Crystal oscillator
Product Number (please contact us)
CRYSTAL OSCILLATOR (SPXO)
OUTPUT : LV-PECL
SG-770: X1G0023x1xxxx00
SG-771: X1G00282xxxxx00
SG - 770
/
SG - 771
series
Frequency
range
:
Supply
voltage
:
Output
:
External
dimensions
:
Features
:
Function
:
:
50 MHz to 230 MHz
2.5 V Typ. / 3.3 V Typ.
Differential LV-PECL
7.0 × 5.0 × 1.6 mm
Fundamental mode oscillator with HFF-XTAL
Standby (
ST
)
···SG-770 series
Output enable (OE) ···SG-771 series
Actual size
Specifications (characteristics)
Item
Output frequency range
Supply voltage
Storage temperature
Operating temperature
Frequency tolerance
Current consumption
Symmetry
Symbol
f
0
V
CC
T_stg
T_use
f_tol
I
CC
SYM
V
OH
V
OL
L_ECL
V
IH
V
IL
t
r
/ t
f
t_str
SG-770SDD
Specifications
SG-770SCD
SG-771PCD
80.000 MHz to
175.000 MHz
Conditions / Remarks
Please contact us about available
frequencies.
Storage as single product.
50.000 MHz to 230.000 MHz
2.5 V
0.125
V
3.3 V
0.165
V
3.3 V
0.165
V
-55
C
to +125
C
As per below table
-6
50
10
Max.
As per below table
90 mA Max.
70 mA Max.
45 % to 55 %
40 % to 60 %
V
CC
-1.1 V Min.
Output voltage
V
CC
-1.5 V Max.
Output load condition (ECL)
LV-PECL
70 % V
CC
Min.
Input voltage
30 % V
CC
Max.
Rise time / Fall time
1 ns Max.
Start-up time
10 ms Max.
*1
This is included in
-6
Frequency aging
f_aging
5
10 / year Max.
frequency tolerance
specification.
*1 Rise time (0 V to 2.13 V or 3.15 V) of V
CC
> 150
s
Product Name
(Standard form)
50
at outputs crossing point
ST
terminal or OE terminal
20 % to 80 % (V
OH
-V
OL
)
Time at minimum supply voltage to be 0 s
+25
C,
V
CC
=2.5 V or 3.3 V, First year.
SG-770 S D D - 156.250000 - Q
①
②③
④
⑤
①Model ②Function
(P: Output enable, S:Standby)
③Supply
voltage
④Frequency(MHz) ⑤Frequency
tolerance/ Operating temperature
⑤
SG-770 series
L
B
P
Q
Frequency
tolerance
50
10
-6
③Supply
voltage
D
C
2.5 V Typ.
3.3 V Typ.
Operating
temperature
40
°C to +85 °C
20
°C to +70 °C
10
°C to +70 °C
0 °C to +70 °C
⑤
SG-771series
A
B
C
D
(Unit:mm)
Frequency
tolerance
-6
30
10
-6
35
10
-6
20
10
-6
25
10
Operating
temperature
-40 °C to +85 °C
-40 °C to +85 °C
-10 °C to +70 °C
-10 °C to +70 °C
Frequency
aging
10 years
20 years
10 years
20 years
(Unit:mm)
External dimensions
7.0±0.2
#6
#5
#4
Footprint (Recommended)
1.8
C (ex. 0.01 µF)
#6
#5
#4
5.0±0.2
Pin map
SCD 674A
#1
#2
#3
1.6±0.2
Pin
1
2
3
4
5
6
Connection
ST or OE
DNC
GND
OUT1(Positive)
OUT2(Negative)
V
CC
C
4.2
Resist
#1
#2
5.08
#3
1.4±0.15
C0.5
Note:
*Please do not connect DNC pin (2 pin) to the
other circuit patterns such as Supply voltage or GND.
SG-770series
ST pin = HIGH or “Open” : Specified frequency output.
ST pin = LOW : Output is high impedance, oscillation stop.
SG-711series
OE pin = HIGH or “Open” : Specified frequency output.
OE pin = LOW : Output is high impedance
To maintain stable operation, provide a 0.01uF to
0.1uF by-pass capacitor at a location as near as
possible to the power source terminal of the crystal
product (between Vcc - GND).
2.54±0.15 2.54±0.15
1.2±0.15
2.0
E 156.250L
PROMOTION OF ENVIRONMENTAL MANAGEMENT SYSTEM
CONFORMING TO INTERNATIONAL STANDARDS
At Seiko Epson, all environmental initiatives operate under the
Plan-Do-Check-Action (PDCA) cycle designed to achieve continuous
improvements. The environmental management system (EMS)
operates under the ISO 14001 environmental management standard.
All of our major manufacturing and non-manufacturing sites, in
Japan and overseas, completed the acquisition of ISO 14001
certification.
ISO 14000 is an international standard for environmental
management that was established by the International
Standards Organization in 1996 against the background of
growing concern regarding global warming, destruction of
the ozone layer, and global deforestation.
WORKING FOR HIGH QUALITY
In order provide high quality and reliable products and services
than meet customer needs,
Seiko Epson made early efforts towards obtaining ISO9000 series
certification and has acquired ISO9001 for all business
establishments in Japan and abroad. We have also acquired ISO/TS
16949 certification that is requested strongly by major automotive
manufacturers as standard.
►Explanation
of the mark that are using it for the catalog
►Pb
free.
►Complies
with EU RoHS directive.
*About the products without the Pb-free mark.
Contains Pb in products exempted by EU RoHS directive.
(Contains Pb in sealing glass, high melting temperature type solder or other.)
►Designed
for automotive applications such as Car Multimedia, Body Electronics, Remote Keyless Entry etc.
►Designed
for automotive applications related to driving safety (Engine Control Unit, Air Bag, ESC etc ).
ISO/TS16949 is the international standard that added the
sector-specific supplemental requirements for automotive
industry based on ISO9001.
Notice
This material is subject to change without notice.
Any part of this material may not be reproduced or duplicated in any form or any means without the written permission of Seiko Epson.
The information about applied circuitry, software, usage, etc. written in this material is intended for reference only. Seiko Epson does
not assume any liability for the occurrence of infringing on any patent or copyright of a third party. This material does not authorize the
licensing for any patent or intellectual copyrights.
When exporting the products or technology described in this material, you should comply with the applicable export control laws and
regulations and follow the procedures required by such laws and regulations.
You are requested not to use the products (and any technical information furnished, if any) for the development and/or manufacture of
weapon of mass destruction or for other military purposes. You are also requested that you would not make the products available to
any third party who may use the products for such prohibited purposes.
These products are intended for general use in electronic equipment. When using them in specific applications that require extremely
high reliability, such as the applications stated below, you must obtain permission from Seiko Epson in advance.
/ Space equipment (artificial satellites, rockets, etc.) / Transportation vehicles and related (automobiles, aircraft, trains,
vessels, etc.) / Medical instruments to sustain life / Submarine transmitters / Power stations and related / Fire work equipment
and security equipment / traffic control equipment / and others requiring equivalent reliability.
All brands or product names mentioned herein are trademarks and/or registered trademarks of their respective.
Seiko Epson Corporation
