SXN15 Series
DC/DC CONVERTERS
•
•
•
•
•
•
•
•
•
•
Dual positive output
15W High Efficiency DC/DC Converters
1
Two positive outputs
Output voltage tracking
High efficiency
Approved to EN60950, UL/cUL1950
Wide operating temperature up to and exceeding 65°C
(natural convection)
Up to 100% load imbalance
Trim function
No minimum load
Complies with ETS 300 019-1-3/2-3
Fully compliant with ETS 300 386-1
The SXN15 is a new high efficiency open frame isolated 15 Watt converter series. The first
two models in the series feature an input voltage range of 33 to 75VDC and are available in
output voltages of 5V/3.3V and 3.3V/2.5V. The output voltage on each model is adjustable
from 90% to 110% of the nominal value. Typical efficiencies for the models are 86% for the
5V/3.3V and 85% for the 3.3V/2.5V version. The SXN15 series also has a remote on/off
capability with active high or active low logic. Overcurrent and overvoltage protection
features are included as standard. With full international safety approval including EN60950
and cUL1950, the SXN15 reduces compliance costs and time to market.
TÜV
2 YEAR WARRANTY
All specifications are typical at nominal input, full load at 25°C unless otherwise stated
SPECIFICATIONS
OUTPUT SPECIFICATIONS
Voltage adjustability
Voltage setpoint
Voltage accuracy
(See Note 8)
Output voltage
(Over all line and
load conditions)
Minimum load
Ripple and noise
20MHz bandwidth
Transient response
50% to 75% to 50%
Both outputs
Both outputs
Both outputs
5V/3.3V
3.3V/2.5V
4.931V
3.236V
3.297V
2.431V
<
<
<
<
±10% min.
±2% typ.
±4% max.
V
o1
V
o2
V
o1
V
o2
<
<
<
<
5.133V
3.368V
3.431V
2.531V
0%
140mV pk-pk max.
50mV rms max.
D05-3V3, V
01
D05-3V3, V
02
D3V3-2V5, V
01
D3V3-2V5, V
02
To 1.0%, no external cap.
10A rms
180mV max.
100mV max.
150mV max.
100mV max.
100µs
EMC CHARACTERISTICS
ETS 300 386-1 table 5
Conducted emissions
Radiated emissions
Immunity:
ESD air
ESD contact
EFT DC power
EFT signal
Radiated field enclosure
Surges indoor signal
Conducted (DC power)
Conducted (signal)
Input transients
EN55022 (See Note 6)
Level A
EN55022 (See Note 6)
Level B
EN55022 (See Longform Data Sheet) Level B
EN61000-4-2 8kV, 15kV
EN61000-4-2 6kV, 8kV
EN61000-4-4 2kV, 4kV
EN61000-4-4 1kV, 2kV
EN61000-4-3 10V/m
EN61000-4-5 500V
EN61000-4-6 10V
EN61000-4-6 10V
ETS 300 132-2, ETR 283
(See Note 7)
GENERAL SPECIFICATIONS
Efficiency
Operational insulation
Input fuse
Switching frequency
Approvals and
standards
(See Notes 1, 2 and 3)
Weight
Fixed
Input/output
See table
1500VDC
2.0A slow blow
265kHz
UL/cUL1950, EN60950
TÜV Rheinland
12g (0.42oz)
MIL-HDBK-217F
>600,000 hours
48S05 @ 48Vin, 40°C,
100% load ground benign
BELLCORE 332
>1,500,000 hours
Peak dev. settling time
Short circuit protection
(Isc)
Tracking
INPUT SPECIFICATIONS
Input voltage range
Input current
UVLO turn ON voltage
UVLO turn OFF voltage
Continuous
automatic recovery
Max. differential 0.7V during
start-up
48Vin nominal
No load
Remote OFF
33 to 75VDC
35mA max.
25mA max.
33V (typ)
30V (typ)
MTBF
Representative model:
ENVIRONMENTAL SPECIFICATIONS
Thermal performance
(See Note 5)
Operating ambient
temperature
Non-operating
-40°C to +65°C
-40°C to +120°C
Active high remote ON/OFF
Logic compatibility
ON
OFF
Start-up time
Nominal line
(See Note 4)
Open collector ref. to -input
Open circuit or >2VDC
<1.2VDC
2.5ms (typ)
File Name: SXN15D.PDF Rev: 15 Nov 2001
SXN15 Series
DC/DC CONVERTERS
INPUT
VOLTAGE
33-75VDC
33-75VDC
Notes
1
2
Dual positive output
15W High Efficiency DC/DC Converters
2
For the most current data and application support visit www.artesyn.com/powergroup/products.htm
OUTPUT VOLTAGE
1
2
5V
3.3V
3.3V
2.5V
OUTPUT CURRENT
1
2
3.0A
3.5A
4.5A
4.5A
OVP
1
6.2V
4.0V
2
4.2V
3.0V
TYPICAL
EFFICIENCY
86%
85%
MODEL
NUMBER
(4)
SXN15-48D05-3V3
SXN15-48D3V3-2V5
PIN CONNECTIONS
PIN NUMBER
1
2
3
4
5
6
7
8
9
10
FEATURE
V
o1
+
Com
V
o2
+
Trim
N/C
N/C
N/C
On/Off
N/C
Vin -
Vin +
3
4
5
6
7
8
User must provide recommended fuses in order to comply with safety
approvals.
Maximum continuous output power.
15 Watts for D05-3V3 model.
11.55 Watts for D3V3-2V5 model.
Maximum temperature on hot spots not to exceed 115°C.
Refer to Longform data sheet for details.
Active low remote on/off is available. Standard product is active high.
Designate with the suffix ‘-R’, e.g. SXN15-48D05-3V3-R.
Operating ambient temperatures are specified at natural convection.
Higher operating temperatures are possible with increased airflow.
See Application Note 116 for further details.
Measured with external filter. See Application Note 116 for further details.
Signal line assumed < 3m in length.
This parameter is calculated at worst case line, load, temperature and
initial conditions.
CAUTION: Hazardous internal voltages and high temperatures.
Ensure that unit is not user accessible.
International Safety Standard Approvals
UL/cUL 1950 3rd edition. File No. E135734
11
TÜV
TÜV Rheinland. Certificate No. R2074133
1.905 (48.39)
All Dimensions in Inches [mm]
TOP VIEW
1.010 (25.65)
SIDE VIEW
1
0.335 (8.51)
0.110 (2.79)
0.820 (20.83)
0.020 (0.51)
0.120 (3.05)
1
2
3
4
5
6
0.072 (1.83)
0.070 (1.78)
Tolerance:
±
.015 (± .38)
Recommended Land & Hole Pattern
1.031 (26.19)
BOTTOM VIEW
0.840 (21.37)
0.197 (5.00)
11
10
9
8
7
0.197 (5.00)
0.347 (8.81)
0.105 (2.67)
0.302 (7.67)
1.136 (28.85)
1.483 (37.67)
1.680 (42.67)
11
10
9
8
7
1.020 (25.91)
0.800 (20.32)
0.130 (3.30)
0.110 (2.79)
1
2
3
4
5
6
1.705 (43.31)
Data Sheet © Artesyn Technologies® 2002
The information and specifications contained in this data sheet are believed to be correct at time of publication. However, Artesyn Technologies accepts no responsibility for consequences arising
from printing errors or inaccuracies. Specifications are subject to change without notice. No rights under any patent accompany the sale of any such product(s) or information contained herein.
Please consult our website for the following items:
Application Note
Longform Data Sheet
www.artesyn.com
File Name: SXN15D.PDF Rev: 15 Nov 2001
