Product – Specification
TYPE MSC15 SERIES
3
rd
February 2004
ISSUE 2
RF Inductor Moulded
TYPE MSC15 SERIES
The Sigma MSC15 is a fully moulded sister to the well
known SC10 and SC15 series. The characteristics,
Tolerance, Q, SRF and DC resistance mirror almost the
SC10/SC15. The current carrying capacity is similar
although the specification is slightly derated due to the
higher measuring temperature. This fully moulded and
colour banded construction provides excellent
environmental protection at a surprisingly attractive
price.
KEY FEATURES
•
•
•
•
•
•
•
Fully Moulded Construction
Colour Banded Coding
Rugged Moulded Construction
Wide Inductance R10 - 1000µH
±5%
Selection Tolerance
Attractively Priced
Special Designs Welcome
STOCKISTS:
This product is not stocked in Distribution.
Telephone Tyco Passive Product Support Team ++ 44 (0) 1793 572484
Website – passives.tycoelectronics.com
Email – passivesales@tycoelectronics.com
Page 1 of 3
Product – Specification
TYPE MSC15 SERIES
ELECTRICAL
Construction:
Max. Operating Temperature:
Max. Temperature Rise:
Ambient Temperature:
Dielectric Withstand:
Lead Pull Strength:
Inductance Value Range:
Phenolic LT4 Grade1 Class B
Powdered iron & ferrite LT10 Grade 1 Class A
Phenolic -55°C to +125°C
Powdered Iron & ferrite -55°C to +105°C
Phenolic 35°C
Powdered Iron & ferrite 15°C
90°C
Sea Level 1000V. RMS
2.27 kg
Phenolic 0.1µh - 1µh
Powdered Iron 1.1µh - 27µh
Ferrite 30µh - 1000
µh
0.5g max.
3
rd
February 2004
ISSUE 2
Weight:
DIMENSIONS
•
•
Manufactured to meet BS9751 N0001 pattern A but released to commercial standard.
Colour banded in accordance with MIL - C - 15305
All Dimensions are nominal
and in mm. unless otherwise
shown. Do Not Scale.
HOW TO ORDER
MSC15
COMMON PART
MSC15 – Moulded
Wound Inductor
220
INDUCTANCE VALUE
See Table on Page 3
K
TOLERANCE
K – 10%
R
PACK STYLE
R – Reeled 1000
This publication is issued to provide outline information only and (unless specifically agreed to the contrary by the Company in writing) is not to form part of any order or be
regarded as a representation relating to the products or service concerned. We reserve the right to alter without notice the specification, design, price or conditions of
supply of any product or service. Whilst Tyco Electronics Components products are of the very highest quality and reliability, all electronic components can occasionally
be subject to failure. Where failure of a Tyco Electronics Components product could result in life threatening consequences, then the circuit and application must
be discussed with the Company. Such areas might include ECG, respiratory and other medical and nuclear applications and any non fail-safe applications circuit.
Telephone Tyco Passive Product Support Team ++ 44 (0) 1793 572484
Website – passives.tycoelectronics.com
Email – passivesales@tycoelectronics.com
Page 2 of 3
Product – Specification
TYPE MSC15 SERIES
3
rd
February 2004
ISSUE 2
Inductance
Code
R15
R22
R33
R47
R56
R68
R82
1R0
1R2
1R5
1R8
2R2
2R7
3R3
3R9
4R7
5R6
6R8
8R2
100
120
150
180
220
270
330
360
390
430
470
510
560
620
680
750
820
910
101
111
121
131
151
161
181
201
221
241
271
301
331
361
391
431
471
511
561
621
681
751
821
911
102
Inductance
µH
0.15±20%
0.22±20%
0.33±20%
0.47±20%
0.56±10%
0.68±10%
0.82±10%
1.00±10%
1.20±10%
1.50±10%
1.80±10%
2.20±10%
2.70±10%
3.30±10%
3.90±10%
4.70±10%
5.60±10%
6.80±10%
8.20±10%
10.00±10%
12.00±10%
15.00±10%
18.00±10%
22.00±10%
27.00±10%
33.00±10%
36.00±5%
39.00±5%
43.00±5%
47.00±5%
51.00±5%
56.00±5%
62.00±5%
68.00±5%
75.00±5%
82.00±5%
91.00±5%
100.0±5%
110.0±5%
120.0±5%
130.0±5%
150.0±5%
160.0±5%
180.0±5%
200.0±5%
220.0±5%
240.0±5%
270.0±5%
300.0±5%
330.0±5%
360.0±5%
390.0±5%
430.0±5%
470.0±5%
510.0±5%
560.0±5%
620.0±5%
680.0±5%
750.0±5%
820.0±5%
910.0±5%
1000.0±5%
Q
Min.
50
50
45
45
50
50
50
50
33
33
33
33
33
33
33
33
45
50
50
55
65
65
75
75
60
65
60
60
60
55
55
55
55
55
55
50
50
50
60
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
65
Test Freq.
(L&Q) MHz
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
SRF (Min)
MHz
525
450
360
310
280
250
220
200
180
160
150
135
120
110
100
90
60
55
50
45
42
40
34
30
25
19
15.5
14.5
13.7
13.0
12.7
12.0
11.5
11.0
10.5
10.3
10.0
9.5
8.9
8.7
8.5
8.0
7.5
7.0
6.5
6.2
5.9
5.7
5.4
5.1
4.8
4.5
4.2
3.9
3.8
3.7
3.3
3.1
2.9
2.7
2.5
2.3
DCR (Max)
ohms
0.03
0.055
0.09
0.12
0.135
0.15
0.22
0.29
0.42
0.50
0.65
0.95
1.20
2.00
2.30
2.60
0.32
0.50
0.60
0.90
1.10
1.40
2.25
2.50
2.60
3.00
2.50
2.60
2.70
2.75
2.85
3.00
3.15
3.30
3.70
3.90
4.30
4.50
4.90
5.20
5.45
6.05
6.40
6.75
7.10
7.45
7.80
11.0
11.5
12.0
12.5
16.3
17.1
17.9
18.8
19.5
25.9
27.2
28.6
30.0
31.5
33.0
Rated DC Current mA
at 90°C
2450
1900
1400
1225
1220
1100
900
830
650
600
525
435
385
300
280
260
495
395
360
290
265
240
185
175
170
165
180
176
172
170
167
164
160
156
147
143
136
133
128
124
121
114
111
108
106
103
101
85
83
81
80
70
68
67
65
64
55
54
53
52
50
49
35°C Rise
750
600
545
445
404
370
280
265
260
250
245
240
230
220
200
185
175
165
155
145
Telephone Tyco Passive Product Support Team ++ 44 (0) 1793 572484
Website – passives.tycoelectronics.com
Email – passivesales@tycoelectronics.com
Page 3 of 3
