U20 SERIES
DC/DC MODULES
Model Number
U20-12S5
U20-12S12
U20-12S15
U20-12D12
U20-12D15
U20-12D5
U20-12S3.3
U20-48S5
U20-48S12
U20-48S15
U20-48D12
U20-48D15
U20-48D5
U20-48S3.3
V
In
9-36 VDC
9-36 VDC
9-36 VDC
9-36 VDC
9-36 VDC
9-36 VDC
9-36 VDC
18-72 VDC
18-72 VDC
18-72 VDC
18-72 VDC
18-72 VDC
18-72 VDC
18-72 VDC
V
Out
5.0 VDC
12.0 VDC
15.0 VDC
±12.0 VDC
±15.0 VDC
±5.0 VDC
3.3 VDC
5.0 VDC
12.0 VDC
15.0 VDC
±12.0 VDC
±15.0 VDC
±5.0 VDC
3.3 VDC
I
Out
4000.0 mA
1670.0 mA
1330.0 mA
±833.0 mA
±666.0 mA
±2000.0 mA
4000.0 mA
4000.0 mA
1670.0 mA
1330.0 mA
±833.0 mA
±666.0 mA
±2000.0 mA
4000.0 mA
I
No Load
15.0 mA
15.0 mA
15.0 mA
20.0 mA
20.0 mA
20.0 mA
15.0 mA
10.0 mA
10.0 mA
10.0 mA
15.0 mA
15.0 mA
15.0 mA
10.0 mA
I
Full Load
1029.0 mA
1006.0 mA
1004.0 mA
1004.0 mA
1004.0 mA
1004.0 mA
705.0 mA
508.0 mA
497.0 mA
496.0 mA
496.0 mA
496.0 mA
496.0 mA
353.0 mA
Eff
81%
83%
83%
83%
83%
83%
78%
82%
84%
84%
84%
84%
84%
78%
Case
U
U
U
U
U
U
U
U
U
U
U
U
U
U
• Servers, Switches and Data Storage
• Wireless Communications
• Distributed Power Architecture
• Semiconductor Test Equipment
Applications
• Networking Gear
• Data Communications
• Telecommunications
• Industrial / Medical
The U20 Families of high efficiency DC/DC converters offer power levels of up to 20 Watt, which exceeds that of other bricks with the same Industry-Standard Pinouts, while providing much smaller
footprints. With a ultra- wide input voltage range and single and multi-outputs, ranging from 3.3 to ±15 Volts, these converters provide versatility without sacrificing the board space. All models
feature an input filter, input undervoltage lockout, output current limiting and short circuit protection. The fully enclosed, encapsulated construction achieves very efficient heat transfer with no hot
spots. All converters combine creative design practices with highly derated power devices to achieve very high reliability, high performance and low cost solution to systems designers.
Approval Pending
Specifications & Features Summary
Typical at Ta= +25 ºC under nominal line voltage and 75% load conditions, unless noted. The information and specifications
contained in this brief are believed to be accurate and reliable at the time of publication. Specifications are subject to change without
notice. Refer to product specification sheet for performance characteristics and application guidelines.
Consult factory for hundreds of other available input/output voltage configurations.
Input Specifications
Input Voltage Range
Input Filter
Positive Logic Remote ON/OFF Control
Output Specifications
Voltage Accuracy Single Output
Voltage Accuracy Dual + Output
Voltage Accuracy Dual - Output
Voltage Balance, Dual Output at Full Load
Transient Response
Single 25% Step Load Change
Dual FL, 1/2L +/- 1% Error Band
External Trim Adj. Range
Ripple and Noise 20MHz BW
Temperature Coefficient
Short Circuit Protection
Line Regulation
1
, Single Dual / Output
Load Regulation
2
, Single Dual / Output
General Specifications
Efficiency
Isolation Capacitance
Isolation Resistance
Switching Frequency
Operating Temperature Range
Derating, Above 60
o
C
Case Temperature
Storage Temperature Range
EMI / RFI
Dimensions
Case Material
Notes
1
2
3
Measured From High Line to Low Line
Measured From Full Load to 1/4 Load
Remote On/Off Control :
ON > +5.5VDC or Open Circuit
OFF < 1.8VDC
Control Common---Referenced to input minus
12V Nominal: 9-36Vin
48V Nominal: 18-72Vin
Pi Type
See Note 3
+/-1.0% max.
+/-1.0% max.
+/-2.0% max.
+/-1.0% max.
<500u sec.
<500u sec.
+/-10%
20mV RMS, max.
75mV p-p. max.
+/-0.02% /
o
C max.
Continuous
+/-0.5% max.
+/-0.5% max.
See Table
1500 VDC min.
10
8
ohms min.
300KHz, typ
-25
o
C to +71
o
C
Linearly to Zero Power at +100
o
C
100
o
C max.
-55
o
C to +105
o
C
Six sided Continuous Shield
2X1.6X0.45 inches
(50.8 X 40.64 X 11.43 mm)
Black Coated Copper with Non-Conductive
Base
Pin #
1
3
4
5
6
7
8
• 1500V, 10MΩ input-to-output isolation
• No airflow or heatsink required
• Enclosed six-sided metal shield construction for low EMI/RFI
• Efficiency 84%
• 4:1 Input Range
• Pi Input Filter
• Continuous Short Circuit Protection
• Meets EN55022 Class A, Conducted
• Remote On/Off Control
• Delivers up to 20W in 2”x1.6” package with Industry-Standard Pinouts
BOTTOM VIEW
U20 FAMILY
4
0.60
[15.24]
8
0.40
[10.16]
1.60
[40.64]
7
6
0.80
[20.32]
0.40
[10.16]
3
0.40
[10.16]
0.30
[7.62]
1
5
0.20
[5.08]
0.10
[2.54]
1.80
[45.72]
2.00
[50.80]
0.20
[5.08]
SIDE VIEW
0.45
[11.43]
U20 S(ingle)
On/Off
Vin -
Vin +
Trim
Vout -
Vout +
No Pin
U20 D(ual)
On/Off
Vin -
Vin +
Trim
Vout -
Common
Vout +
Tolerances
Inches
•
XX ±0.040
•
XXX ±0.010
All dimensions are in inches [mm]
All pins are dia. 0.040 [1.02]
Pin material: Gold plated Brass
Intronics Power Inc. 1400 Providence Highway, Building 2, Norwood, MA 02062-5015 Phone: 1-781-551-5500 Fax: 1-781-551-5555 Rev. B
•
•
