2DC271CB
ECES2DC271DB ECEC2DC271DB
ECES2DC331BB ECEC2DC331BB
ECES2DC331CB ECEC2DC331CB
ECES2DC331DB ECEC2DC331DB
ECES2DC391BB ECEC2DC391BB
ECES2DC391CB ECEC2DC391CB
ECES2DC391DB ECEC2DC391DB
ECES2DC471BB ECEC2DC471BB
ECES2DC471CB ECEC2DC471CB
ECES2DC471DB ECEC2DC471DB
ECES2DC561CB ECEC2DC561CB
ECES2DC561DB ECEC2DC561DB
ECES2DC561EB ECEC2DC561EB
ECES2DC681CB ECEC2DC681CB
ECES2DC681DB ECEC2DC681DB
ECES2DC681EB ECEC2DC681EB
ECES2DC821DB ECEC2DC821DB
ECES2DC821EB ECEC2DC821EB
ECES2DC102DB ECEC2DC102DB
ECES2DC102EB ECEC2DC102EB
ECES2DC122EB ECEC2DC122EB
ECES2DC152EB ECEC2DC152EB
ECES2EC121BB ECEC2EC121BB
ECES2EC151BB ECEC2EC151BB
ECES2EC151CB ECEC2EC151CB
ECES2EC181BB ECEC2EC181BB
ECES2EC181CB ECEC2EC181CB
ECES2EC221BB ECEC2EC221BB
ECES2EC221CB ECEC2EC221CB
ECES2EC221DB ECEC2EC221DB
ECES2EC271BB ECEC2EC271BB
ECES2EC271CB ECEC2EC271CB
ECES2EC271DB ECEC2EC271DB
ECES2EC331BB ECEC2EC331BB
ECES2EC331CB ECEC2EC331CB
ECES2EC331DB ECEC2EC331DB
ECES2EC391CB ECEC2EC391CB
330
22
25
30
390
22
25
30
470
200
560
22
25
30
25
30
35
680
25
30
35
820
1000
1200
1500
120
150
180
220
250
270
30
35
30
35
35
35
22
22
25
22
25
22
25
30
22
25
30
330
22
25
30
390
25
