Cover (HIF3B Series) against EMI (Electromagnetic Interference)
sFeatures
1. Electromagnetic Shielding Effect
This product enhances shielding effects with a metallic cover
over the ribbon cable connector (HIF3B series).
sApplications
Peripheral and termination equipment, control machines, measuring
instruments etc.
sOrdering
Information
2. Screw Locking Mechanism
The locking mechanism is designed in a stubborn and
steady structure for the screw type.
3. Assembling
The ribbon cable connector (HIF3B series) can be easily
assembled.
HIF 3 -
*
CVFA
q
q
Series Name
e
CVFA
: HIF 3
: Cover case for EMI
w
e
w
Number of contacts : 10, 16, 20, 26, 30, 34, 40, 50, 64
sI/O
Cable Termination
sMaterial
Material
Zinc alloy
Finish
Nickel plated
As shown above, bend the shield knitted cord, wind
the conductive tape 1 to 2 turns, and finish cable
termination so as not to loosen the shield knitted cord.
B45
sCover
Unit : mm
Part Number
HIF3-10CVFA
HIF3-16CVFA
HIF3-20CVFA
HIF3-26CVFA
HIF3-30CVFA
HIF3-34CVFA
HIF3-40CVFA
HIF3-50CVFA
HIF3-64CVFA
CL No.
612-0061-4
612-0062-7
612-0063-0
612-0064-2
612-0065-5
612-0066-8
612-0067-0
612-0068-3
612-0070-5
Number of Contacts
10
16
20
26
30
34
40
50
64
A
8.5
7.8
9.0
10.0
9.2
11.0
13.0
14.5
15.4
B
8.0
7.8
8.5
9.5
9.2
10.0
10.0
10.0
10.0
C
31.7
34.9
39.98
47.6
52.68
57.76
65.38
78.08
D
E
38.12 17.52
41.32 25.14
46.4
59.1
71.8
84.5
30.22
42.92
55.62
68.32
86.1
54.02 37.84
64.18 48.0
95.86 102.7
B46
sApplicable
Socket Connector
Notes1 and 2: The number of polarizing guide and keys change according to products.
Unit : mm
Part Number
HIF3BA-10D-2.54R-CL(21)
HIF3BA-16D-2.54R-CL(21)
HIF3BA-20D-2.54R-CL(21)
HIF3BA-26D-2.54R-CL(21)
HIF3BA-30D-2.54R-CL(21)
HIF3BA-34D-2.54R-CL(21)
HIF3BA-40D-2.54R-CL(21)
HIF3BA-50D-2.54R-CL(21)
HIF3BB-50D-2.54R-CL(21)
HIF3BA-64D-2.54R-CL(21)
HIF3BB-64D-2.54R-CL(21)
CL No.
610-0190-4-21
610-0192-0-21
610-0193-2-21
610-0194-5-21
610-0195-8-21
610-0196-0-21
610-0197-3-21
610-0198-6-21
610-0201-9-21
610-0200-6-21
610-0203-4-21
Number of Contacts
10
16
20
26
30
34
40
50
50
64
64
A
B
C
D
Polarizing guide
Polarizing keyway
One at center
17.27 10.16 11.43 12.8
24.89 17.78 19.05 20.42
29.97 22.86 24.13 25.5
37.59 30.48 31.75 33.12
42.67 35.56 36.83 38.2
47.75 40.64 41.91 43.28
55.37 48.26 49.53 50.9
68.07 60.96 62.23 63.6
68.07 60.96 62.23 63.6
85.85 78.74 80.01 81.38
One on right and left sides, resp.
One at center
One at center
One on right and left sides, resp.
One at center
85.85 78.74 80.01 81.38 One on right and left sides, resp
sPin
Header
The pin header applicable to the socket connector HIF series can wholly use the HIF3 series. It is recommended to
use following products, considering positioning (protection of mating area) when the connector is engaged.
In addition, when the connector is installed, the locking mechanism is removed. If needed, order the product (11)
according to the specification (unlock), as shown below.
HIF3B –
*PA
–2.54DS,DSA(11)
HIF3BA–
*PA
–2.54DS,DSA(11)
HIF3BB–
*PA
–2.54DS,DSA(11)
Note:
HIF3B–
*PA
–2.54DS, DSA (11) is limited
to number of contacts as follows:
DSA-20, 30, 34, 40 contacts
DSA-26, 50 contacts
B47
sRecommended
Panel catouts
Number of Contacts
10
16
20
26
30
34
40
50
64
A
B
C
10.16
17.78
30.48
D
21.8
29.5
34.5
42.2
47.2
52.3
59.9
72.6
90.4
18.52 31.7
26.14 34.9
38.84 47.6
49.0
31.22 39.98 22.86
43.92 52.68 35.56
57.76 40.64
56.62 65.38 48.26
69.32 78.08 60.96
87.1
95.86 78.74
q
Right Angle Type
HIF3B-*PA-DS(11)
HIF
3BA
-*PA-DS(11)
3BB
3.45
4.75
B48
sCover
Assembling Procedures
4
5
2
1
6
3
1
7
8
3
BAssembling
Procedures
1. Insert the connected connector (cable shield cable after termination process)
1
in the adapter metal
2,
and
connect the assembly to the cover A
3.
2. Insert the cable unit
1
in the clamp slot of cover A
3,
and mount the clamp metal
4.
Then, tighten the unit by
screws.
3. Next, place the lock screw
5
in the right slot, and mount the cover B
7
so as not to bite the cable, and tighten the
assembly by screws. At this time, check that no clearance is found between cover A and B.
B49
