Common Mode Chokes
For three-phase AC power lines
●Three-phase
FM-H coils
Three-phase FM-H coils
FM-H coils are compact common modes chokes having
excellent RF noise suppression properties for three-phase AC
400V power lines.
Table 9. Standard Specifications
Item
Rated voltage
Insulation voltage rating
Insulation resistance
Insulation grade
Temperature rise
Operating temperature range
AC415V
AC2kV for 1min. or AC2.4kV for 3 sec. (line
–
line)
Over 100MΩafter applying DC500V for 1min. (line
–
line)
Class B (130℃)
*60℃
-40℃– +130℃ (including temperature rise)
Specification
・The above specifications are in accordance with Electrical Appliance and Material Control Law, UL, CSA and IEC standards.
・No Ozone Layer Depleting Chemicals are used in these products or in their manufacturing process.
* Note 1: The temperature rise in Table 1 is a projected value based on temperature increase by the heat from DC resistance of the coil when the rated current
(DC or 50/60Hz) in Table 2 is conducted.
* Note 2: The temperature rise is affected by the mounting condition on the circuit board and the amount of harmonic distortion on the load current. Please make
sure that the temperatures of the coil and the terminals are not exceeded the operating temperature range.
Table 10. Product code, part number and specifications
Rated
Product code
P/N
current
(A)
F1AH0286
F1AH0285
F1AH0287
F1AH0288
FM-H15O672MB
FM-H20O472MB
FM-H25O302MB
FM-H30O232MB
15
20
25
30
L(mH)
10kHz
MIN.
24.1
16.8
10.7
8.2
100kHz
MIN.
6.7
4.7
3.0
2.3
Wire
diameter
(mm)
1.8
2.2
2.4
2.8
85
52
75
40
Finished dimensions(mm)
A
MAX.
B
MAX.
F
REF.
G
REF.
Weight
(g)
TYP.
370
410
410
440
DC
resistance
(mΩ)
MAX.
17.0
9.5
6.5
4.5
・UL94V-0 certified resin is used for the case and the base plate.
・Lead free type coils are also available.
P/N for lead free type has "PF" at the last digits. The above table does not show product code for lead free type. Please contact us for the code.
・Custom made coils are also available.
A
②
①
B
15±5
①
②
③
⑥
④
⑤
8MAX.
①
G
②
１
３
５
③
⑤
⑥
④
⑥
⑤
F
④
⑤
２
４
６
Polarity
Figure 37. FM-H□□□□□□
Figure 38. Circuit diagram
100
FM-H □□ ○ □□△ MB
Impedance (kΩ）
Content of
part number
Coil name
Rated current(A)
Core shape
L : □□×10
△
μH
10
1
FM-H15O672MB
FM-H20O472MB
FM-H25O302MB
FM-H30O232MB
0.1
0.01
1
10
100
1000
Frequency(kHz)
10000
100000
Figure 39. Frequency dependence of impedance
16
For safety and the proper usage, you are requested to approve our product specifications or to transact the approval sheet for product specifications before ordering.
This catalog and its contents are subject to change without notice.
