GI1-1200GP thru GI1-1600GP
New Product
Vishay Semiconductors
formerly General Semiconductor
Miniature High Voltage
Glass Passivated Rectifier
DO-204AC (DO-15)
0.034 (0.86)
0.028 (0.71)
Dia.
Reverse Voltage
1200 to 1600 V
Forward Current
1.0 A
Features
• Plastic package has Underwriters Laboratory
Flammability Classification 94V-0.
• High temperature metallurgically bonded construction
• Cavity-free glass passivated junction
• 1.0 ampere operation at T
A
=75°C with no thermal runaway
• Typical I
R
less than 0.1µA
• Hermetically sealed package
• Capable of meeting environmental standards of
MIL-S-19500
• High temperature soldering guaranteed: 350°C/10 seconds,
0.375" (9.5mm) lead length, 5 lbs. (2.3kg) tension
1.0 (25.4)
min.
ed*
nt
ate
P
0.140 (3.6)
0.104 (2.6)
Dia.
0.300 (7.6)
0.230 (5.8)
Mechanical Data
Case:
JEDEC DO-204AC, molded plastic over glass body
Terminals:
Plated axial leads, solderable per
MIL-STD-750, Method 2026
Polarity:
Color band denotes cathode end
Mounting Position:
Any
Weight:
0.015 oz., 0.4 g
®
1.0 (25.4)
min.
*
Glass-plastic encapsulation technique is covered by
Patent No. 3,996,602 and brazed-lead assembly by Patent No. 3,930,306.
Maximum Ratings & Thermal Characteristics
Parameter
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
0.375” (9.5mm) lead length at T
A
=75°C
Peak forward surge current 8.3ms single half sine-wave
superimposed on rated load (JEDEC Method)
Typical thermal resistance
(1)
Ratings at 25°C ambient temperature unless otherwise specified.
Symbol
V
RRM
V
RMS
V
DC
I
F(AV
)
I
FSM
R
ΘJA
T
J
,T
STG
GI1-1200GP
1200
840
1200
GI1-1400GP
1400
980
1400
1.0
30
55
-65 to +175
GI1-1600GP
1600
1120
1600
Unit
V
V
V
A
A
°C/W
°C
Operating junction and storage temperature range
Electrical Characteristics
Parameter
Maximum instantaneous forward voltage
Maximum DC reverse current
at rated DC blocking voltage
Maximum reverse recovery time
at I
F
=0.5A, I
R
=1.0A, I
rr
=0.25A
Ratings at 25°C ambient temperature unless otherwise specified.
Symbol
at 1.0A
at 3.14A
T
A
= 25°C
T
A
=100°C
typical
maximum
V
F
I
R
t
rr
t
rr
t
fr
C
J
GI1-1200GP
GI1-1400GP
1.1
1.3
10
100
25
0.7
1.5
1.0
15
GI1-1600GP
Unit
V
µA
µs
µs
µs
pF
Maximum reverse recovery time at I
FM
=20mA, I
RM
=2mA
Maximum forward recovery time at I
FM
=20mA
Typical junction capacitance at 4.0V, 1MHz
Notes:
(1) Thermal resistance from junction to ambient at 0.375” (9.5mm) lead length, P.C.B. mounted
Document Number 88622
03-Jan-03
www.vishay.com
1
GI1-1200GP thru GI1-1600GP
Vishay Semiconductors
formerly General Semiconductor
Ratings and
Characteristic Curves
(T
A
= 25°C unless otherwise noted)
Fig. 1 – Forward Current
Derating Curve
1.5
50
Fig. 2 – Maximum Non-Repetitive
Peak Forward Surge Current
Peak Forward Surge Current (A)
8.3ms Single Half Sine-Wave
(JEDEC Method)
T
A
= 25°C
No Load
Condition
Average Forward Rectified Current (A)
1.25
1.0
60 H
Z
Resistive
or Inductive Load
0.375" (9.5mm) Lead Length
40
30
0.75
Ipk / I
AV
=
π
20
T
J
= T
J
max.
Rated Load
Conditions
0.5
Capacitance Load
5.0
10
20
20
40
60
80
100
120
140
160
180
10
0.25
0
0
1
10
100
Ambient Temperature (°C)
Number of Cycles at 60 H
Z
Fig. 3 – Typical Instantaneous
Forward Characteristics
10
Fig. 4 – Typical Reverse
Characteristics
10
Instantaneous Forward Current (A)
Instantaneous Reverse Leakage
Current (µA)
T
J
= 150°C
1
T
J
= 25°C
Pulse Width = 300µs
1% Duty Cycle
T
J
= 125°C
1
T
J
= 75°C
0.1
0.1
T
J
= 25°C
0.01
0.4
0.6
0.8
1.0
1.2
1.4
1.6
0.01
0
20
40
60
80
100
Instantaneous Forward Voltage (V)
Percent of Rated Peak Reverse Voltage (%)
Fig. 5 – Typical Junction
Capacitance
30
T
J
= 25°C
f = 1.0MH
Z
Vsig = 50MVp-p
10
Junction Capacitance (pF)
1
1
10
100
Reverse Voltage (V)
www.vishay.com
2
Document Number 88622
03-Jan-03
