SMV1412

Description
Variable Capacitance Diode, Very High Frequency, 10pF C(T), 12V, Silicon, Hyperabrupt,
CategoryDiscrete semiconductor    diode
File Size37KB，1 Pages
ManufacturerCobham PLC
Download Datasheet Parametric Compare View All

SMV1412 Overview

Variable Capacitance Diode, Very High Frequency, 10pF C(T), 12V, Silicon, Hyperabrupt,

SMV1412 Parametric

Parameter NameAttribute value
MakerCobham PLC
Reach Compliance Codeunknown
ECCN codeEAR99
Other features3% MATCHED SETS ARE AVAILABLE
Minimum breakdown voltage12 V
ConfigurationSINGLE
Diode Capacitance Tolerance20%
Minimum diode capacitance ratio7.5
Nominal diode capacitance10 pF
Diode component materialsSILICON
Diode typeVARIABLE CAPACITANCE DIODE
frequency bandVERY HIGH FREQUENCY
JESD-30 codeR-PDSO-G3
Number of components1
Number of terminals3
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Maximum power dissipation0.25 W
Certification statusNot Qualified
minimum quality factor200
Maximum repetitive peak reverse voltage12 V
surface mountYES
Terminal formGULL WING
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Varactor Diode ClassificationHYPERABRUPT

Preview

Download Datasheet
SILICON HYPERABRUPT
TUNING DIODES
•
High capacitance ratios
•
Linear tuning between 2 and 8 volts
•
Available over a broad range junction capacitances
•
Satisfies a large number of broadband applications thru the VHF frequency band
SMV1401 - SMV1412
DIODE CAPACITANCE
TUNING RATIO (TR)
(CT)
C•1V / C•10V C•2V / C•10V
•
•
pF @ 1V•1MHz pF @ 2V•1 MHz
•
@ 1 MHz
@ 1 MHz
MIN
MAX MIN
MAX
MIN
MIN
440
660
14:1
45
69
10:1
140
210
10:1
96
144
10:1
200
300
10:1
80
120
10:1
54
82
10:1
37
57
10:1
26
40
10:1
17
27
9.5:1
12
18
8.5:1
8
12
7.5:1
QUALITY FACTOR
AVAILABLE
Q
IN THE FOLLOWING
@ 2V • 1 MHz
PACKAGES
MIN
200
-01, -14, -15
200
-01, -08, -09, -15
200
-01, -09, -15
200
-01, -08, -09, -15
200
-01, -09, -15
200
-01, -08, -09, -15
200
-01, -08, -09, -15
200
-01, -06, -08, -09, -10, -15
200
-01, -08, -06
200
-01, -06, -07, -08, -09, -10, -15
200
-01, -06, -07, -08, -09, -10, -15
200
-01, -06, -07, -08, -09, -10, -15
PART
NUMBER
♦♦♦
SMV1401
SMV1402
SMV1403
SMV1404
SMV1405
SMV1406
SMV1407
SMV1408
SMV1409
SMV1410
SMV1411
SMV1412
Device Dissipation (P
D
)
Ta = 25°C
Junction Temperature (T
J
)
Reverse Breakdown Voltage (V
BR
) 10 µAdc
Max Reverse Leakage Current (I
R
) Vr = 10 Vdc
Operating Temperature (Topr)
Storage Temperature (Tstg)
Capacitance Tolerance
♦♦♦
250 mW
125°C
12 Vdc Min
0.1 µAdc
-55° to + 125°C
-65° to + 150°C
Standard Device ± 20%
Package Styles
Requires adding a dash suffix number to the part number
SOT23 SINGLE
SOT23 Common Anode
SOT23 Common Cathode
SOT223
SOD323
SOD523 (SC79, SC90)
TO92 2 Terminal (TMV)
CHIPS
-08
-09
-10
-14
-06
-07
-15
-01
P.O. BOX 609
•
ROCKPORT, MAINE 04856
•
207-236-6076
•
FAX 207-236-9558
