JA SERIES
Piconics JA series fixed inductors are a low cost rod core device, aimed at the commercial marketplace where high volume
production, high reliability and low cost are required. The coils are constructed from a single piece of self-bonding wire with a
temperature range of -55° C to + 125° C. They are supplied with a clear epoxy bonding. The leads are supplied not stripped or
tinned, but are solder strippable. Their principal application is low cost commercial RF and IF amplifiers, thick and thin film add
on components.
Piconics L uH +/- Q Min
part
10%
number
JA070K8I
.007
60
JA090K8I
.009
60
JA120K8I
.012
60
JA250K8l
.025
60
JA450K8l
.045
60
JA650K8I
.065
50
JA101K8I
.10
45
JA121K8I
.12
45
JA151K8I
.15
45
JA221K8I
.22
40
JA331K8I
.33
40
JA471K8I
.47
40
JA681K8I
.68
40
JA102K6I
1.0
35
JA152K6I
1.5
30
JA222K6I
2.2
30
JA332K6I
3.3
30
JA472K6I
4.7
30
JA682K6I
6.8
30
JA103K3F
10
25
JA153K3F
15
25
JA183K3F
18
35
JA223K3F
22
35
JA273K3F
27
35
JA333K3F
33
35
JA473K3F
47
35
JA563K3F
56
35
JA683K3F
68
30
JA823K3F
82
30
JA104K3F
100
33
JA124K3F
120
33
JA154K3F
150
35
JA184K3F
180
35
JA224K3F
220
35
JA274K3F
270
35
JA334K3F
330
35
JA394K3F
390
35
JA474K1F
470
35
JA564K1F
560
35
JA684K1F
680
35
JA824K1F
820
35
JA105K1F
1000
33
Test
Freq
MHz
50
50
50
50
50
50
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.25
SRF Min
MHz
3000
3000
2800
2000
1200
1000
700
650
600
480
370
320
240
150
90
75
60
50
40
24
15
12
10
9
9
6
6
6
5.5
4.0
4.0
3.9
3.5
3.2
3.1
2.8
2.5
2.3
2.2
2.1
2.1
1.1
DCR Idc Max
Max
ma
Ohms
.01
300
.02
300
.02
300
.02
300
.03
300
.08
200
.10
100
.12
100
.30
100
.40
100
.60
100
1.0
70
2.1
70
1.4
50
3.3
50
3.6
50
4.3
50
4.7
50
5.3
50
6.0
50
8.1
50
4.0
8I
4.0
77
6.0
73
6.0
69
6.3
63
6.3
60
7.0
57
7.5
56
12
50
14
40
16
36
18
33
21
28
23
25
37
20
39
17
45
15
47
13
62
12
80
11
96
10
FEATURES:
•
Automated Production
•
High Quality
•
Small Size
•
Low Cost
ABSOLUTE MAXIMUM RATINGS:
•
Storage temperature range: -55° C to
+ 125° C
•
Operating temperature range: -55° C to
+ 125° C
•
Temperature rise (at 90°C): 35° C
•
Maximum operating temperature: 125° C
PHYSICAL CHARACTERISTICS:
•
Self-Leaded
•
Solder Strippable
•
Recommend pretinning of leads
prior to circuit insertion
Piconics Inc.
www.Piconics.com
26 Cummings Rd Tyngsboro, MA 01879
E-Mail:
Sales@Piconics.com
Tel: 978-649-7501
Fax: 978-649-9643
