015-38-8099: Description9 CONTACT(S), FEMALE, FFC/FPC CONNECTOR, CRIMP; CategoryThe connector The connector; File Size142KB，3 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric Compare View All

015-38-8099 Overview

9 CONTACT(S), FEMALE, FFC/FPC CONNECTOR, CRIMP

015-38-8099 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Molex
Reach Compliance Code	unknown
Is Samacsys	N
Other features	SL
Connector type	FFC/FPC CONNECTOR
Contact to complete cooperation	TIN (150)
Contact completed and terminated	Tin (Sn)
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e3
MIL compliance	NO
Mixed contacts	NO
Installation type	CABLE
Number of rows loaded	1
Options	GENERAL PURPOSE
Termination type	CRIMP
Total number of contacts	9
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

This document was generated on 05/18/2010

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMA

Part Number:

Status:

Overview:

Description:

Documents:

3D Model

Drawing (PDF)

0015388099

Active

cgrid__sl_products

2.54mm (.100") C-Grid SL™ Single Row, Female, Version D Receptacle, 9 Circuits

Product Specification PS-70430 (PDF)

RoHS Certificate of Compliance (PDF)

Agency Certification

CSA

UL

LR19880

E29179

General

Product Family

Series

Comments

Overview

Product Name

FFC/FPC Connectors

70430

Stackable Back-to-Back

cgrid__sl_products

SL™

Physical

Circuits (Loaded)

Color - Resin

Contact Position

Durability (mating cycles max)

Entry Angle

Flammability

Material - Metal

Material - Plating Mating

Material - Plating Termination

Material - Resin

Number of Rows

Orientation

PCB Retention

Packaging Type

Pitch - Mating Interface (in)

Pitch - Mating Interface (mm)

Plating min: Mating (µin)

Plating min: Mating (µm)

Plating min: Termination (µin)

Plating min: Termination (µm)

Polarized to PCB

Stackable

Temperature Range - Operating

Termination Interface: Style

Wire/Cable Type

9

Black

N/A

25

Vertical

94V-0

Phosphor Bronze

Tin

Polyester Alloy

1

Vertical

None

Tube

0.100 In

2.54 mm

150

3.75

75

1.875

No

Yes

-40°C to +105°C

IDT or Pierce

FFC/FPC

EU RoHS

ELV and

Complia

REACH S

Not Revi

Halogen

Status

Not Revi

Need mo

environm

Email pro

For a mu

Complian

Please vi

non-prod

Search

70430S

Mates

70004

Electrical

Current - Maximum per Contact

Voltage - Maximum

1A, 2A

250V

Material Info

Old Part Number

70430-0078

Reference - Drawing Numbers

Product Specification

Sales Drawing

PS-70430

SDA-70430-0071-0094

Applic

Tooling

found b

Crimp H

contain

Specifi

Global

Descri

Manua

Cable C

Tool

Tool Ki

Manua

Standa

Press f

TM-42™

SL™ T
