Short Locking Fork Terminals, Nylon Insulated
–
Non-Funnel Entry
Type PN-SLF
• Continuously molded design provides reliable, consistent
performance through the applicator for a high quality termination
every time
• Lock in place for a secure connection in limited spaces
• Fork design provides for fast and easy installation, without the
need to remove fastener
• Metal insulation grip sleeve crimps to wire insulation, providing
protection to the crimp joint during high vibration applications
• Internal barrel serrations assure good wire contact and maximum
tensile strength
• UL Flammability UL 94V-2/HB, maximum insulation temperature
221°F (105°C)
• UL and CSA rated up to 600 V per UL 486A/B
B1.
Cable Ties
B2.
Cable
Accessories
B3.
Stainless
Steel Ties
L
C1.
Wiring
Duct
Stock
Thickness
(In.)
Max.
Ins.
(In.)
W
C
Wire
Range
22 – 18
AWG
Color
Code
Stud
Size
#5
#6
#8
#10
#5
#6
#8
#10
#8
#10
Figure Dimensions
(In.)
L
0.75
0.75
0.79
0.80
0.75
0.75
0.80
0.81
0.92
0.92
W
0.26
0.27
0.29
0.33
0.25
0.25
0.29
0.33
0.29
0.33
C
0.19
0.19
0.23
0.23
0.19
0.19
0.23
0.23
0.22
0.22
CA9
Series
Crimp Die
CA-800/EZ
Series
Crimp Die
Pieces
Per
Reel
3000
3000
3000
3000
3000
3000
3000
3000
2000
2000
C2.
Surface
Raceway
C3.
Abrasion
Protection
C4.
Cable
Management
Part Number
PN18-5SLF-3K
PN18-6SLF-3K
PN18-8SLF-3K
PN18-10SLF-3K
PN14-5SLF-3K
PN14-6SLF-3K
PN14-8SLF-3K
PN14-10SLF-3K
PN10-8SLF-2K
PN10-10SLF-2K
Red
0.03
0.145
CD9-1A
CD-800-1
16 – 14
AWG
12 – 10
AWG
Blue
0.03
0.162
CD9-2A
CD-800-2
Yellow
0.04
0.225
CD9-3B
CD-800-3
D1.
Terminals
For applicator information, see page D1.143.
Short Locking Fork Terminals, Nylon Insulated
–
Funnel Entry
Type PNF-SLF
• Continuously molded design provides reliable, consistent
performance through the applicator for a high quality termination
every time
• Lock in place for a secure connection in limited spaces
• Fork design provides for fast and easy installation, without the
need to remove fastener
• Metal insulation grip sleeve crimps to wire insulation, providing
protection to the crimp joint during high vibration applications
• Internal barrel serrations assure good wire contact and maximum
tensile strength
• UL Flammability UL 94V-2/HB, maximum insulation temperature
221°F (105°C)
• UL and CSA rated up to 600 V per UL 486A/B
D2.
Power
Connectors
D3.
Grounding
Connectors
E1.
Labeling
Systems
L
E2.
Labels
W
C
E3.
Pre-Printed
& Write-On
Markers
E4.
Permanent
Identification
E5.
Lockout/
Tagout
& Safety
Solutions
F.
Index
Part Number
PNF18-5SLF-3K
PNF18-6SLF-3K
PNF18-8SLF-3K
PNF18-10SLF-3K
PNF14-6SLF-3K
PNF14-10SLF-3K
PNF10-6SLF-2K
PNF10-8SLF-2K
PNF10-10SLF-2K
Wire
Range
Color
Code
Stock
Thickness
(In.)
Max.
Ins.
(In.)
Stud
Size
#5
#6
#8
#10
#6
Figure Dimensions
(In.)
L
0.73
0.74
0.80
0.80
0.75
0.81
0.91
0.92
0.93
W
0.26
0.27
0.29
0.33
0.25
0.33
0.25
0.29
0.33
C
0.19
0.19
0.23
0.23
0.19
0.23
0.17
0.22
0.22
CA9
Series
Crimp Die
CA-800/EZ
Series
Crimp Die
Pieces
Per
Reel
3000
3000
3000
3000
3000
22 – 18
AWG
Red
0.03
0.145
CD9-1A
CD-800-1
16 – 14
AWG
12 – 10
AWG
Blue
0.03
0.162
#10
#6
#8
#10
CD9-2A
CD-800-2
3000
2000
2000
2000
Yellow
0.04
0.225
CD9-3B
CD-800-3
For applicator information, see page D1.143.
Order number of pieces required, in multiples of Standard Package Quantity.
Prime items appear in
BOLD.
