HCMOS, 7.5x5mm, 2.5V, SMD Oscillator
Model: F4400 SERIES
Page 1 of 2
RoHS Compliant / Pb Free
Rev. 2/25/2008
http://www.foxonline.com/need_a_sample.htm
FEATURES
•
•
•
•
•
2.5V Operation
HCMOS Output
Low Power Consumption
Standby Function
Tape and Reel
(2,000 pcs. STD)
XpressO
®
Equivalent
FXO-HC72
Why XpressO?
Lower Cost, Faster Delivery, Low Jitter!
• PART nUMbER SELECTIOn
Learn More - Internet Required
Part Number
521-Frequency-xxxxx
522-Frequency-xxxxx
523-Frequency-xxxxx
524-Frequency-xxxxx
525-Frequency-xxxxx
526-Frequency-xxxxx
527-Frequency-xxxxx
Model Frequency
Number Stability
1
F4400
±100PPM
F4400R
±100PPM
F4405
±50PPM
F4405R
±50PPM
F4406
±25PPM
F4406R
±25PPM*
F4408
±20PPM*
Operating
Temperature (ºC)
-10 ~ +70
-40 ~ +85
-10 ~ +70
-40 ~ +85
-10 ~ +70
-40 ~ +85
-10 ~ +70
Frequency
Range (MHz)
1.800 ~ 125.000
1.800 ~ 125.000
1.800 ~ 125.000
1.800 ~ 125.000
1.800 ~ 65.000
1.800 ~ 50.000
1.800 ~ 50.000
• ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (F
o
)
Storage Temperature Range (T
stg
)
Supply Voltage
(V
dd
)
Input Current
(I
dd
)
1.800 ~ 32.100 MHz
32.100+ ~ 50.000 MHz
50.000+ ~ 125.000 MHz
Output Symmetry (50% V
dd
)
Rise Time (10% ~ 90% V
dd
) (T
r
)
Fall Time (90% ~ 10% V
dd
) (T
f
)
Output Voltage
(V
ol
)
(V
oh
)
Output Current
(I
ol
)
(I
oh
)
Output Load
(HCMOS)
Standby Current
Start-up Time
(T
s
)
Output Disable Time
2
Output Enable Time
2
1
MAX
(unless otherwise noted)
1.800 ~ 125.000 MHz
-55ºC ~ +125ºC
2.5V ± 5%
10mA
12mA
60mA
45% ~ 55%
5nS
5nS
10% V
dd
90% V
dd
Min
4mA Min
4mA Min
15pF
10µA
10mS
150nS
10mS
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration. *Excludes Shock/Vibration
2
An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.
Note: A 0.01µF bypass capacitor should be placed between VDD (Pin 4) and GND (Pin 2) to
minimize power supply line noise.
Drawing is for reference to critical specifications defined by size measurements.
Certain non-critical visual attributes, such as side castellations, reference pin shape, etc. may vary.
All specifications subject to change without notice.
All dimensions are in millimeters.
• EnAbLE / DISAbLE FUnCTIOn
INH (Pin 1)
OUTPUT (Pin 3)
OPEN
2
ACTIVE
'1' Level V
ih
≥
70% V
dd
ACTIVE
'0' Level V
il
≤
30% V
dd
High Z
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
© 2008 FOX ELECTRONICS | ISO9001:2000 Certified
EMEA
Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282
|
Japan
Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
HCMOS, 7.5x5mm, 2.5V, SMD Oscillator
Model: F4400 SERIES
Page 1 of 2
RoHS Compliant / Pb Free
Rev. 2/25/2008
http://www.foxonline.com/need_a_sample.htm
• TAPE SPECIFICATIOnS
(millimeters)
MODEL
F4400 Series
• REEL SPECIFICATIOnS
(millimeters)
G H
I
J
K
L M
2.0
∅13 ∅21 ∅80 ∅255
17.5 2.0
b
C D E
F
STD Reel QTY
MODEL
A
F4400 Series
2,000
∅1.5
4.0 8.0 7.5 16.0 2.15
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
© 2008 FOX ELECTRONICS | ISO9001:2000 Certified
EMEA
Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282
|
Japan
Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
