788726-1 Product Details
Live Product Chat
Product Photo
Universal Serial Bus (USB) Connectors
Not EU R oHS or ELV C om plia nt
(
Find R oHS C om plia nt Alte rna te s
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
788726-1
T E I nternal N umber: 7 8 8 7 2 6 - 1
Product Highlights:
l
Size = Standard
l
A Series
l
Receptacle
l
Without Locking Feature
l
2 Ports
View all Features
Superseded
Search for Replacement Parts
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Size = Standard
l
Gender = Receptacle
l
Number of Ports = 2
l
Orientation = Right Angle
l
PC B Thickness (mm [in]) = 1.57 [0.062]
l
Number of Positions = 4
Mechanical Attachment:
l
Mount Location = Top
Electrical Characteristics:
l
Panel Ground Type = Ground Finger
Termination Related Features:
l
Termination Method = Solder to PC Board
l
Tail Length (mm [in]) = 2.84 [0.112]
Body Related Features:
l
Series
= A
l
Locking Feature = Without
l
LED = Without
l
Panel Ground
= With
l
PC B Retention Method = Kinked Leg
l
Shell Plating = Bright Tin
l
Assembly Process Feature = Without Pick and Place C over
l
Locating Post(s) = Without
Contact Related Features:
l
C ontact Termination Type = Through Hole
l
C ontact Mating Area Plating Material
= Gold or Gold Flash over
Palladium Nickel
l
C ontact Mating Area Plating Thickness = 30 Microinches
Housing Related Features:
l
Housing C olor
= Black
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not suitable for lead free processing
l
TID Number = 60000243
Conditions for Usage:
l
Terminate To = Printed C ircuit Board
Packaging Related Features:
l
Panel Ground Location = C enter
l
Packaging Method
= Tray
Other:
l
Brand = AMP
