Tri-State Enable/Disable 3.3V Oscillator
Model: F5c-2E3lF Series
RoHS compliant / Pb Free
FEATURES
•
•
•
•
Rev. 9/18/2006
http://www.foxonline.com/need_a_sample.htm
3.3V Operation
HCMOS Output
Tri-State Enable/Disable
14-Pin DIP
OPTiOnS
• 8-Pin DIP Available (H5C-2E3LF)
• PART nUMbER SElEcTiOn
Learn More - Internet Required
Part Number
148LF-Freq-xxxxx
355LF-Freq-xxxxx
328LF-Freq-xxxxx
356LF-Freq-xxxxx
329LF-Freq-xxxxx
358LF-Freq-xxxxx
567LF-Freq-xxxxx
Model Number
F5C-2E3LF
F5C-2E3RLF
F6C-2E3LF
F6C-2E3RLF
F7C-2E3LF
F7C-2E3RLF
F8C-2E3LF
learn more about:
Part Marking Identification
Mechanical Specification
internet required
Frequency
Frequency
Operating
1
Stability Temperature(ºC) Range (MHz)
1.000~160.000
±100PPM
0 ~ +70
1.000~160.000
±100PPM
-40 ~ +85
1.000~160.000
±50PPM
0 ~ +70
1.000~160.000
±50PPM
-40 ~ +85
1.000~160.000
±25PPM
0 ~ +70
1.000~125.000
±25PPM
-40 ~ +85
1.000~125.000
±20PPM
0 ~ +70
• ElEcTRicAl cHARAcTERiSTicS
Frequency Range (F
o
)
Storage Temperature Range (T
stg
)
Supply Voltage
(V
dd
)
Input Current
(I
dd
)
1.000 ~ 23.999 MHz
24.000 ~ 49.999 MHz
50.000 ~ 69.999 MHz
70.000 ~ 125.000 MHz
125.000 ~ 160.000 MHz
Output Symmetry (50% V
dd
)
Rise Time (10% ~ 90% V
dd
) (T
r
)
Fall Time (90% ~ 10% V
dd
) (T
f
)
Output Voltage
(V
ol
)
(V
oh
)
Output Current
(I
ol
)
(I
oh
)
Output Load
(HCMOS)
Start-up Time
(T
s
)
Output Enable/Disable Time
2
1
PARAMETERS
MAX
(unless otherwise noted)
1.000 ~ 160.000 MHz
-55ºC ~ +125ºC
3.3V ± 10%
15mA
20mA
40mA
45mA
60mA
40% ~ 60%
10 nS
10 nS
10% V
dd
90% V
dd
Min
8mA Min
-8mA Min
15pF
10mS
100nS
All dimensions are in millimeters.
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration.
2
An internal pullup resistor from pin 1 to V
DD
allows active output if pin 1 is left open.
All specifications subject to change without notice.
• EnAblE / DiSAblE FUncTiOn
INH (Pin 1)
OUTPUT (Pin 8)
OPEN
2
ACTIVE
'1' Level V
ih
≥
2.2 V
ACTIVE
'0' Level V
il
≤
0.8 V
High Z
EMEA
Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282 |
Taiwan
Tel: +886.2.22073427 Fax +886.2.22073486
|
Japan
Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
© 2006 FOX ELECTRONICS | ISO9001:2000 Certified
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
