The nominal frequency fN is fixed at 2096 MHz. The insertion loss ae is defined as loss value determined at fN. Reference level for the relative attenuation
arel of the TFS 2096A is the insertion loss ae
.
All specified data are met within the operating temperature range.
Data
Insertion loss
(reference level)
Nominal frequency
Passband
Pass band variation
Relative attenuation
0,3
862
1887,4
2190
2300
3000
MHz
MHz
MHz
MHz
MHz
MHz
...
...
...
...
...
...
862
1887,4
2000
2300
3000
6000
MHz
MHz
MHz
MHz
MHz
MHz
arel
ae
f
N
PB
typ. value
3,2
-
-
1,1
dB
f
N
dB
tolerance / limit
max.
3,7
2096,0
±
20,0
2,0
dB
MHz
MHz
dB
max.
68
49
47
36
45
35
dB
dB
dB
dB
dB
dB
min.
min.
min.
min.
min.
min.
55
40
33
25
35
15
dB
dB
dB
dB
dB
dB
Group delay ripple
2077,4
MHz ...
2114,5
MHz
3
1,8 : 1
1,8 : 1
-
-
OTR
TCf **
-
-
- 42
ppm/K
ns
max.
max.
max.
max.
10
2,4 : 1
2,4 : 1
0
V
ns
Input VSWR within PB
Output VSWR within PB
Permissible DC voltage
Operable temperature range
Operating temperature range
Storage temperature range
Temperature coefficient of frequency
- 30 °C ... + 80 °C
- 20 °C ... + 50 °C
- 50 °C ... +125 °C
-
*) The terminating impedances depend on parasitics and q-values of matching elements and the board used, and are to be understood as reference
values only. Should there be additional questions do not hesitate to ask for an application note or contact our design team.
**)
∆f(Hz)
= TCf(ppm/K) x (T-T
0
) x fTo(MHz)
Generated:
Checked / Approved:
Vectron International GmbH & Co. KG
Potsdamer Straße 18
D 14 513 TELTOW / Germany
Tel: (+49) 3328 4784-0 / Fax: (+49) 3328 4784-30
E-Mail:
tft@vectron.com
Vectron International GmbH & Co. KG reserves the right to make changes to the product(s) and/or information contained herein without
notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such
product(s) or information.
Filename: tfs 2096a.doc
Version 1.1
08.12.2009
Vectron International
Filter characteristic
insertion loss: -3.33 dB
0
-10
-20
-30
-40
-50
-60
-70
-80
-90
-100
Filter specification
TFS 2096A
2/5
0
-1
-2
-3
-4
-5
-6
-7
-8
-9
-10
2046
0.03
0.028
0.026
0.024
0.022
0.02
0.018
0.016
0.014
0.012
0.01
2146
magnitude in dB
magnitude in dB
9
608.8
1208.6
1808.4
2408.2
3008
3607.8
frequency in MHz
4207.6
4807.4
5407.2
6007
2056
2066
2076
2086
2096
2106
frequency in MHz
2116
2126
2136
Construction and pin connection
(All dimensions in mm)
N96A
●
X50
1
2
3
4
5
6
7
8
Input
Input
Ground
Ground
Output
Output
Ground
Ground
Date code:
X
A
B
...
Year + week
2009
2010
2011
150
Ω
/ 150
Ω
Test circuit
L1
150 Ohm
C1
L2
1
2
5
L2
C2
L4
150 Ohm
SAW
6
3,4,7, 8
Vectron International GmbH & Co. KG
Potsdamer Straße 18
D 14 513 TELTOW / Germany
Tel: (+49) 3328 4784-0 / Fax: (+49) 3328 4784-30
E-Mail:
tft@vectron.com
Vectron International GmbH & Co. KG reserves the right to make changes to the product(s) and/or information contained herein without
notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such
product(s) or information.
delay in µs
Filename: tfs 2096a.doc
Version 1.1
08.12.2009
Vectron International
Stability characteristics, reliability
Filter specification
TFS 2096A
3/5
After the following tests the filter shall meet the whole specification:
1. Shock:
2. Vibration:
3. Change of
temperature:
4. Resistance to
solder heat (reflow):
5. ESD
500g, 1 ms, half sine wave, 3 shocks each plane;
DIN IEC 68 T2 - 27
10 Hz to 500 Hz, 0,35 mm or 5 g respectively, 1 octave per min, 10 cycles per plan, 3 plans;
DIN IEC 68 T2 - 6
-55 °C to 125°C / 30 min. each / 10 cycles
DIN IEC 68 part 2 – 14 Test N
reflow possible: three times max.;
for temperature conditions refer to the attached "Air reflow temperature conditions" on page 4;
MIL-STD-883E using coupling network of ISO 10605 and EN 6100-4-2
HBM:250V; CDM:V;
This filter is RoHS compliant (2002/95/EG, 2005/618/EG)
Packing
Tape & Reel:
IEC 286 – 3, with exception of value for N and minimum bending radius;
tape type II, embossed carrier tape with top cover tape on the upper side;
max. pieces of filters per reel:
reel of empty components at start:
reel of empty components at start including leader:
trailer:
Pull Off Direction
9000
min. 300 mm
min. 500 mm
min. 300 mm
Tape (all dimensions in mm)
W
: 8,00 ± 0,3
Po
: 4,00 ± 0,1
Do
: 1,50 +0,1/-0
E
: 1,75 ± 0,1
F
: 3,50 ± 0,05
G(min)
: 0,75
P2
: 2,00 ± 0,05
P1
: 4,00 ± 0,1
D1(min)
: 1,50
Ao
: 3,25 ± 0,1
Bo
: 3,25 ± 0,1
Ct
: 5,5 ± 0,1
P1
Date Code
t
Do
Po
P2
E
G
Ct
Bo
F
Ko
Typ
PIN Marker
D1
Ao
W 2
Reel (all dimensions in mm)
A
: 330
W1
: 8,4 +1,5/-0
W2(max) : 14,4
N(min)
: 50
C
: 13,0 +0,5/-0,2
A
C
N
W 1
The minimum bending radius is 45 mm.
Vectron International GmbH & Co. KG
Potsdamer Straße 18
D 14 513 TELTOW / Germany
Tel: (+49) 3328 4784-0 / Fax: (+49) 3328 4784-30
E-Mail:
tft@vectron.com
Vectron International GmbH & Co. KG reserves the right to make changes to the product(s) and/or information contained herein without
notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such
product(s) or information.
G
W
Filename: tfs 2096a.doc
Version 1.1
08.12.2009
Vectron International
Air reflow temperature conditions
Filter specification
TFS 2096A
4/5
Conditions
Average ramp-up rate (30°C to 217°C)
> 100°C
> 150°C
> 217°C
Peak temperature
Time within 5°C of actual peak temperature
Cool-down rate (Peak to 50°C)
Time from 30°C to Peak temperature
Exposure
less than 3°C/second
between 300 and 600 seconds
between 240 and 500 seconds
between 30 and 150 seconds
max. 260°C
between 10 and 30 seconds
less than 6°C/second
no greater than 300 seconds
Chip-mount air reflow profile
Temperature / °C
max. 260°C
217°C
max. 300 s
10 ... 30 s
30 ... 150 s
Time / s
Vectron International GmbH & Co. KG
Potsdamer Straße 18
D 14 513 TELTOW / Germany
Tel: (+49) 3328 4784-0 / Fax: (+49) 3328 4784-30
E-Mail:
tft@vectron.com
Vectron International GmbH & Co. KG reserves the right to make changes to the product(s) and/or information contained herein without
notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such
product(s) or information.
Filename: tfs 2096a.doc
Version 1.1
08.12.2009
Vectron International
History
Version
1.0
1.1
Reason of Changes
Filter specification
TFS 2096A
5/5
Name
S. Channaa
S. Channaa
Date
28.09.2009
08.12.2009
- Generation of development specification
- Add typical values and filter characteristic
- Generation of filter specification
Vectron International GmbH & Co. KG
Potsdamer Straße 18
D 14 513 TELTOW / Germany
Tel: (+49) 3328 4784-0 / Fax: (+49) 3328 4784-30
E-Mail:
tft@vectron.com
Vectron International GmbH & Co. KG reserves the right to make changes to the product(s) and/or information contained herein without
notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such
