OUTPUT CIRCUITS
TYPE R (Voltage)
Vcc
2kΩ
Signal
20mA
max
7.5
3-M3
CABLE SHIELD
0V
Ø44
5.5
TYPE C (Open Coll)
Vcc
Signal
30mA
max
*
30˚
CABLE SHIELD
0V
STANDARD RESOLUTIONS
MES30-XXX
40
40 P/R
1000 1000 P/R
100 100 P/R
1024 1024 P/R
200 200 P/R
1200 1200 P/R
250 250 P/R
1500 1500 P/R
300 300 P/R
1800 1800 P/R
360 360 P/R
2000 2000 P/R
400 400 P/R
2048 2048 P/R
500 500 P/R
‡
2500 2500 P/R
600 600 P/R
‡
3600 3600 P/R
720 720 P/R
‡
4500 4500 P/R
800 800 P/R
‡
9000 9000 P/R
SPECIFICATIONS
Supply Voltage
Current
Output
Voltage
Sink Current
Signal Risetime
Freq. Response
MECHANICAL
1. Max Shaft Load; radial: 2.0 kgf
axial: 1.0 kgf
2. Moment of Inertia: 4 g•cm
2
3. Angular Acceleration: 1x10
4
rad/S
2
4. Max Slewing Speed: 6000 RPM
5. Starting Torque: 30 gf•cm max.
6. Rotational Life: 1 x 10
7
rpm•hrs
120˚
PCD36
‡
Type "E" not available
TYPE E (Line-Driver)
24
5.5
10
Vcc
Signal
Inv. Signal
0V
*Ø8, 9.525 (0.375"), &
12 optional bore sizes
OUTPUT WAVEFORM
(Clockwise
rotation viewed from front)
ORDERING INSTRUCTIONS
TYPE
R
C
60mA max.
E
5VDC
≥
2.5V
R, C
E
Sig A
5 ~ 12 VDC
24 VDC ±10%
P
Sig A
Sig B
h
Sig B
h min
Sig Z
MES30-_ _ _-_-_
Resolution
Output Format:
Blank = Voltage
C = Open Coll
E = Line Driver
Input Voltage:
1 = 5VDC
±10%
2 = 12VDC
±10%
3 = 5~12VDC
±10%
4 = 24VDC
±10%
Signal A
ab cd
Signal B
Signal Z
1
P=
PPR
P P
a,b,c,d = ±
4 8
h max
H
L
Vcc - 1V
≤
0.5V
20mA max.
≤
2µS
50 - 100kHz
Sig Z
h = P ± 0.75P
Wave Duty Ratio: 50% ± 25%
ENVIRONMENTAL
1.
2.
3.
4.
5.
Operating Temp: 0° to +60° C
Storage Temp: -20° to +80° C
Humidity: 90% RH, no condensation
Vibration: 10~ 55 Hz, 1.5 mm, 2 hrs
Shock: 50G, 11ms, 3 axes, 3 reps
C U I Stack, Inc.
9615 SW Allen Blvd. #103
Beaverton, OR 97005
Tel: 503/643-4899 FAX: 503/643-6129
DRAWN BY
UPDATED
CHECKED
RELEASED
PART NO.
REV.
MES30-XXX-X-X A
