Series 8454
60
870
1065
400
600
API Delevan’s combination of high performance Ni-Zn cores and
low capacitance type windings allow for superior frequency
characteristics.
• Only small scattered fields are generated by the windings
• Ensures excellent attenuation characteristics over a wide
frequency range
• Packaged in a flat-top (UL94V-O) header, compatible with auto
insertion equipment
Typical Applications
Data line filters; audio signal filters; current
supply choke; video signal filters.
• Sample kit available
Notes
* 1.
Insulation Voltage (VDC) is one minute line to case;
inductance measured at 1kHz/1V
2.
Impedance measurement using HP4191A
impedance analyzer.
Physical Parameters
Inches
Millimeters
A 0.260 to 0.276 6.6 to 7.0
B 0.205 to 0.228 5.2 to 5.8
C 0.071 to 0.083 1.8 to 2.1
D 0.323 to 0.339 8.2 to 8.6
E 0.091 Max.
2.3 Max.
F 0.026 to 0.037 0.65 to 0.95
G 0.102
2.6
H 0.051
1.3
I 0.363
8.8
Operating Temperature Range
–55°C to +125°C
Termination
90/10 tin-lead
Packaging
Tape & reel (8mm):
7" reel, 1000 pieces max.;
13" reel, 4000 pieces max.
2000
TYPICAL CURVES
8454-2
1800
8454-82
1600
1400
10
0M
Hz
Surface Mount
EMI/RFI Filter Chokes
IMPEDANCE
MINIMUM
SUPPRESSORS
IMPEDANCE (OHMS)
1200
1000
800
600
8454-1R5
8454-11
LAND PATTERN
DIMENSIONS
400
200
8454-1
10
100
300
FREQUENCY (MHz)
