A-42375-0047

Description
2.54mm (.100) Pitch KK Header, Breakaway, Vertical, 12 Circuits, 0.38m (15m) Gold (Au) Selective Plating, Mating Pin Length 6.09mm (.240)
File Size521KB,36 Pages
ManufacturerMolex
Websitehttps://www.molex.com/molex/home
Download Datasheet View All

A-42375-0047 Overview

2.54mm (.100) Pitch KK Header, Breakaway, Vertical, 12 Circuits, 0.38m (15m) Gold (Au) Selective Plating, Mating Pin Length 6.09mm (.240)

This document was generated on 04/20/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMA
Part Number:
Status:
Description:
0022284123
Active
2.54mm (.100") Pitch KK® Header, Breakaway, Vertical, 12 Circuits, 0.38µm (15µ")
Gold (Au) Selective Plating, Mating Pin Length 6.09mm (.240")
Documents:
3D Model
Drawing (PDF)
Product Specification PS-10-07 (PDF)
RoHS Certificate of Compliance (PDF)
Agency Certification
CSA
UL
LR19980
E29179
General
Product Family
Series
Application
Product Name
PCB Headers
42375
Board-to-Board, Wire-to-Board
KK®
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Orientation
PC Tail Length (in)
PC Tail Length (mm)
PCB Locator
PCB Retention
PCB Thickness Recommended (in)
PCB Thickness Recommended (mm)
Packaging Type
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Plating min: Mating (µin)
Plating min: Mating (µm)
Plating min: Termination (µin)
Plating min: Termination (µm)
Polarized to Mating Part
Polarized to PCB
Shrouded
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Yes
12
12
Black
100
No
94V-0
No
No
None
None
Brass
Gold
Tin
High Temperature Thermoplastic
1
Vertical
0.125 In
3.18 mm
No
None
0.062 In
1.60 mm
Bag
0.100 In
2.54 mm
15
0.375
100
2.5
No
No
No
No
Yes
0°C to +75°C
EU RoHS
ELV and
Complia
REACH S
Contains
Halogen
Status
Not Halo
Need mo
environm
Email pro
For a mu
Complian
Please vi
non-prod
