BYV27-400-PBF: DescriptionRectifier Diode; CategoryDiscrete semiconductor diode; File Size314KB，3 Pages; ManufacturerDigitron; Websitehttp://www.digitroncorp.com; Environmental Compliance

Download Datasheet Parametric Compare View All

BYV27-400-PBF Overview

Rectifier Diode

BYV27-400-PBF Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Digitron
Reach Compliance Code	unknown
application	ULTRA FAST RECOVERY
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.07 V
JESD-30 code	E-XALF-W2
Maximum non-repetitive peak forward current	50 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	175 °C
Minimum operating temperature	-55 °C
Maximum output current	2 A
Package body material	UNSPECIFIED
Package shape	ELLIPTICAL
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum repetitive peak reverse voltage	400 V
Maximum reverse current	1 µA
Maximum reverse recovery time	0.025 µs
surface mount	NO
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

High-reliability discrete products

and engineering services since 1977

FEATURES



BYV27-50-BYV27-600

ULTRAFAST RECOVERY RECTIFIERS

Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number.

Available as non-RoHS (Sn/Pb plating), standard, and as RoHS by adding “-PBF” suffix.

MAXIMUM RATINGS

Parameter

Test Condition

Part

BYV27-50

BYV27-100

BYV27-150

Peak reverse voltage, non-repetitive

BYV27-200

BYV27-300

BYV27-400

BYV27-500

BYV27-600

BYV27-50

BYV27-100

BYV27-150

Reverse voltage = repetitive peak reverse voltage

BYV27-200

BYV27-300

BYV27-400

BYV27-500

BYV27-600

Peak forward surge current

Repetitive peak forward current

Average forward current

Pulse energy in avalanche mode, non repetitive

(inductive load switch off)

Junction and storage temperature range

l = 10mm, T

L

= constant

Junction ambient

On PC board with spacing

25mm

I

(BR)

= 1A, T

J

= 175°C

t

p

= 10ms, half-sine wave

I

FSM

I

FRM

I

FAV

E

R

T

J

, T

STG

R

thJA

R

thJA

V

R

= V

RRM

V

RSM

Symbol

Value

55

110

165

220

330

440

560

675

50

100

150

200

300

400

500

600

50

15

2

20

-55 to +175

45

100

A

mJ

°C

K/W

V

Unit

ELECTRICAL CHARACTERISTICS

(T

A

= 25°C unless otherwise specified)

Parameter

Forward voltage

Test Condition

I

F

= 3A

I

F

= 3A, T

J

= 175°C

V

R

= V

RRM

Reverse current

Reverse recovery time

V

RSM

V

R

= V

RRM

, T

J

= 165°C

I

F

= 0.5A, I

R

= 1A, I

R

= .25A

t

rr

I

R

Symbol

V

F

Min

Typ

Max

1.07

0.88

1

100

150

25

ns

µA

Unit

V

Rev. 20121119
